XKU304A-TYMMB3 (2006)
Toyota Dyna/Toyoace Hv
(0610- )5F
M550
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33205 - SHAFT SUB-ASSY, SELECT LEVER | ||||
| 33262-37020 |
XKU304,344 |
1 | ||
| 33205-37040 |
XKU30#,338,34#,508..5F |
1 | ||
| 33205D - WASHER(FOR OUTER LEVER OIL SETTING) | ||||
| 90201-13029 |
XKU304,344 外径=28 |
1 | ||
| 90201-13029 |
XKU30#,338,34#,508..5F 外径=28 |
1 | ||
| 33212A - FORK, GEAR SHIFT, NO.1 | ||||
| 33210-37010 |
XKU30#,34#..(DM6,T3,T4)..5F |
1 | ||
| 33212-60050 |
XKU304,344 |
1 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05002 |
XKU30#,338,34#,508..5F |
3 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05002 |
XKU30#,338,34#,508..5F |
3 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05002 |
XKU30#,338,34#,508..5F |
3 | ||
| 33213B - BOLT(FOR SHIFT FORK SET) | ||||
| 90105-08211 |
XKU30#,338,34#,508..5F |
1 | ||
| 90105-08211 |
XKU304,344 |
2 | ||
| 33213G - FORK, GEAR SHIFT, NO.2 | ||||
| 33220-37020 |
XKU30#,338,34#,508..5F |
1 | ||
| 33213-60060 |
XKU304,344 |
1 | ||
| 33220-37010 |
XKU30#,338,34#,508..5F |
1 | ||
| 33214G - FORK, GEAR SHIFT, NO.3 | ||||
| 33214-37020 |
XKU30#,338,34#,508..5F |
1 | ||
| 33219 - PLATE, SHIFT FORK LOCK | ||||
| 33219-37010 |
XKU30#,338,34#,508..5F |
1 | ||
| 33240 - BRACKET ASSY, REVERSE SHIFT ARM | ||||
| 33240-37010 |
XKU30#,338,34#,508..5F |
1 | ||
| 33242 - SHAFT, GEAR SHIFT FORK, NO.1 | ||||
| 33242-37050 |
XKU30#,338,34#,508..5F |
1 | ||
| 33243A - SHAFT, GEAR SHIFT FORK, NO.2 | ||||
| 33244-37040 |
XKU304,344 |
1 | ||
| 33243-37050 |
XKU30#,34#..(DM6,T3,T4)..5F |
1 | ||
| 33244D - SHAFT, GEAR SHIFT FORK, NO.3 | ||||
| 33244-37070 |
XKU30#,338,34#,508..5F |
1 | ||
| 33244-37060 |
XKU30#,338,34#,508..5F |
1 | ||
| 33245G - SHAFT, GEAR SHIFT FORK, NO.4 | ||||
| 33242-37040 |
XKU304,344 |
1 | ||
| 33245-37020 |
XKU30#,338,34#,508..5F |
1 | ||
| 33245-37030 |
XKU30#,338,34#,508..5F |
1 | ||
| 33250 - SHAFT ASSY, SHIFT & SELECT LEVER | ||||
| 33250-37010 |
XKU30#,338,34#,508..5F |
1 | ||
| 33257 - LEVER, SELECT OUTER | ||||
| 33257-37050 |
XKU304,344 |
1 | ||
| 33257-37090 |
XKU30#,338,34#,508..5F |
1 | ||
| 33257P - PIN, SELECT OUTER LEVER LOCK | ||||
| 33282-35010 |
XKU304,344 |
1 | ||
| 33282-35010 |
XKU30#,338,34#,508..5F |
1 | ||
| 33264A - PLUG, INTER LOCK HOLE | ||||
| 90341-12008 |
XKU304,344 外径=18 |
4 | ||
| 90341-12008 |
XKU30#,338,34#,508..5F 外径=18 |
3 | ||
| 33264A - PLUG, INTER LOCK HOLE | ||||
| 90341-12008 |
XKU304,344 外径=18 |
4 | ||
| 90341-12008 |
XKU30#,338,34#,508..5F 外径=18 |
3 | ||
| 33264A - PLUG, INTER LOCK HOLE | ||||
| 90341-12008 |
XKU304,344 外径=18 |
4 | ||
| 90341-12008 |
XKU30#,338,34#,508..5F 外径=18 |
3 | ||
| 33264C - BALL (FOR SHIFT INTER LOCK) | ||||
| 90360-10003 |
XKU30#,338,34#,508..5F |
3 | ||
| 90360-10003 |
XKU304,344 |
3 | ||
| 33264C - BALL (FOR SHIFT INTER LOCK) | ||||
| 90360-10003 |
XKU30#,338,34#,508..5F |
3 | ||
| 90360-10003 |
XKU304,344 |
3 | ||
| 33264C - BALL (FOR SHIFT INTER LOCK) | ||||
| 90360-10003 |
XKU30#,338,34#,508..5F |
3 | ||
| 90360-10003 |
XKU304,344 |
3 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14155 |
XKU304,344 長さ=29.3 |
3 | ||
| 90501-14194 |
XKU30#,338,34#,508..5F 長さ=31.7 |
3 | ||
| 90501-15055 |
XKU30#,338,34#,508..5F 長さ=90.5 |
1 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14155 |
XKU304,344 長さ=29.3 |
3 | ||
| 90501-14194 |
XKU30#,338,34#,508..5F 長さ=31.7 |
3 | ||
| 90501-15055 |
XKU30#,338,34#,508..5F 長さ=90.5 |
1 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14155 |
XKU304,344 長さ=29.3 |
3 | ||
| 90501-14194 |
XKU30#,338,34#,508..5F 長さ=31.7 |
3 | ||
| 90501-15055 |
XKU30#,338,34#,508..5F 長さ=90.5 |
1 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14155 |
XKU304,344 長さ=29.3 |
3 | ||
| 90501-14194 |
XKU30#,338,34#,508..5F 長さ=31.7 |
3 | ||
| 90501-15055 |
XKU30#,338,34#,508..5F 長さ=90.5 |
1 | ||
| Common parts | ||||
| 91611-B0825 | ||||
| 94130-60600 | ||||
| 94531-00600 | ||||
