XZU645-TQTQX3 (2019)

Toyota Dyna/Toyoace

Production May 2019 - Sep 9999
Engine N04C
Transmission 6FC ATM
Displacement 2500cc
Power 168 HP (125 kW)

ILLUST NO. 2 OF 5(1905- )XZU645..30T..DCRWD

Click highlighted areas on diagram

diagram 48414C 48415C 48416B 48417D 48418B 48418B 48418B 48418B 48516D 48517B 51013 51014 51017 51018 51100F 51115 51116 51143A 51144A 51155B 51155B 51155C 51155C 51155D 51155D 51155G 51155G 51201A 51203 51204 51205 51206 51209C 51705E 9155201020 9155201020 9155201025 9155281030 91552F1240 9415121000 9415121000 9415121000 9415181000
Part # Description Qty Price
48414C - BRACKET, SPRING, NO.3 RH
48414-37100

XZU645..30T..DCRWD;XZC655,XZU600,640,650,655,685,695..(T2,T3,T4)..DCRWD

 1
48414-37240

XZU645..20T..DCRWD;XZC60#,645,675,XZU600,605,675..(DM3,DM5,DM6,T2,T4,T5)..DCRWD

 1
48415C - BRACKET, SPRING, NO.3 LH
48414-37240

XZU645..20T..DCRWD;XZC60#,645,675,XZU600,605,675..(DM3,DM5,DM6,T2,T4,T5)..DCRWD

 1
48415-37020

XZU645..30T..DCRWD;XZC655,XZU600,640,650,655,685,695..(T2,T3,T4)..DCRWD

 1
48416B - BRACKET, SPRING, NO.4 RH
48416-37100

XZU645..30T..DCRWD;XZC655,XZU600,640,650,655,685,695..(T2,T3,T4)..DCRWD

 1
48416-37200

XZU645..20T..DCRWD;XZC60#,645,675,XZU600,605,675..(DM3,DM5,DM6,T2,T4,T5)..DCRWD

 1
48417D - BRACKET, SPRING, NO.4 LH
48416-37100

XZU645..30T..DCRWD;XZC655,XZU600,640,650,655,685,695..(T2,T3,T4)..DCRWD

 1
48416-37200

XZU645..20T..DCRWD;XZC60#,645,675,XZU600,605,675..(DM3,DM5,DM6,T2,T4,T5)..DCRWD

 1
48418B - BRACKET, SPRING, NO.6
48418-36090

XZU645..30T..DCRWD;XZC655,XZU600,602,640,642,65#,685,695..(DM7,T2,T3,T4)..(DCRWD,DCVTO)

 4
48418B - BRACKET, SPRING, NO.6
48418-36090

XZU645..30T..DCRWD;XZC655,XZU600,602,640,642,65#,685,695..(DM7,T2,T3,T4)..(DCRWD,DCVTO)

 4
48418B - BRACKET, SPRING, NO.6
48418-36090

XZU645..30T..DCRWD;XZC655,XZU600,602,640,642,65#,685,695..(DM7,T2,T3,T4)..(DCRWD,DCVTO)

 4
48418B - BRACKET, SPRING, NO.6
48418-36090

XZU645..30T..DCRWD;XZC655,XZU600,602,640,642,65#,685,695..(DM7,T2,T3,T4)..(DCRWD,DCVTO)

 4
48516D - BRACKET SUB-ASSY, REAR SHOCK ABSORBER, UPPER RH
48505-37130

XZC605,645,655,675,XZU60#,64#,65#,675,685,695..(DM3,DM6,DM7,T2,T3,T4,T5)..(DCRWD,DCVTO)

 1
48517B - BRACKET SUB-ASSY, REAR SHOCK ABSORBER, UPR LH
48505-37130

XZC605,645,655,675,XZU60#,64#,65#,675,685,695..(DM3,DM6,DM7,T2,T3,T4,T5)..(DCRWD,DCVTO)

 1
51013 - CHANNEL SUB-ASSY, SIDE RAIL, INNER FRONT RH
51013-37560

XZC605,645,655,XZU605,645,655..DCRWD

 1
51014 - CHANNEL SUB-ASSY, SIDE RAIL, INNER FRONT LH
51014-37530

XZC605,645,655,XZU605,645,655..DCRWD

 1
51017 - REINFORCEMENT SUB-ASSY, SIDE RAIL, NO.1 RH
51017-37170

XZC605,645,655,XZU605,645,655..DCRWD

 1
51018 - REINFORCEMENT SUB-ASSY, SIDE RAIL, NO.1 LH
51018-37230

XZC60#,630,645,655,XZU60#,630,64#,65#..DCRWD,DCVTO

 1
51100F - FRAME SUB-ASSY
51002-3VF80

XZU645..30T..DCRWD

 1
51115 - RAIL, FRAME SIDE, REAR RH
51115-37650

XZU640,645..SCB..30T..DCRWD

 1
51116 - RAIL, FRAME SIDE, REAR LH
51116-37490

XZU640,645..SCB..30T..DCRWD

 1
51143A - REINFORCEMENT, SIDE RAIL, FRONT RH
51141-37350

XZC60#,645,655,XZU60#,64#,65#..(DCRWD,DCVTO)..(CBU,IV3,IV5,IV6,IV7)

 2
51144A - REINFORCEMENT, SIDE RAIL, FRONT LH
51141-37350

XZC60#,645,655,XZU60#,64#,65#..(DCRWD,DCVTO)..(CBU,IV3,IV5,IV6,IV7)

 2
51155B - STIFFENER, FRAME SIDE RAIL, REAR NO.2
51155-37080

XZU645..30T..DCRWD;XZC655,XZU600,640,650,655..(T2,T3,T4)..DCRWD

 2
51155B - STIFFENER, FRAME SIDE RAIL, REAR NO.2
51155-37080

XZU645..30T..DCRWD;XZC655,XZU600,640,650,655..(T2,T3,T4)..DCRWD

 2
51155C - STIFFENER, FRAME SIDE RAIL, REAR NO.3
51155-37260

XZU645..30T..DCRWD;XZC655,XZU600,602,640,642,65#..(DM7,T2,T3,T4)..(DCRWD,DCVTO)..(CBU,IV3,IV6,IV7)

 2
51155C - STIFFENER, FRAME SIDE RAIL, REAR NO.3
51155-37260

XZU645..30T..DCRWD;XZC655,XZU600,602,640,642,65#..(DM7,T2,T3,T4)..(DCRWD,DCVTO)..(CBU,IV3,IV6,IV7)

 2
51155D - STIFFENER, FRAME SIDE RAIL, REAR NO.1
51155-37060

XZC605,645,655,675,XZU60#,64#,65#,675,685,695..(DM3,DM6,T2,T3,T4,T5)..(DCRWD,DCVTO)

 2
51155D - STIFFENER, FRAME SIDE RAIL, REAR NO.1
51155-37060

XZC605,645,655,675,XZU60#,64#,65#,675,685,695..(DM3,DM6,T2,T3,T4,T5)..(DCRWD,DCVTO)

 2
51155G - STIFFENER, FRAME SIDE RAIL, REAR NO.4
51155-37250

XZU645..30T..DCRWD;XZC655,XZU600,602,640,642,65#..(DM7,T2,T3,T4)..(DCRWD,DCVTO)..(CBU,IV3,IV6,IV7)

 2
51155G - STIFFENER, FRAME SIDE RAIL, REAR NO.4
51155-37250

XZU645..30T..DCRWD;XZC655,XZU600,602,640,642,65#..(DM7,T2,T3,T4)..(DCRWD,DCVTO)..(CBU,IV3,IV6,IV7)

 2
51201A - CROSSMEMBER SUB-ASSY, FRAME, FRONT
51211-37280

XZC60#,630,645,655,XZU60#,630,64#,65#..DCRWD,DCVTO

 1
51203 - CROSSMEMBER SUB-ASSY, FRAME, NO.2
51202-37280

XZU600..DM5..IV3;XZU640..DCRWD..IV4;XZU600..(DM5,T3)..DCRWD..(CBU,IV4);XZC60#,630,645,655,675,XZU605,630,645,655,675,685,695..DCRWD

 1
51204 - CROSSMEMBER SUB-ASSY, FRAME, NO.3
51203-37390

XZU600,640..SCB..(DCRWD,DCVTO);XZC60#,645,655,675,XZU602,605,642,645,65#,675,685,695..DCRWD,DCVTO

 1
51205 - CROSSMEMBER SUB-ASSY, FRAME, NO.4
51205-37190

XZU645..30T..DCRWD;XZU600,602,640,642,685,695..(DM7,T3,T4)..(DCRWD,DCVTO)..(CBU,IV3,IV6,IV7)

 1
51205-37200

XZU645..20T..DCRWD;XZC605,645,675,XZU600,605,675..(DM3,DM6,T2,T4,T5)..DCRWD

 1
51206 - CROSSMEMBER SUB-ASSY, FRAME, NO.5
51206-37090

XZU645..20T..DCRWD;XZC605,645,675,XZU600,605,675..(DM3,DM6,T2,T4,T5)..DCRWD

 1
51261-37190

XZU645..30T..DCRWD;XZU600,602,640,642,685..(DM7,T3,T4)..(DCRWD,DCVTO)

 1
51209C - CROSSMEMBER SUB-ASSY, FRAME, REAR
51291-37040

XZC675,XZU600,675..DM5..DCRWD;XZC600,645,655,XZU64#,65#,685,695..DCRWD,DCVTO

 1
51705E - BRACKET SUB-ASSY, CAB REAR MOUNTING
51705-37B40

XZC605,645,655,XZU605,645,655..SCB..DCRWD

 1
Common parts
91552-01020
91552-01025
91552-81030
91552-F1240
94151-21000
94151-81000

ILLUST NO. 4 OF 5(1905- )DCRWD,DCVTO

Click highlighted areas on diagram

ﾌﾟﾛﾍﾟﾗｼｬﾌﾄｶﾞｰﾄﾞ

diagram 51569 51569C 9155180825 9155180825
Part # Description Qty Price
51569 - GUARD, PROPELLER SHAFT
51569-37430

XZU640..SCB..DCRWD;XZC605,645,675,XZU60#,645,675,685..(DM3,DM6,T2,T3,T4,T5)..(DCRWD,DCVTO)..(CBU,IV3,IV5,IV6,IV7)

 1
Common parts
91551-80825
