XZU605A-TYFMX5 (2019)
Toyota Dyna/Toyoace
(1107- )XZU605..DCRTH,DCRWD ; (1107- )XZU645,655..T4..20T ; (1107- )XZU645
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04465 - PAD KIT, DISC BRAKE, FRONT | ||||
| 04465-37250 |
XZU650..T3..DCRWD;XZU600,605,645,655..30T..DCRWD;XZC675,XZU630,640,675,685,695..DCRWD;XZU600,605,655..(DM3,DM6,T2,T3,T5)..20T..DCRWD ﾏｰｸ AK NS265 |
1 | ||
| 04465-37250 |
XZU650..T3..DCRWD;XZU600,605,645,655..30T..DCRWD;XZC675,XZU630,640,675,685,695..DCRWD;XZU600,605,655..(DM3,DM6,T2,T3,T5)..20T..DCRWD ﾏｰｸ AK NS265 |
1 | ||
| 04479 - CYLINDER KIT, DISC BRAKE, FRONT | ||||
| 0447B-37021 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
2 | ||
| 0447B-37021 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
2 | ||
| 04945 - SHIM KIT, ANTI SQUEAL, FRONT | ||||
| 04945-37230 |
XZU650..T3..DCRWD;XZU600,605,645,655..30T..DCRWD;XZC675,XZU630,640,675,685,695..DCRWD;XZU600,605,655..(DM3,DM6,T2,T3,T5)..20T..DCRWD |
1 | ||
| 04945-37230 |
XZU650..T3..DCRWD;XZU600,605,645,655..30T..DCRWD;XZC675,XZU630,640,675,685,695..DCRWD;XZU600,605,655..(DM3,DM6,T2,T3,T5)..20T..DCRWD |
1 | ||
| 04947 - FITTING KIT, DISC BRAKE, FRONT | ||||
| 0494A-37050 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
2 | ||
| 0494A-37050 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
2 | ||
| 31478B - CAP, BLEEDER PLUG(FOR FRONT DISC BRAKE) | ||||
| 31478-30010 |
XZC60#,630,645,655,675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
2 | ||
| 31478-30010 |
XZC60#,630,645,655,675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
2 | ||
| 47547B - PLUG, BLEEDER(FOR FRONT DISC BRAKE) | ||||
| 47547-12010 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
2 | ||
| 47547-12010 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
2 | ||
| 47703 - COVER SUB-ASSY, DISC BRAKE DUST, FRONT RH | ||||
| 47703-37043 |
XZC605,645,655,XZU605,645,655..DCRWD |
1 | ||
| 47703-37043 |
XZC605,645,655,XZU605,645,655..DCRWD |
1 | ||
| 47704 - COVER SUB-ASSY, DISC BRAKE DUST, FRONT LH | ||||
| 47704-37043 |
XZC605,645,655,XZU605,645,655..DCRWD |
1 | ||
| 47704-37043 |
XZC605,645,655,XZU605,645,655..DCRWD |
1 | ||
| 47721 - MOUNTING, FRONT DISC BRAKE CYLINDER, RH | ||||
| 47721-37180 |
XZU605,645,655..30T..DCRWD;XZC675,XZU675,685,695..DCRWD;XZU605,655..(DM6,T2,T3,T5)..20T..DCRWD |
1 | ||
| 47721-37180 |
XZU605,645,655..30T..DCRWD;XZC675,XZU675,685,695..DCRWD;XZU605,655..(DM6,T2,T3,T5)..20T..DCRWD |
1 | ||
| 47721A - BOLT(FOR FRONT DISC BRAKE CYLINDER MOUNTING) | ||||
| 90119-12256 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD *12−1.25PX75−30,NO.1 |
4 | ||
| 90119-12256 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD *12−1.25PX75−30,NO.1 |
4 | ||
| 90119-08B87 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD *8−1.25PX59−27,NO.2 |
4 | ||
| 90119-08B87 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD *8−1.25PX59−27,NO.2 |
4 | ||
| 47721A - BOLT(FOR FRONT DISC BRAKE CYLINDER MOUNTING) | ||||
| 90119-12256 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD *12−1.25PX75−30,NO.1 |
4 | ||
| 90119-12256 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD *12−1.25PX75−30,NO.1 |
4 | ||
| 90119-08B87 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD *8−1.25PX59−27,NO.2 |
4 | ||
| 90119-08B87 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD *8−1.25PX59−27,NO.2 |
4 | ||
| 47722 - MOUNTING, FRONT DISC BRAKE CYLINDER, LH | ||||
| 47721-37180 |
XZU605,645,655..30T..DCRWD;XZC675,XZU675,685,695..DCRWD;XZU605,655..(DM6,T2,T3,T5)..20T..DCRWD |
1 | ||
| 47721-37180 |
XZU605,645,655..30T..DCRWD;XZC675,XZU675,685,695..DCRWD;XZU605,655..(DM6,T2,T3,T5)..20T..DCRWD |
1 | ||
| 47730 - CYLINDER ASSY, FRONT DISC BRAKE, RH | ||||
| 47730-37180 |
XZU605,645,655..30T..DCRWD;XZC675,XZU675,685,695..DCRWD;XZU605,655..(DM6,T2,T3,T5)..20T..DCRWD |
1 | ||
| 47730-37180 |
XZU605,645,655..30T..DCRWD;XZC675,XZU675,685,695..DCRWD;XZU605,655..(DM6,T2,T3,T5)..20T..DCRWD |
1 | ||
| 47731 - PISTON, FRONT DISC BRAKE | ||||
| 47731-36020 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
4 | ||
| 47731-36020 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
4 | ||
| 47731-37010 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
4 | ||
| 47731-37010 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
4 | ||
| 47731 - PISTON, FRONT DISC BRAKE | ||||
| 47731-36020 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
4 | ||
| 47731-36020 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
4 | ||
| 47731-37010 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
4 | ||
| 47731-37010 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
4 | ||
| 47750 - CYLINDER ASSY, DISC BRAKE, LH | ||||
| 47750-37180 |
XZU605,645,655..30T..DCRWD;XZC675,XZU675,685,695..DCRWD;XZU605,655..(DM6,T2,T3,T5)..20T..DCRWD |
1 | ||
| 47750-37180 |
XZU605,645,655..30T..DCRWD;XZC675,XZU675,685,695..DCRWD;XZU605,655..(DM6,T2,T3,T5)..20T..DCRWD |
1 | ||
| 47769 - BUSH, CYLINDER SLIDE, NO.1(FOR FRONT DISC BRAKE) | ||||
| 47769-36030 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
4 | ||
| 47769-36030 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
4 | ||
| 47775B - BOOT, BUSH DUST, NO.1 | ||||
| 47775-36050 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
8 | ||
| 47775-36050 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
8 | ||
| 47775B - BOOT, BUSH DUST, NO.1 | ||||
| 47775-36050 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
8 | ||
| 47775-36050 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
8 | ||
| 47775C - BOOT, BUSH DUST, NO.2 | ||||
| 47775-36040 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
8 | ||
| 47775-36040 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
8 | ||
| 47775C - BOOT, BUSH DUST, NO.2 | ||||
| 47775-36040 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
8 | ||
| 47775-36040 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
8 | ||
| 47779 - BUSH, CYLINDER SLIDE, NO.2(FOR FRONT DISC BRAKE) | ||||
| 47779-36010 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
4 | ||
| 47779-36010 |
XZC675,XZU600,605,630,640,645,650,655,675,685,695..DCRWD |
4 | ||
| Common parts | ||||
| 90105-16072 | ||||
| 90105-16073 | ||||
| 91611-B0812 | ||||
