XZU605-TPMMB (2011)
Toyota Dyna/Toyoace
(1107- )T2,T3,T4,T5..CBU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 66418C - BOLT, U, FRONT | ||||
| 90117-12045 |
XZC605,XZU60#..T5..20T..CBU ﾀｲﾔ & ﾃﾞｨｽｸﾎｲｰﾙ−185/85R16,ﾘﾌﾞﾗｸﾞ,長さ=300 |
2 | ||
| 90117-12045 |
XZU655..DCB..CBU;XZC605,XZU605..T5..CBU;XZU605,655..T4..30T..CBU;XZC600,XZU600..T5..5F..CBU;XZC675,XZU645,675..T4..CBU 長さ=300 |
2 | ||
| 66418D - BOLT, U, CENTER | ||||
| 90117-12045 |
XZU605,655..DCB..CBU;XZC605,XZU605..T5..CBU;XZU605,655..T4..30T..CBU;XZC600,XZU600..T5..5F..CBU;XZC675,XZU645,675,685,695..T4..CBU 長さ=300 |
2 | ||
| 66418E - BOLT, U, REAR | ||||
| 90117-12044 |
XZU650..35T..CBU;XZU675..30T..CBU;XZU640..DCRTK..CBU;XZU650..T3..DCRTJ..CBU;XZC600,XZU600,685,695..(T3,T5)..5F..CBU;XZC605,655,XZU605,645,655..(T3,T5)..CBU 長さ=274 |
2 | ||
| 66446A - BRACE, FRAME TO REAR BODY FLOOR | ||||
| 66446-37110 |
XZU695..T3..20T..CBU;XZC605,XZU60#..T5..CBU |
2 | ||
| 66446-37150 |
XZU605..T5..5F..20T..DCRTJ..CBU ﾊﾟﾜｰｹﾞｰﾄ |
2 | ||
| 66446-37150 |
XZU605..T5..5F..20T..DCRTJ..CBU ﾊﾟﾜｰﾘﾌﾄ |
2 | ||
| 66446A - BRACE, FRAME TO REAR BODY FLOOR | ||||
| 66446-37110 |
XZU695..T3..20T..CBU;XZC605,XZU60#..T5..CBU |
2 | ||
| 66446-37150 |
XZU605..T5..5F..20T..DCRTJ..CBU ﾊﾟﾜｰｹﾞｰﾄ |
2 | ||
| 66446-37150 |
XZU605..T5..5F..20T..DCRTJ..CBU ﾊﾟﾜｰﾘﾌﾄ |
2 | ||
| 66451E - PLATE, U BOLT, FRONT | ||||
| 66451-37030 |
XZU650..35T..CBU;XZU655..DCB..CBU;XZU685..SCB..CBU;XZU640..DCRTK..CBU;XZU655..T3..20T..CBU;XZU650..T3..DCRTJ..CBU;XZU605,655..(T3,T4)..30T..CBU;XZC605,655,XZU605..(T3,T5)..CBU;XZC600,XZU600..(T3,T5)..5F..CBU;XZC675,XZU645,675,695..(T3,T4)..CBU |
2 | ||
| 66451-37030 |
XZC605,XZU60#..T5..20T..CBU ﾀｲﾔ & ﾃﾞｨｽｸﾎｲｰﾙ−185/85R16,ﾘﾌﾞﾗｸﾞ |
2 | ||
| 66451F - PLATE, U BOLT, CENTER | ||||
| 66451-37030 |
XZU650..35T..CBU;XZU640..DCRTK..CBU;XZU645,685,695..CBU;XZU605,655..DCB..CBU;XZU650..T3..DCRTJ..CBU;XZU605,655..(T3,T4)..30T..CBU;XZC605,655,XZU605..(T3,T5)..CBU;XZC600,XZU600,655..(T3,T5)..5F..20T..CBU |
2 | ||
| 66451G - PLATE, U BOLT, REAR | ||||
| 66451-37030 |
XZU650..35T..CBU;XZU640..DCRTK..CBU;XZU605,655..DCB..CBU;XZU655..T3..20T..CBU;XZU650..T3..DCRTJ..CBU;XZU605,655..(T3,T4)..30T..CBU;XZC600,XZU600..(T3,T5)..5F..CBU;XZC605,655,XZU605..(T3,T5)..CBU;XZC675,XZU645,675,685,695..(T3,T4)..CBU |
2 | ||
| 66471A - REINFORCEMENT, FRAME U BOLT | ||||
| 66405-37120 |
XZU605..DCB..CBU;XZU605..T4..30T..CBU;XZC605,XZU605..T5..CBU;XZC600,XZU600..T5..5F..CBU 右側,NO.1 |
1 | ||
| 66471-37230 |
XZU605..DCB..CBU;XZU605..T4..30T..CBU;XZC605,XZU605..T5..CBU;XZC600,XZU600..T5..5F..CBU 左側,NO.1 |
1 | ||
| 66471-37220 |
XZU605,655..DCB..CBU;XZU650..T3..DCRTJ..CBU;XZU605,655..(T3,T4)..30T..CBU;XZC605,655,XZU605..(T3,T5)..CBU;XZC600,XZU600,655..(T3,T5)..5F..20T..CBU NO.2 |
2 | ||
| 66471A - REINFORCEMENT, FRAME U BOLT | ||||
| 66405-37120 |
XZU605..DCB..CBU;XZU605..T4..30T..CBU;XZC605,XZU605..T5..CBU;XZC600,XZU600..T5..5F..CBU 右側,NO.1 |
1 | ||
| 66471-37230 |
XZU605..DCB..CBU;XZU605..T4..30T..CBU;XZC605,XZU605..T5..CBU;XZC600,XZU600..T5..5F..CBU 左側,NO.1 |
1 | ||
| 66471-37220 |
XZU605,655..DCB..CBU;XZU650..T3..DCRTJ..CBU;XZU605,655..(T3,T4)..30T..CBU;XZC605,655,XZU605..(T3,T5)..CBU;XZC600,XZU600,655..(T3,T5)..5F..20T..CBU NO.2 |
2 | ||
| Common parts | ||||
| 90119-10087 | ||||
| 94130-01002 | ||||
| 94130-61200 | ||||
(1107- )T2,T3,T4,T5..CBU
ﾚﾝﾀｶｰｼﾖｳ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 66418C - BOLT, U, FRONT | ||||
| 90117-12045 |
XZC605,XZU60#..T5..20T..CBU ﾀｲﾔ & ﾃﾞｨｽｸﾎｲｰﾙ−185/85R16,ﾘﾌﾞﾗｸﾞ,長さ=300 |
2 | ||
| 90117-12045 |
XZU655..DCB..CBU;XZC605,XZU605..T5..CBU;XZU605,655..T4..30T..CBU;XZC600,XZU600..T5..5F..CBU;XZC675,XZU645,675..T4..CBU 長さ=300 |
2 | ||
| 66418D - BOLT, U, CENTER | ||||
| 90117-12045 |
XZU605,655..DCB..CBU;XZC605,XZU605..T5..CBU;XZU605,655..T4..30T..CBU;XZC600,XZU600..T5..5F..CBU;XZC675,XZU645,675,685,695..T4..CBU 長さ=300 |
2 | ||
| 66418E - BOLT, U, REAR | ||||
| 90117-12044 |
XZU650..35T..CBU;XZU675..30T..CBU;XZU640..DCRTK..CBU;XZU650..T3..DCRTJ..CBU;XZC600,XZU600,685,695..(T3,T5)..5F..CBU;XZC605,655,XZU605,645,655..(T3,T5)..CBU 長さ=274 |
2 | ||
| 66446A - BRACE, FRAME TO REAR BODY FLOOR | ||||
| 66446-37110 |
XZU695..T3..20T..CBU;XZC605,XZU60#..T5..CBU |
2 | ||
| 66446-37150 |
XZU605..T5..5F..20T..DCRTJ..CBU ﾊﾟﾜｰｹﾞｰﾄ |
2 | ||
| 66446-37150 |
XZU605..T5..5F..20T..DCRTJ..CBU ﾊﾟﾜｰﾘﾌﾄ |
2 | ||
| 66446A - BRACE, FRAME TO REAR BODY FLOOR | ||||
| 66446-37110 |
XZU695..T3..20T..CBU;XZC605,XZU60#..T5..CBU |
2 | ||
| 66446-37150 |
XZU605..T5..5F..20T..DCRTJ..CBU ﾊﾟﾜｰｹﾞｰﾄ |
2 | ||
| 66446-37150 |
XZU605..T5..5F..20T..DCRTJ..CBU ﾊﾟﾜｰﾘﾌﾄ |
2 | ||
| 66451E - PLATE, U BOLT, FRONT | ||||
| 66451-37030 |
XZU650..35T..CBU;XZU655..DCB..CBU;XZU685..SCB..CBU;XZU640..DCRTK..CBU;XZU655..T3..20T..CBU;XZU650..T3..DCRTJ..CBU;XZU605,655..(T3,T4)..30T..CBU;XZC605,655,XZU605..(T3,T5)..CBU;XZC600,XZU600..(T3,T5)..5F..CBU;XZC675,XZU645,675,695..(T3,T4)..CBU |
2 | ||
| 66451-37030 |
XZC605,XZU60#..T5..20T..CBU ﾀｲﾔ & ﾃﾞｨｽｸﾎｲｰﾙ−185/85R16,ﾘﾌﾞﾗｸﾞ |
2 | ||
| 66451F - PLATE, U BOLT, CENTER | ||||
| 66451-37030 |
XZU650..35T..CBU;XZU640..DCRTK..CBU;XZU645,685,695..CBU;XZU605,655..DCB..CBU;XZU650..T3..DCRTJ..CBU;XZU605,655..(T3,T4)..30T..CBU;XZC605,655,XZU605..(T3,T5)..CBU;XZC600,XZU600,655..(T3,T5)..5F..20T..CBU |
2 | ||
| 66451G - PLATE, U BOLT, REAR | ||||
| 66451-37030 |
XZU650..35T..CBU;XZU640..DCRTK..CBU;XZU605,655..DCB..CBU;XZU655..T3..20T..CBU;XZU650..T3..DCRTJ..CBU;XZU605,655..(T3,T4)..30T..CBU;XZC600,XZU600..(T3,T5)..5F..CBU;XZC605,655,XZU605..(T3,T5)..CBU;XZC675,XZU645,675,685,695..(T3,T4)..CBU |
2 | ||
| 66471A - REINFORCEMENT, FRAME U BOLT | ||||
| 66405-37120 |
XZU605..DCB..CBU;XZU605..T4..30T..CBU;XZC605,XZU605..T5..CBU;XZC600,XZU600..T5..5F..CBU 右側,NO.1 |
1 | ||
| 66471-37230 |
XZU605..DCB..CBU;XZU605..T4..30T..CBU;XZC605,XZU605..T5..CBU;XZC600,XZU600..T5..5F..CBU 左側,NO.1 |
1 | ||
| 66471-37220 |
XZU605,655..DCB..CBU;XZU650..T3..DCRTJ..CBU;XZU605,655..(T3,T4)..30T..CBU;XZC605,655,XZU605..(T3,T5)..CBU;XZC600,XZU600,655..(T3,T5)..5F..20T..CBU NO.2 |
2 | ||
| 66471A - REINFORCEMENT, FRAME U BOLT | ||||
| 66405-37120 |
XZU605..DCB..CBU;XZU605..T4..30T..CBU;XZC605,XZU605..T5..CBU;XZC600,XZU600..T5..5F..CBU 右側,NO.1 |
1 | ||
| 66471-37230 |
XZU605..DCB..CBU;XZU605..T4..30T..CBU;XZC605,XZU605..T5..CBU;XZC600,XZU600..T5..5F..CBU 左側,NO.1 |
1 | ||
| 66471-37220 |
XZU605,655..DCB..CBU;XZU650..T3..DCRTJ..CBU;XZU605,655..(T3,T4)..30T..CBU;XZC605,655,XZU605..(T3,T5)..CBU;XZC600,XZU600,655..(T3,T5)..5F..20T..CBU NO.2 |
2 | ||
| Common parts | ||||
| 90119-10087 | ||||
| 94130-01002 | ||||
| 94130-61200 | ||||
