XZU378-PKMMW3 (2004)
Toyota Dyna/Toyoace
(0406- )XZU368,378,388
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 42419A - SCREW, FRONT AXLE BEARING LOCK NUT | ||||
| 42419-36010 |
XZU368,378,388 |
2 | ||
| 42427B - NUT, FRONT AXLE BEARING LOCK | ||||
| 42427-36040 |
XZU368,378,388 |
2 | ||
| 42428A - PLATE, FRONT AXLE LOCK NUT | ||||
| 42428-36031 |
XZU368,378,388 |
2 | ||
| 43246A - DEFLECTOR, FRONT WHEEL BEARING DUST, NO.1 RH | ||||
| 43247-37010 |
XZU368,378,388 |
1 | ||
| 43246B - DEFLECTOR, FRONT WHEEL BEARING DUST, NO.1 LH | ||||
| 43247-37010 |
XZU368,378,388 |
1 | ||
| 43410S - RING, SNAP (FOR FRONT DRIVE SHAFT RH) | ||||
| 90035-20025 |
XZU368,378,388 厚さ=1.50 |
1 | ||
| 43410U - SHIM (FOR FRONT DRIVE SHAFT SNAP RING RH) | ||||
| 90035-64037 |
XZU368,378,388 厚さ=0.5 |
1 | ||
| 90035-64036 |
XZU368,378,388 厚さ=1.0 |
1 | ||
| 90035-64035 |
XZU368,378,388 厚さ=0.8 |
1 | ||
| 90035-64038 |
XZU368,378,388 厚さ=0.3 |
1 | ||
| 43420D - SHIM (FOR FRONT DRIVE SHAFT SNAP RING LH) | ||||
| 90035-64036 |
XZU368,378,388 厚さ=1.0 |
1 | ||
| 90035-64035 |
XZU368,378,388 厚さ=0.8 |
1 | ||
| 90035-64038 |
XZU368,378,388 厚さ=0.3 |
1 | ||
| 90035-64037 |
XZU368,378,388 厚さ=0.5 |
1 | ||
| 43420E - RING, SNAP (FOR FRONT DRIVE SHAFT LH) | ||||
| 90035-20025 |
XZU368,378,388 厚さ=1.50 |
1 | ||
| 43501C - HUB SUB-ASSY, FRONT AXLE, RH | ||||
| 43501-37150 |
XZU368,378,388 |
1 | ||
| 43501D - BOLT, HUB (FOR FRONT AXLE RH) | ||||
| 90942-02071 |
BZU300,340,RZU30#,340,XZU30#,31#,321,33#,34#,35#,368,378,388 |
1 | ||
| 90942-02071 |
BU30#,346;BZU300,340,RZU30#,340,XZU300,301,302,306,307,31#,32#,33#,340,341,342,346,347,351,352,362,37#,382..20T,295T,30T |
5 | ||
| 43501E - BEARING (FOR FRONT AXLE HUB RH) | ||||
| 90033-64017 |
XZU368,378,388 |
1 | ||
| 43501F - SEAL, OIL (FOR FRONT AXLE HUB RH) | ||||
| 90311-77001 |
XZU368,378,388 |
1 | ||
| 43501M - BEARING (FOR FRONT AXLE HUB INNER RH) | ||||
| 90366-60015 |
XZU368,378,388 |
1 | ||
| 43501N - BEARING (FOR FRONT AXLE HUB OUTER RH) | ||||
| 90366-55042 |
XZU368,378,388 |
1 | ||
| 43502C - HUB SUB-ASSY, FRONT AXLE, LH | ||||
| 43502-37150 |
XZU368,378,388 |
1 | ||
| 43502D - BOLT, HUB (FOR FRONT AXLE LH) | ||||
| 90942-02072 |
BU30#,346;BZU300,340,RZU30#,340,XZU300,301,302,306,307,31#,32#,33#,340,341,342,346,347,351,352,362,37#,382..20T,295T,30T |
5 | ||
| 90942-02072 |
BZU300,340,RZU30#,340,XZU30#,31#,321,33#,34#,35#,368,378,388 |
1 | ||
| 43502E - BEARING (FOR FRONT AXLE HUB LH) | ||||
| 90033-64017 |
XZU368,378,388 |
1 | ||
| 43502F - SEAL, OIL (FOR FRONT AXLE HUB LH) | ||||
| 90311-77001 |
XZU368,378,388 |
1 | ||
| 43502M - BEARING (FOR FRONT AXLE HUB INNER LH) | ||||
| 90366-60015 |
XZU368,378,388 |
1 | ||
| 43502N - BEARING (FOR FRONT AXLE HUB OUTER LH) | ||||
| 90366-55042 |
XZU368,378,388 |
1 | ||
| 43508B - BODY SUB-ASSY, FREE WHEEL HUB, RH | ||||
| 43508-37020 |
XZU368,378,388 |
1 | ||
| 43508C - BODY SUB-ASSY, FREE WHEEL HUB, LH | ||||
| 43508-37020 |
XZU368,378,388 |
1 | ||
| 43509A - COVER SUB-ASSY, FREE WHEEL HUB, RH | ||||
| 43509-39015 |
XZU368,378,388 |
1 | ||
| 43509B - COVER SUB-ASSY, FREE WHEEL HUB, LH | ||||
| 43509-39015 |
XZU368,378,388 |
1 | ||
| 43512 - DISC, FRONT | ||||
| 43512-37090 |
XZU368,378,388;XZU341..T3..20T;BZU300,XZU301,304..T4..30T;BZU340,RZU300,XZU31#,331,334,341,344..30T;BZU300,XZU30#,321,336,338,346,348,351..DM2,DM3,DM6,DM7,T1,T2,T3,T5 |
2 | ||
| 43515 - ROTOR, SKID CONTROL, FRONT | ||||
| 43515-37040 |
XZU368,378,388 |
2 | ||
| 43524B - SPACER, FRONT WHEEL INNER BEARING, RH | ||||
| 43524-37010 |
XZU368,378,388 |
1 | ||
| 43524C - SPACER, FRONT WHEEL INNER BEARING, LH | ||||
| 43524-37010 |
XZU368,378,388 |
1 | ||
| 43531A - GASKET, FREE WHEEL HUB, RH | ||||
| 43531-37010 |
XZU368,378,388 |
1 | ||
| 43531B - GASKET, FREE WHEEL HUB, LH | ||||
| 43531-37010 |
XZU368,378,388 |
1 | ||
| Common parts | ||||
| 90105-10493 | ||||
| 90105-14101 | ||||
| 90119-06595 | ||||
