XZU334-PKTQL4 (2004)
Toyota Dyna/Toyoace
(0406- )6FC
A860
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 32904 - TUBE SUB-ASSY, OIL COOLER INLET, NO.1 | ||||
| 32904-37151 |
XZU304,334..6FC |
1 | ||
| 32904-37152 |
XZU304,334..6FC |
1 | ||
| 32904-37153 |
XZU304,334..6FC |
1 | ||
| 32905 - TUBE SUB-ASSY, OIL COOLER OUTLET, NO.1 | ||||
| 32905-37151 |
XZU304,334..6FC |
1 | ||
| 32905-37152 |
XZU304,334..6FC |
1 | ||
| 32921C - UNION(FOR OIL COOLER TUBE) | ||||
| 90407-20009 |
XZU301,304,306,331,334,336,341,346,351..6FC ｱｳﾄﾚｯﾄ |
1 | ||
| 90407-20010 |
XZU301,304,306,331,334,336,341,346,351..6FC ｲﾝﾚｯﾄ |
1 | ||
| 32921C - UNION(FOR OIL COOLER TUBE) | ||||
| 90407-20009 |
XZU301,304,306,331,334,336,341,346,351..6FC ｱｳﾄﾚｯﾄ |
1 | ||
| 90407-20010 |
XZU301,304,306,331,334,336,341,346,351..6FC ｲﾝﾚｯﾄ |
1 | ||
| 32921G - RING, O(FOR OIL COOLER TUBE UNION) | ||||
| 90301-11006 |
RZU301,XZU301,304,306,308,33#,341,346,348,351..ATM |
2 | ||
| 32921G - RING, O(FOR OIL COOLER TUBE UNION) | ||||
| 90301-11006 |
RZU301,XZU301,304,306,308,33#,341,346,348,351..ATM |
2 | ||
| 32923A - CLAMP, AUTOMATIC TRANSMISSION OIL COOLER TUBE | ||||
| 32929-25020 |
XZU301,304,306,308,33#,341,346,348,351..ATM..DSL |
1 | ||
| 32923B - CLAMP, AUTOMATIC TRANSMISSION OIL COOLER TUBE, NO.1 | ||||
| 32923-37011 |
XZU301,304,306,331,334,336,341,346,351..6FC |
1 | ||
| 32924 - CLAMP, OIL COOLER TUBE, NO.2 | ||||
| 32924-37010 |
XZU301,304,306,308,33#,341,346,348,351..ATM |
1 | ||
| 32924A - CLAMP(FOR OIL COOLER TUBE, NO.2) | ||||
| 90462-12076 |
XZU301,304,306,308,33#,341,346,348,351..ATM..DSL |
3 | ||
| 90462-12076 |
RZU301,XZU304,334..ATM..(DSLL,LPG) |
4 | ||
| 32924A - CLAMP(FOR OIL COOLER TUBE, NO.2) | ||||
| 90462-12076 |
XZU301,304,306,308,33#,341,346,348,351..ATM..DSL |
3 | ||
| 90462-12076 |
RZU301,XZU304,334..ATM..(DSLL,LPG) |
4 | ||
| 32924A - CLAMP(FOR OIL COOLER TUBE, NO.2) | ||||
| 90462-12076 |
XZU301,304,306,308,33#,341,346,348,351..ATM..DSL |
3 | ||
| 90462-12076 |
RZU301,XZU304,334..ATM..(DSLL,LPG) |
4 | ||
| 32924A - CLAMP(FOR OIL COOLER TUBE, NO.2) | ||||
| 90462-12076 |
XZU301,304,306,308,33#,341,346,348,351..ATM..DSL |
3 | ||
| 90462-12076 |
RZU301,XZU304,334..ATM..(DSLL,LPG) |
4 | ||
| 32925A - CLAMP, FLEXIBLE HOSE, NO.2 | ||||
| 32929-25020 |
XZU301,304,306,308,33#,341,346,348,351..ATM |
1 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-60010 |
XZU301,304,306,308,33#,341,346,348,351..ATM 長さ=45,内径=12 |
10 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-60010 |
XZU301,304,306,308,33#,341,346,348,351..ATM 長さ=45,内径=12 |
10 | ||
| 32928 - CLAMP, FLEXIBLE HOSE, NO.1 | ||||
| 32928-37041 |
XZU301,304,306,331,334,336,341,346,351..6FC |
1 | ||
| 32928-37040 |
XZU301,304,306,331,334,336,341,346,351..6FC |
1 | ||
| 32941 - HOSE, OIL COOLER INLET, NO.1 | ||||
| 32941-37120 |
XZU304,334..6FC |
1 | ||
| 32942 - HOSE, OIL COOLER OUTLET, NO.1 | ||||
| 32942-37090 |
XZU304,334..6FC |
1 | ||
| Common parts | ||||
| 90467-16022 | ||||
| 91611-B0616 | ||||
| 91611-B0816 | ||||
| 91612-B1020 | ||||
