WU75D-MDTJ3 (1988)
Toyota Dyna/Toyoace
(8808- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16331 - OUTLET, WATER | ||||
| 16331-78010 |
1W..WU75,85,9# |
1 | ||
| 16331A - THERMOSTAT | ||||
| 90916-03068 |
1W..WU75,85,9# *WAX 88−100 |
1 | ||
| 16361 - FAN | ||||
| 16361-78010 |
1W..WU75,85,9# |
1 | ||
| 16381 - BAR, FAN BELT ADJUSTING | ||||
| 16381-78020 |
1W..WU75,85,9# |
1 | ||
| 16400 - RADIATOR ASSY | ||||
| 16400-58143 |
1W..WU75,9#..DM1,T3 |
1 | ||
| 16400-58111 |
1W..WU75,85,9#..DM1,T3 |
1 | ||
| 16400B - PLUG, RADIATOR DRAIN COCK | ||||
| 16417-24051 |
1W..WU75,85,9# |
1 | ||
| 16400F - PACKING(FOR RADIATOR DRAIN COCK) | ||||
| 16418-24051 |
1W..WU75,85,9# |
1 | ||
| 16401 - CAP SUB-ASSY, RADIATOR | ||||
| 16401-71010 |
1W..WU75,85,9# |
1 | ||
| 16470 - TANK ASSY, RADIATOR RESERVE | ||||
| 16470-58010 |
1W..WU90;1W..WU75,85,95..DM1,T3 ｵ-ﾅ ｶｽﾀﾑ ｼﾖｳ |
1 | ||
| 16470-58020 |
1W..WU75,85,9# |
1 | ||
| 16470 - TANK ASSY, RADIATOR RESERVE | ||||
| 16470-58010 |
1W..WU90;1W..WU75,85,95..DM1,T3 ｵ-ﾅ ｶｽﾀﾑ ｼﾖｳ |
1 | ||
| 16470-58020 |
1W..WU75,85,9# |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 90445-12143 |
1W..WU75,85,9# 長さ=620 |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 90445-12143 |
1W..WU75,85,9# 長さ=620 |
1 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
1W..WU75,85,9# |
2 | ||
| 16471 - CAP SUB-ASSY, RESERVE TANK | ||||
| 16405-56070 |
1W..WU75,85,9# |
1 | ||
| 16471 - CAP SUB-ASSY, RESERVE TANK | ||||
| 16405-56070 |
1W..WU75,85,9# |
1 | ||
| 16472 - HOSE, BREATHER | ||||
| 16472-58010 |
1W..WU75,85,9# |
1 | ||
| 16472 - HOSE, BREATHER | ||||
| 16472-58010 |
1W..WU75,85,9# |
1 | ||
| 16571 - HOSE, RADIATOR, INLET | ||||
| 16571-78020 |
1W..WU75,85,9# |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-42001 |
1W..WU75,85,9# |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-42001 |
1W..WU75,85,9# |
1 | ||
| 16572 - HOSE, RADIATOR, OUTLET | ||||
| 16572-78011 |
1W..WU75,85,9# |
1 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 96111-10510 |
1W..WU75,85,9# |
2 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 96111-10510 |
1W..WU75,85,9# |
2 | ||
| 16593 - GUIDE, RADIATOR AIR, NO.1 | ||||
| 16593-58050 |
1W..WU75,9# |
1 | ||
| 16593-58050 |
1W..WU75,85,9# |
1 | ||
| 16593-58050 |
1W..WU75,85,9# |
1 | ||
| 16701 - SHROUD SUB-ASSY, FAN | ||||
| 16701-58040 |
1W..WU75,85,9#..DM1,T3 |
1 | ||
| Common parts | ||||
| 90119-10180 | ||||
| 90179-06070 | ||||
| 90179-08040 | ||||
| 90179-08061 | ||||
| 90179-08126 | ||||
| 90179-08143 | ||||
| 90339-16001 | ||||
| 90412-08004 | ||||
| 90462-08035 | ||||
| 90462-08043 | ||||
| 90463-15002 | ||||
| 90464-00234 | ||||
| 90467-05018 | ||||
| 90467-11085 | ||||
| 90467-13001 | ||||
| 90929-01186 | ||||
| 91611-60825 | ||||
| 91651-40814 | ||||
| 91651-60616 | ||||
| 91651-60820 | ||||
| 91656-60820 | ||||
| 91661-40820 | ||||
| 93383-16016 | ||||
| 99555-10220 | ||||
| Linked diagrams | ||||
| 1605 | ||||
| 8716 | ||||
(8808- )1W
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16331 - OUTLET, WATER | ||||
| 16331-78010 |
1W..WU75,85,9# |
1 | ||
| 16331A - THERMOSTAT | ||||
| 90916-03068 |
1W..WU75,85,9# *WAX 88−100 |
1 | ||
| 16333 - HOUSING, WATER OUTLET | ||||
| 16303-78010 |
1W..WU75,85,9# |
1 | ||
| 16333B - RING, O(FOR WATER OUTLET HOUSING) | ||||
| 90301-31001 |
1W..WU75,85,9# |
2 | ||
| 16333B - RING, O(FOR WATER OUTLET HOUSING) | ||||
| 90301-31001 |
1W..WU75,85,9# |
2 | ||
| 16346 - GASKET, THERMOSTAT | ||||
| 16346-78010 |
1W..WU75,85,9# |
1 | ||
| 16361 - FAN | ||||
| 16361-78010 |
1W..WU75,85,9# |
1 | ||
| 16381 - BAR, FAN BELT ADJUSTING | ||||
| 16381-78020 |
1W..WU75,85,9# |
1 | ||
| 16400 - RADIATOR ASSY | ||||
| 16400-58143 |
1W..WU75,9#..DM1,T3 |
1 | ||
| 16400-58111 |
1W..WU75,85,9#..DM1,T3 |
1 | ||
| 16400B - PLUG, RADIATOR DRAIN COCK | ||||
| 16417-24051 |
1W..WU75,85,9# |
1 | ||
| 16400F - PACKING(FOR RADIATOR DRAIN COCK) | ||||
| 16418-24051 |
1W..WU75,85,9# |
1 | ||
| 16401 - CAP SUB-ASSY, RADIATOR | ||||
| 16401-71010 |
1W..WU75,85,9# |
1 | ||
| 16470 - TANK ASSY, RADIATOR RESERVE | ||||
| 16470-58010 |
1W..WU90;1W..WU75,85,95..DM1,T3 ｵ-ﾅ ｶｽﾀﾑ ｼﾖｳ |
1 | ||
| 16470-58020 |
1W..WU75,85,9# |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 90445-12143 |
1W..WU75,85,9# 長さ=620 |
1 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
1W..WU75,85,9# |
2 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
1W..WU75,85,9# |
2 | ||
| 16471 - CAP SUB-ASSY, RESERVE TANK | ||||
| 16405-56070 |
1W..WU75,85,9# |
1 | ||
| 16472 - HOSE, BREATHER | ||||
| 16472-58010 |
1W..WU75,85,9# |
1 | ||
| 16571 - HOSE, RADIATOR, INLET | ||||
| 16571-78020 |
1W..WU75,85,9# |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-42001 |
1W..WU75,85,9# |
1 | ||
| 16572 - HOSE, RADIATOR, OUTLET | ||||
| 16572-78011 |
1W..WU75,85,9# |
1 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 96111-10510 |
1W..WU75,85,9# |
2 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 96111-10510 |
1W..WU75,85,9# |
2 | ||
| 16593 - GUIDE, RADIATOR AIR, NO.1 | ||||
| 16593-58050 |
1W..WU75,9# |
1 | ||
| 16593-58050 |
1W..WU75,85,9# |
1 | ||
| 16593-58050 |
1W..WU75,85,9# |
1 | ||
| 16593A - GUIDE, RADIATOR AIR, NO.1 RH | ||||
| 16593-58060 |
1W..WU75,85,9# |
1 | ||
| 16594 - GUIDE, RADIATOR AIR, NO.2 | ||||
| 16594-58030 |
1W..WU75,85,9# |
1 | ||
| 16595A - GUIDE, RADIATOR AIR, NO.1 LH | ||||
| 16595-58040 |
1W..WU75,85,9# |
1 | ||
| 16701 - SHROUD SUB-ASSY, FAN | ||||
| 16701-58040 |
1W..WU75,85,9#..DM1,T3 |
1 | ||
| Common parts | ||||
| 90119-08390 | ||||
| 90119-08406 | ||||
| 90119-10294 | ||||
| 90119-10356 | ||||
| 90119-12071 | ||||
| 90460-55008 | ||||
| 90461-10383 | ||||
| 90467-0501801 | ||||
| 91611-40612 | ||||
| 91651-40814 | ||||
| 91651-40820 | ||||
| 94110-70600 | ||||
| 94511-00600 | ||||
| Linked diagrams | ||||
| 1605 | ||||
| 8401 | ||||
