LY280-TGMFS3 (2001)
Toyota Dyna/Toyoace
(0107- )KDY27#,28#,LY270,280..ST
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 42323B - WASHER, CONE (FOR FRONT AXLE SHAFT RH) | ||||
| 42323-60010 |
LY270,280,290..DSL |
6 | ||
| 42323-60010 |
KDY270,280,290,RZY281 |
6 | ||
| 42323C - WASHER, CONE (FOR FRONT AXLE SHAFT LH) | ||||
| 42323-60010 |
KDY270,280,290,RZY281 |
6 | ||
| 42323-60010 |
LY270,280,290..DSL |
6 | ||
| 43410T - SPACER (FOR FRONT DRIVE SHAFT RH) | ||||
| 90560-27005 |
LY270,280,290..DSL 厚さ=2.0 |
1 | ||
| 90560-27005 |
KDY270,280,290,RZY281 厚さ=2.0 |
1 | ||
| 43420F - SPACER (FOR FRONT DRIVE SHAFT LH) | ||||
| 90560-27005 |
LY270,280,290..DSL 厚さ=2.0 |
1 | ||
| 90560-27005 |
KDY270,280,290,RZY281 厚さ=2.0 |
1 | ||
| 43421E - FLANGE, FRONT AXLE OUTER SHAFT, RH | ||||
| 43421-26010 |
KDY270,280,290,RZY281 |
1 | ||
| 43421-26010 |
LY270,280,290..DSL |
1 | ||
| 43421F - FLANGE, FRONT AXLE OUTER SHAFT, LH | ||||
| 43421-26010 |
LY270,280,290..DSL |
1 | ||
| 43421-26010 |
KDY270,280,290,RZY281 |
1 | ||
| 43421G - PIN, STRAIGHT (FOR FRONT AXLE OUTER SHAFT FLANGE RH) | ||||
| 90250-07057 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
2 | ||
| 43421H - PIN, STRAIGHT (FOR FRONT AXLE OUTER SHAFT FLANGE LH) | ||||
| 90250-07057 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
2 | ||
| 43421J - BOLT, STUD (FOR FRONT AXLE OUTER SHAFT FLANGE RH) | ||||
| 90116-08325 |
LY270,280,290..DSL |
6 | ||
| 90116-08325 |
KDY270,280,290,RZY281 |
6 | ||
| 43421K - BOLT, STUD (FOR FRONT AXLE OUTER SHAFT FLANGE LH) | ||||
| 90116-08325 |
LY270,280,290..DSL |
6 | ||
| 90116-08325 |
KDY270,280,290,RZY281 |
6 | ||
| 43422B - GASKET, FRONT AXLE OUTER SHAFT FLANGE, RH | ||||
| 43422-60010 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 43422C - GASKET, FRONT AXLE OUTER SHAFT FLANGE, LH | ||||
| 43422-60010 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 43423 - CAP, FRONT AXLE OUTER SHAFT FLANGE | ||||
| 43423-35010 |
KDY270,280,290,RZY281 |
2 | ||
| 43423-35010 |
LY270,280,290..DSL |
2 | ||
| 43501C - HUB SUB-ASSY, FRONT AXLE, RH | ||||
| 43511-39015 |
LY220,230,270,280,RZY220,230..T2,T3,TW1,TW2,TW3 |
1 | ||
| 43503-29025 |
KDY22#,23#,27#,28#,LY220,230,270,280,RZY220,230,TRY220,230..T2,T3,TW1,TW2,TW3 ｱﾘ(ABS) |
1 | ||
| 43501D - BOLT, HUB (FOR FRONT AXLE RH) | ||||
| 90942-02049 |
KDY22#,23#,27#,28#,LY220,230,270,280,RZY220,230,TRY220,230..T2,T3,TW1,TW2,TW3 |
6 | ||
| 43501F - SEAL, OIL (FOR FRONT AXLE HUB RH) | ||||
| 90311-66003 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 43501L - WASHER, CLAW (FOR FRONT AXLE HUB RH) | ||||
| 90214-42030 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 43502C - HUB SUB-ASSY, FRONT AXLE, LH | ||||
| 43511-39015 |
LY220,230,270,280,RZY220,230..T2,T3,TW1,TW2,TW3 |
1 | ||
| 43503-29025 |
KDY22#,23#,27#,28#,LY220,230,270,280,RZY220,230,TRY220,230..T2,T3,TW1,TW2,TW3 ｱﾘ(ABS) |
1 | ||
| 43502D - BOLT, HUB (FOR FRONT AXLE LH) | ||||
| 90942-02049 |
KDY22#,23#,27#,28#,LY220,230,270,280,RZY220,230,TRY220,230..T2,T3,TW1,TW2,TW3 |
6 | ||
| 43502F - SEAL, OIL (FOR FRONT AXLE HUB LH) | ||||
| 90311-66003 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 43502L - WASHER, CLAW (FOR FRONT AXLE HUB LH) | ||||
| 90214-42030 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 43510B - BEARING, TAPERED ROLLER (FOR FRONT AXLE INNER BEARING) | ||||
| 90368-49084 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 KOYO |
2 | ||
| 90080-36064 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 TIMKEN |
2 | ||
| 43510C - BEARING, TAPERED ROLLER (FOR FRONT AXLE OUTER BEARING) | ||||
| 90080-36067 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 TIMKEN |
2 | ||
| 90368-45087 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 KOYO |
2 | ||
| 43512 - DISC, FRONT | ||||
| 43512-25060 |
KDY220,230,240,270,280,290,LY220,230,240,270,280,290,RZY220,23#,281 |
2 | ||
| 43521C - NUT, FRONT WHEEL ADJUSTING, RH | ||||
| 43521-60011 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
2 | ||
| 43521C - NUT, FRONT WHEEL ADJUSTING, RH | ||||
| 43521-60011 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
2 | ||
| 43521D - NUT, FRONT WHEEL ADJUSTING, LH | ||||
| 43521-60011 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
2 | ||
| 43521D - NUT, FRONT WHEEL ADJUSTING, LH | ||||
| 43521-60011 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
2 | ||
| 43523A - WASHER, FRONT WHEEL ADJUSTING LOCK, RH | ||||
| 90215-42025 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 43523B - WASHER, FRONT WHEEL ADJUSTING LOCK, LH | ||||
| 90215-42025 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| Common parts | ||||
| 90119-08466 | ||||
| 90119-10396 | ||||
| 90201-08042 | ||||
| 90520-27023 | ||||
| 94130-00802 | ||||
