LY280-PQMES (2001)
Toyota Dyna/Toyoace
(0107- )5L..MTM
12V 2.2KW
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 28011 - CLUTCH SUB-ASSY, STARTER | ||||
| 28011-54010 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28011-54450 |
5L..LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28100 - STARTER ASSY | ||||
| 28100-54450 |
5L..LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28100-54430 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28100 - STARTER ASSY | ||||
| 28100-54450 |
5L..LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28100-54430 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28120 - YOKE ASSY, STARTER | ||||
| 28120-56081 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28120-64040 |
1KDFTV..KDY221..T3..TS..MTM;1KDFTV..KDY231..TW2..TB..MTM;1KDFTV..KDY221..(T2,T4,TW1)..MTM;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..MTM;1KDFTV,5L..KDY241,271,281,LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28140 - HOLDER ASSY, STARTER BRUSH | ||||
| 28140-77090 |
1KDFTV..KDY221..T3..TS;1KDFTV..KDY231..TW2..TB;1KDFTV..KDY231..ST..IV6;1KDFTV..KDY221..T2,T4,TW1;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..(CBU,IV3);1KDFTV,2KDFTV,5L..KDY220,230,24#,27#,28#,290,LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28140-64040 |
1KDFTV..KDY221..T3..TS..MTM;1KDFTV..KDY231..TW2..TB..MTM;1KDFTV..KDY221..(T2,T4,TW1)..MTM;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..MTM;1KDFTV,5L..KDY241,271,281,LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28150 - SWITCH ASSY, MAGNET STARTER | ||||
| 28150-54320 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28150-54330 |
5L..LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28160 - ARMATURE ASSY, STARTER | ||||
| 28160-54160 |
1KDFTV..KDY221..T3..TS;1KDFTV..KDY231..TW2..TB;1KDFTV..KDY231..ST..IV6;1KDFTV..KDY221..T2,T4,TW1;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..(CBU,IV3);1KDFTV,2KDFTV,5L..KDY220,230,24#,27#,28#,290,LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28160-64041 |
1KDFTV..KDY221..T3..TS..MTM;1KDFTV..KDY231..TW2..TB..MTM;1KDFTV..KDY221..(T2,T4,TW1)..MTM;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..MTM;1KDFTV,5L..KDY241,271,281,LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| Common parts | ||||
| 90179-08204 | ||||
| 91619-61265 | ||||
| 94130-61200 | ||||
(0107- )5L
12V 2.7KW
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 28011 - CLUTCH SUB-ASSY, STARTER | ||||
| 28011-54010 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28011-54450 |
5L..LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28100 - STARTER ASSY | ||||
| 28100-54450 |
5L..LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28100-54430 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28100 - STARTER ASSY | ||||
| 28100-54450 |
5L..LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28100-54430 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28120 - YOKE ASSY, STARTER | ||||
| 28120-56081 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28120-64040 |
1KDFTV..KDY221..T3..TS..MTM;1KDFTV..KDY231..TW2..TB..MTM;1KDFTV..KDY221..(T2,T4,TW1)..MTM;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..MTM;1KDFTV,5L..KDY241,271,281,LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28140 - HOLDER ASSY, STARTER BRUSH | ||||
| 28140-77090 |
1KDFTV..KDY221..T3..TS;1KDFTV..KDY231..TW2..TB;1KDFTV..KDY231..ST..IV6;1KDFTV..KDY221..T2,T4,TW1;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..(CBU,IV3);1KDFTV,2KDFTV,5L..KDY220,230,24#,27#,28#,290,LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28140-64040 |
1KDFTV..KDY221..T3..TS..MTM;1KDFTV..KDY231..TW2..TB..MTM;1KDFTV..KDY221..(T2,T4,TW1)..MTM;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..MTM;1KDFTV,5L..KDY241,271,281,LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28150 - SWITCH ASSY, MAGNET STARTER | ||||
| 28150-54320 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28150-54330 |
5L..LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28160 - ARMATURE ASSY, STARTER | ||||
| 28160-54160 |
1KDFTV..KDY221..T3..TS;1KDFTV..KDY231..TW2..TB;1KDFTV..KDY231..ST..IV6;1KDFTV..KDY221..T2,T4,TW1;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..(CBU,IV3);1KDFTV,2KDFTV,5L..KDY220,230,24#,27#,28#,290,LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28160-64041 |
1KDFTV..KDY221..T3..TS..MTM;1KDFTV..KDY231..TW2..TB..MTM;1KDFTV..KDY221..(T2,T4,TW1)..MTM;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..MTM;1KDFTV,5L..KDY241,271,281,LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28191 - STAY, STARTER | ||||
| 28191-54010 |
5L..LY220..15T,1T;5L..LY220..125T..ST;5L..LY230..125T..WT;5L..LY240,270,280,290;5L..LY230..(T2,T3,TW3)..TS;5L..LY230..TB..(12T,15T,175T) |
1 | ||
| Common parts | ||||
| 90179-08068 | ||||
| 90179-10195 | ||||
| 91619-61265 | ||||
| 94130-61200 | ||||
(0107- )5L,1RZE,3RZFPE,1TR#..LY230,280,RZY220,23#,281,TRY220,23#,281
12V 1.4KW
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 28011 - CLUTCH SUB-ASSY, STARTER | ||||
| 28011-54010 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28011-54450 |
5L..LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28100 - STARTER ASSY | ||||
| 28100-54450 |
5L..LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28100-54430 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28100 - STARTER ASSY | ||||
| 28100-54450 |
5L..LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28100-54430 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28120 - YOKE ASSY, STARTER | ||||
| 28120-56081 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28120-64040 |
1KDFTV..KDY221..T3..TS..MTM;1KDFTV..KDY231..TW2..TB..MTM;1KDFTV..KDY221..(T2,T4,TW1)..MTM;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..MTM;1KDFTV,5L..KDY241,271,281,LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28140 - HOLDER ASSY, STARTER BRUSH | ||||
| 28140-77090 |
1KDFTV..KDY221..T3..TS;1KDFTV..KDY231..TW2..TB;1KDFTV..KDY231..ST..IV6;1KDFTV..KDY221..T2,T4,TW1;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..(CBU,IV3);1KDFTV,2KDFTV,5L..KDY220,230,24#,27#,28#,290,LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28140-64040 |
1KDFTV..KDY221..T3..TS..MTM;1KDFTV..KDY231..TW2..TB..MTM;1KDFTV..KDY221..(T2,T4,TW1)..MTM;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..MTM;1KDFTV,5L..KDY241,271,281,LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28150 - SWITCH ASSY, MAGNET STARTER | ||||
| 28150-54320 |
5L..LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28150-54330 |
5L..LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| 28160 - ARMATURE ASSY, STARTER | ||||
| 28160-54160 |
1KDFTV..KDY221..T3..TS;1KDFTV..KDY231..TW2..TB;1KDFTV..KDY231..ST..IV6;1KDFTV..KDY221..T2,T4,TW1;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..(CBU,IV3);1KDFTV,2KDFTV,5L..KDY220,230,24#,27#,28#,290,LY220,230,240,270,280,290 12V 2.7KW |
1 | ||
| 28160-64041 |
1KDFTV..KDY221..T3..TS..MTM;1KDFTV..KDY231..TW2..TB..MTM;1KDFTV..KDY221..(T2,T4,TW1)..MTM;1KDFTV..KDY231..(T2,T3,T4,TW3,TW4)..MTM;1KDFTV,5L..KDY241,271,281,LY220,230,240,270,280,290..MTM 12V 2.2KW |
1 | ||
| Common parts | ||||
| 90179-08204 | ||||
| 91612-61055 | ||||
