LY220-TQMGS (2001)
Toyota Dyna/Toyoace
ILLUST NO. 1 OF 2(0107- )KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,2
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 41101 - CARRIER SUB-ASSY, DIFFERENTIAL, REAR | ||||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101 - CARRIER SUB-ASSY, DIFFERENTIAL, REAR | ||||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41110 - CARRIER ASSY, DIFFERENTIAL, REAR | ||||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41114 - BOLT, REAR DIFFERENTIAL BEARING CAP | ||||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41114 - BOLT, REAR DIFFERENTIAL BEARING CAP | ||||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41115 - RING, DIFFERENTIAL OIL STORAGE | ||||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115 - RING, DIFFERENTIAL OIL STORAGE | ||||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201 - FINAL GEAR KIT, DIFFERENTIAL, REAR | ||||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201A - BEARING (FOR REAR DRIVE PINION REAR) | ||||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201B - BEARING (FOR REAR DRIVE PINION FRONT) | ||||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201C - SEAL, OIL (FOR REAR DIFFERENTIAL CARRIER) | ||||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201D - WASHER, PLATE (FOR REAR DIFFERENTIAL DRIVE PINION) | ||||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 41201E - SHIM (FOR REAR DIFF DRIVE PINION SPACER FRONT ADJUST) | ||||
| 90564-35019 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=1.80 |
1 | ||
| 90564-35020 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=1.82 |
1 | ||
| 90564-35025 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=2.00 |
1 | ||
| 90564-35026 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=2.10 |
1 | ||
| 90564-35022 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=1.86 |
1 | ||
| 90564-35024 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=1.90 |
1 | ||
| 90564-35029 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=2.40 |
1 | ||
| 90564-35023 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=1.88 |
1 | ||
| 90564-35021 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=1.84 |
1 | ||
| 90564-35035 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=3.00 |
1 | ||
| 90564-35030 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=2.50 |
1 | ||
| 90564-35037 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=1.83 |
1 | ||
| 90564-35033 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=2.80 |
1 | ||
| 90564-35038 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=1.85 |
1 | ||
| 90564-35039 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=1.87 |
1 | ||
| 90564-35028 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=2.30 |
1 | ||
| 90564-35031 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=2.60 |
1 | ||
| 90564-35027 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=2.20 |
1 | ||
| 90564-35036 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=1.81 |
1 | ||
| 90564-35040 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=1.89 |
1 | ||
| 90564-35032 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=2.70 |
1 | ||
| 90564-35034 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL 厚さ=2.90 |
1 | ||
| 41204 - FLANGE SUB-ASSY, REAR DRIVE PINION COMPANION, REAR | ||||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204A - WASHER, PLATE (FOR REAR DRIVE PINION) | ||||
| 90201-23002 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL |
1 | ||
| 41204B - NUT (FOR REAR DRIVE PINION) | ||||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 41214 - SLINGER, REAR DIFFERENTIAL DRIVE PINION OIL | ||||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41222 - PLATE, REAR DIFFERENTIAL RING GEAR SET BOLT LOCK | ||||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222A - BOLT (FOR REAR DIFFERENTIAL RING GEAR SET) | ||||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 41231 - SPACER, REAR DIFFERENTIAL DRIVE PINION BEARING | ||||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252 - DEFLECTOR, DUST (FOR REAR DIFFERENTIAL) | ||||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41301 - CASE SUB-ASSY, REAR DIFFERENTIAL | ||||
| 41301-36030 |
LY220,230,240,280,290..(T4,TW4,VAN)..DSL |
1 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41302A - BOLT(FOR REAR DIFFERENTIAL CASE) | ||||
| 90105-12087 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 41315 - NUT, REAR DIFFERENTIAL BEARING ADJUSTING | ||||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315 - NUT, REAR DIFFERENTIAL BEARING ADJUSTING | ||||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41316 - LOCK, REAR DIFFERENTIAL BEARING ADJUSTING NUT | ||||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316 - LOCK, REAR DIFFERENTIAL BEARING ADJUSTING NUT | ||||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41371 - SPIDER, REAR DIFFERENTIAL | ||||
| 41371-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| Common parts | ||||
| 91611-60814 | ||||
ILLUST NO. 1 OF 2(0107- )LY220,230..T2,TW2..MTM..WT ; (0107-)KDY23#..T2,TW2,TW3..TS..MTM ; (0
ﾃﾞｨﾌｧﾚﾝｼｬﾙ4ﾋﾟﾆｵﾝ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 41101 - CARRIER SUB-ASSY, DIFFERENTIAL, REAR | ||||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101 - CARRIER SUB-ASSY, DIFFERENTIAL, REAR | ||||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41110 - CARRIER ASSY, DIFFERENTIAL, REAR | ||||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41114 - BOLT, REAR DIFFERENTIAL BEARING CAP | ||||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41114 - BOLT, REAR DIFFERENTIAL BEARING CAP | ||||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41115 - RING, DIFFERENTIAL OIL STORAGE | ||||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115 - RING, DIFFERENTIAL OIL STORAGE | ||||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201 - FINAL GEAR KIT, DIFFERENTIAL, REAR | ||||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201A - BEARING (FOR REAR DRIVE PINION REAR) | ||||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201B - BEARING (FOR REAR DRIVE PINION FRONT) | ||||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201C - SEAL, OIL (FOR REAR DIFFERENTIAL CARRIER) | ||||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201D - WASHER, PLATE (FOR REAR DIFFERENTIAL DRIVE PINION) | ||||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 41204 - FLANGE SUB-ASSY, REAR DRIVE PINION COMPANION, REAR | ||||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204B - NUT (FOR REAR DRIVE PINION) | ||||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 41214 - SLINGER, REAR DIFFERENTIAL DRIVE PINION OIL | ||||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41222 - PLATE, REAR DIFFERENTIAL RING GEAR SET BOLT LOCK | ||||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222A - BOLT (FOR REAR DIFFERENTIAL RING GEAR SET) | ||||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 41231 - SPACER, REAR DIFFERENTIAL DRIVE PINION BEARING | ||||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252 - DEFLECTOR, DUST (FOR REAR DIFFERENTIAL) | ||||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41302A - BOLT(FOR REAR DIFFERENTIAL CASE) | ||||
| 90105-12087 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90105-12087 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90105-12087 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90105-12087 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90105-12087 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 41315 - NUT, REAR DIFFERENTIAL BEARING ADJUSTING | ||||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315 - NUT, REAR DIFFERENTIAL BEARING ADJUSTING | ||||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41316 - LOCK, REAR DIFFERENTIAL BEARING ADJUSTING NUT | ||||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41371 - SPIDER, REAR DIFFERENTIAL | ||||
| 41371-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41371-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41371-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41371-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41371-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| Common parts | ||||
| 91611-60814 | ||||
ILLUST NO. 1 OF 2(0107- )KDY231..TB..ATM..125T..CBU ; (0107-)KDY221,231..T2,TW2..TS..ATM ; (0
ﾃﾞｨﾌｧﾚﾝｼｬﾙ2ﾋﾟﾆｵﾝ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 41101 - CARRIER SUB-ASSY, DIFFERENTIAL, REAR | ||||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101 - CARRIER SUB-ASSY, DIFFERENTIAL, REAR | ||||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41110 - CARRIER ASSY, DIFFERENTIAL, REAR | ||||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41114 - BOLT, REAR DIFFERENTIAL BEARING CAP | ||||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41114 - BOLT, REAR DIFFERENTIAL BEARING CAP | ||||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41115 - RING, DIFFERENTIAL OIL STORAGE | ||||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115 - RING, DIFFERENTIAL OIL STORAGE | ||||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201 - FINAL GEAR KIT, DIFFERENTIAL, REAR | ||||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201A - BEARING (FOR REAR DRIVE PINION REAR) | ||||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201B - BEARING (FOR REAR DRIVE PINION FRONT) | ||||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201C - SEAL, OIL (FOR REAR DIFFERENTIAL CARRIER) | ||||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201D - WASHER, PLATE (FOR REAR DIFFERENTIAL DRIVE PINION) | ||||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 41204 - FLANGE SUB-ASSY, REAR DRIVE PINION COMPANION, REAR | ||||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204B - NUT (FOR REAR DRIVE PINION) | ||||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 41214 - SLINGER, REAR DIFFERENTIAL DRIVE PINION OIL | ||||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41222 - PLATE, REAR DIFFERENTIAL RING GEAR SET BOLT LOCK | ||||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222A - BOLT (FOR REAR DIFFERENTIAL RING GEAR SET) | ||||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 41231 - SPACER, REAR DIFFERENTIAL DRIVE PINION BEARING | ||||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252 - DEFLECTOR, DUST (FOR REAR DIFFERENTIAL) | ||||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315 - NUT, REAR DIFFERENTIAL BEARING ADJUSTING | ||||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315 - NUT, REAR DIFFERENTIAL BEARING ADJUSTING | ||||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41316 - LOCK, REAR DIFFERENTIAL BEARING ADJUSTING NUT | ||||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| Common parts | ||||
| 91611-60814 | ||||
ILLUST NO. 1 OF 2(0107- )RZY220,230..T2,TW2..WT ; (0107- )KDY220,230..T3..ATM..125T ; (0107-
ﾃﾞｨﾌｧﾚﾝｼｬﾙ2ﾋﾟﾆｵﾝ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 41101 - CARRIER SUB-ASSY, DIFFERENTIAL, REAR | ||||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101 - CARRIER SUB-ASSY, DIFFERENTIAL, REAR | ||||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41110 - CARRIER ASSY, DIFFERENTIAL, REAR | ||||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41114 - BOLT, REAR DIFFERENTIAL BEARING CAP | ||||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41114 - BOLT, REAR DIFFERENTIAL BEARING CAP | ||||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41115 - RING, DIFFERENTIAL OIL STORAGE | ||||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115 - RING, DIFFERENTIAL OIL STORAGE | ||||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201 - FINAL GEAR KIT, DIFFERENTIAL, REAR | ||||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201A - BEARING (FOR REAR DRIVE PINION REAR) | ||||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201B - BEARING (FOR REAR DRIVE PINION FRONT) | ||||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201C - SEAL, OIL (FOR REAR DIFFERENTIAL CARRIER) | ||||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201D - WASHER, PLATE (FOR REAR DIFFERENTIAL DRIVE PINION) | ||||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 41204 - FLANGE SUB-ASSY, REAR DRIVE PINION COMPANION, REAR | ||||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204B - NUT (FOR REAR DRIVE PINION) | ||||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 41214 - SLINGER, REAR DIFFERENTIAL DRIVE PINION OIL | ||||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41222 - PLATE, REAR DIFFERENTIAL RING GEAR SET BOLT LOCK | ||||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222A - BOLT (FOR REAR DIFFERENTIAL RING GEAR SET) | ||||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 41231 - SPACER, REAR DIFFERENTIAL DRIVE PINION BEARING | ||||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252 - DEFLECTOR, DUST (FOR REAR DIFFERENTIAL) | ||||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315 - NUT, REAR DIFFERENTIAL BEARING ADJUSTING | ||||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315 - NUT, REAR DIFFERENTIAL BEARING ADJUSTING | ||||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41316 - LOCK, REAR DIFFERENTIAL BEARING ADJUSTING NUT | ||||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| Common parts | ||||
| 91611-60814 | ||||
ILLUST NO. 1 OF 2(0107- )TRY220,230..ATM..125T ; (0107- )LY220,280..T3,TW3..TS..ATM ; (0107-
ﾃﾞｨﾌｧﾚﾝｼｬﾙ2ﾋﾟﾆｵﾝ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 41101 - CARRIER SUB-ASSY, DIFFERENTIAL, REAR | ||||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101 - CARRIER SUB-ASSY, DIFFERENTIAL, REAR | ||||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41101-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41110 - CARRIER ASSY, DIFFERENTIAL, REAR | ||||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41110-25330 |
KDY230,280..T4;LY280..MTM..WT..DSL;KDY230,280..TW4..MTM;KDY220,240,290,LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41114 - BOLT, REAR DIFFERENTIAL BEARING CAP | ||||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41114 - BOLT, REAR DIFFERENTIAL BEARING CAP | ||||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 90105-16022 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41115 - RING, DIFFERENTIAL OIL STORAGE | ||||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115 - RING, DIFFERENTIAL OIL STORAGE | ||||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41115-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201 - FINAL GEAR KIT, DIFFERENTIAL, REAR | ||||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201-80165 |
LY280..MTM..WT..DSL;LY220,230,240,290,RZY231..(T4,TW4,VAN)..MTM..(125T,15T) *FGR=43:10=4.300 |
1 | ||
| 41201A - BEARING (FOR REAR DRIVE PINION REAR) | ||||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-40100 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201B - BEARING (FOR REAR DRIVE PINION FRONT) | ||||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90366-35108 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201C - SEAL, OIL (FOR REAR DIFFERENTIAL CARRIER) | ||||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48019 |
LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 90311-48024 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY231,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41201D - WASHER, PLATE (FOR REAR DIFFERENTIAL DRIVE PINION) | ||||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40006 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.075 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40009 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.15 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40008 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.125 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40010 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.175 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40004 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.05 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.25 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40015 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.30 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40011 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.20 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40016 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.325 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40007 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.10 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40022 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.475 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40017 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.35 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40019 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.40 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40025 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.55 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40020 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.425 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40024 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.525 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40018 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.375 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40012 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.225 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40014 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.275 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40023 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.50 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 90564-40021 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN 厚さ=1.45 |
1 | ||
| 41204 - FLANGE SUB-ASSY, REAR DRIVE PINION COMPANION, REAR | ||||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41204B - NUT (FOR REAR DRIVE PINION) | ||||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 90179-22003 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 外径=29 |
1 | ||
| 41214 - SLINGER, REAR DIFFERENTIAL DRIVE PINION OIL | ||||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41214-37010 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41222 - PLATE, REAR DIFFERENTIAL RING GEAR SET BOLT LOCK | ||||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
6 | ||
| 41222A - BOLT (FOR REAR DIFFERENTIAL RING GEAR SET) | ||||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 90101-14315 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
12 | ||
| 41231 - SPACER, REAR DIFFERENTIAL DRIVE PINION BEARING | ||||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41231-36040 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252 - DEFLECTOR, DUST (FOR REAR DIFFERENTIAL) | ||||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41252-37020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 90366-52004 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315 - NUT, REAR DIFFERENTIAL BEARING ADJUSTING | ||||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315 - NUT, REAR DIFFERENTIAL BEARING ADJUSTING | ||||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41315-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41316 - LOCK, REAR DIFFERENTIAL BEARING ADJUSTING NUT | ||||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41316-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ｼﾝｸﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41317-36011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾀﾞﾌﾞﾙ ﾀｲﾌﾟ |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41331-36020 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
2 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41341-55013 |
KDY280..TB;KDY280..TW1;KDY231..15T..ST;KDY230,TRY230..T2..15T..ST;KDY230,281,TRY230..TW1,TW4;KDY230,281,TRY230..(T3,T4)..15T;KDY220,240,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,231,281..T4,TW4,VAN |
4 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41351-35011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
4 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60021 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.75 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60480 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.55 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.80 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60041 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.05 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60031 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.90 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60550 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.10 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60500 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.70 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60011 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.60 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.85 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60540 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=2.00 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60490 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.65 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| 41361-60530 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN 厚さ=1.95 |
2 | ||
| Common parts | ||||
| 91611-60814 | ||||
ILLUST NO. 2 OF 2(0107- )T4,TW4,VAN
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04412 - GASKET KIT, REAR DIFFERENTIAL CARRIER | ||||
| 04412-25100 |
KDY22#,23#,24#,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41110A - BOLT, NO.1 (FOR REAR DIFFERENTIAL CARRIER SET) | ||||
| 90116-10211 |
KDY22#,23#,24#,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾈｼﾞ部長さ=17&12.5,長さ41.5 |
4 | ||
| 42110 - HOUSING ASSY, REAR AXLE | ||||
| 42110-25510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 42110-25520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN ｱﾘ(ABS) |
1 | ||
| 42110A - PLUG (FOR REAR AXLE HOUSING FILLER) | ||||
| 90341-18006 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 42110B - GASKET (FOR REAR AXLE HOUSING FILLER PLUG) | ||||
| 12157-10010 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 42110C - PLUG, BREATHER (FOR REAR AXLE HOUSING) | ||||
| 90930-03138 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 42110D - GASKET (FOR REAR AXLE HOUSING DRAIN PLUG) | ||||
| 12157-10010 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 42110E - PLUG (FOR REAR AXLE HOUSING DRAIN) | ||||
| 90341-18040 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 42181 - GASKET, REAR DIFFERENTIAL CARRIER | ||||
| 42181-36060 |
KDY22#,23#,24#,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| Common parts | ||||
| 90119-10283 | ||||
| 94130-01002 | ||||
| 94531-01000 | ||||
| Linked diagrams | ||||
| 4102 | ||||
ILLUST NO. 2 OF 2(0107- )TRY230..T2..WT ; (0107- )TRY230..TB..125T ; (0107- )KDY22#,23#,LY2
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04412 - GASKET KIT, REAR DIFFERENTIAL CARRIER | ||||
| 04412-25100 |
KDY22#,23#,24#,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| 41110A - BOLT, NO.1 (FOR REAR DIFFERENTIAL CARRIER SET) | ||||
| 90116-10211 |
KDY22#,23#,24#,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN ﾈｼﾞ部長さ=17&12.5,長さ41.5 |
4 | ||
| 42110 - HOUSING ASSY, REAR AXLE | ||||
| 42110-25510 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN |
1 | ||
| 42110-25520 |
KDY220,230,240,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,230..T4,TW4,VAN ｱﾘ(ABS) |
1 | ||
| 42110A - PLUG (FOR REAR AXLE HOUSING FILLER) | ||||
| 90341-18006 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 42110B - GASKET (FOR REAR AXLE HOUSING FILLER PLUG) | ||||
| 12157-10010 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 42110C - PLUG, BREATHER (FOR REAR AXLE HOUSING) | ||||
| 90930-03138 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 42110D - GASKET (FOR REAR AXLE HOUSING DRAIN PLUG) | ||||
| 12157-10010 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 42110E - PLUG (FOR REAR AXLE HOUSING DRAIN) | ||||
| 90341-18040 |
KDY22#,23#,24#,27#,28#,290,LY220,230,240,270,280,290,RZY220,23#,281,TRY220,23#,281 |
1 | ||
| 42181 - GASKET, REAR DIFFERENTIAL CARRIER | ||||
| 42181-36060 |
KDY22#,23#,24#,280,290,LY220,230,240,280,290,RZY220,23#,281,TRY220,23#,281..T4,TW4,VAN |
1 | ||
| Common parts | ||||
| 90170-08204 | ||||
| 94531-00800 | ||||
Part Price Details
Loading price information...
Part Number:
Price:
