BZU300-TKMQC (2003)
Toyota Dyna/Toyoace
(0406- )BZU300,RZU300..T3..CBU ; (0406- )XZU301,304,306,308,368..SCB..T3,T4,T
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 60531 - FRAME SUB-ASSY, FLOOR SIDE, RH | ||||
| 60531-37600 |
BZU300,RZU300,XZU301,304..T3..CBU |
1 | ||
| 60532 - FRAME SUB-ASSY, FLOOR SIDE, LH | ||||
| 60532-37600 |
BZU300,RZU300,XZU301,304..T3..CBU |
1 | ||
| 65026 - BRACKET SUB-ASSY, GATE RUBBER BUMPER, RH | ||||
| 65026-37020 |
XZU302..T3..CBU;XZU347..SCB..CBU;BZU300,340..T4..CNG;XZU301..(T3,T5)..CBU;XZU347..DCB..5F..CBU;XZU306,322..T5..5F..CBU;XZU301,306..T4..CBU..4NO;XZU302..(T4,T5)..CBU..4NO;XZU347..DCB..T4..4FC..CBU;BU30#,346,BZU300,340,RZU30#,340,XZU300,307,33#,340,341,342,346,362,372..(T2,T3,T4,T5)..CBU |
1 | ||
| 65026-37020 |
RZU300..LPG;BZU300,340..T4..CNG;BZU300,340,RZU30#,340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..CBU |
1 | ||
| 65027 - BRACKET SUB-ASSY, GATE RUBBER BUMPER, LH | ||||
| 65027-37020 |
XZU302..T3..CBU;XZU347..SCB..CBU;BZU300,340..T4..CNG;XZU301..(T3,T5)..CBU;XZU347..DCB..5F..CBU;XZU306,322..T5..5F..CBU;XZU301,306..T4..CBU..4NO;XZU302..(T4,T5)..CBU..4NO;XZU347..DCB..T4..4FC..CBU;BU30#,346,BZU300,340,RZU30#,340,XZU300,307,33#,340,341,342,346,362,372..(T2,T3,T4,T5)..CBU |
1 | ||
| 65027-37020 |
RZU300..LPG;BZU300,340..T4..CNG;BZU300,340,RZU30#,340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..CBU |
1 | ||
| 65100 - FLOOR ASSY, REAR BODY | ||||
| 65100-37E20 |
BZU300,RZU300,XZU301,304..T3..CBU *** |
1 | ||
| 65100-37K40 |
BZU300,RZU300,XZU301,304..T3..CBU *** |
1 | ||
| 65110 - SILL ASSY, MAIN, RH | ||||
| 65110-37780 |
BZU300,RZU300,XZU300,301,302..T3..CBU |
1 | ||
| 65110-37780 |
BZU300,RZU300,XZU301,304..T3..CBU |
1 | ||
| 65120 - SILL ASSY, MAIN, LH | ||||
| 65120-37780 |
BZU300,RZU300,XZU300,301,302..T3..CBU |
1 | ||
| 65120-37780 |
BZU300,RZU300,XZU301,304..T3..CBU |
1 | ||
| 65125A - SHIM, MAIN SILL, LOWER NO.1 | ||||
| 65125-37670 |
BZU300..T4..CNG;BZU300,RZU300,XZU301,304..T3..CBU ﾌﾛﾝﾄ |
2 | ||
| 65127-37490 |
BZU300..T4..CNG;BZU300,RZU300,XZU301,304..T3..CBU ﾘﾔ右側,ﾘﾔ左側 |
1 | ||
| 65125A - SHIM, MAIN SILL, LOWER NO.1 | ||||
| 65125-37670 |
BZU300..T4..CNG;BZU300,RZU300,XZU301,304..T3..CBU ﾌﾛﾝﾄ |
2 | ||
| 65127-37490 |
BZU300..T4..CNG;BZU300,RZU300,XZU301,304..T3..CBU ﾘﾔ右側,ﾘﾔ左側 |
1 | ||
| 65125A - SHIM, MAIN SILL, LOWER NO.1 | ||||
| 65125-37670 |
BZU300..T4..CNG;BZU300,RZU300,XZU301,304..T3..CBU ﾌﾛﾝﾄ |
2 | ||
| 65127-37490 |
BZU300..T4..CNG;BZU300,RZU300,XZU301,304..T3..CBU ﾘﾔ右側,ﾘﾔ左側 |
1 | ||
| 65125A - SHIM, MAIN SILL, LOWER NO.1 | ||||
| 65125-37670 |
BZU300..T4..CNG;BZU300,RZU300,XZU301,304..T3..CBU ﾌﾛﾝﾄ |
2 | ||
| 65127-37490 |
BZU300..T4..CNG;BZU300,RZU300,XZU301,304..T3..CBU ﾘﾔ右側,ﾘﾔ左側 |
1 | ||
| 65137 - COVER, MAIN SILL END | ||||
| 65137-37030 |
BZU300,340..T4..CNG;BZU300,340,XZU334..30T..CBU;RZU300,XZU301,304,306,308,331,341,344,346,378,388..(T3,T5)..CBU |
2 | ||
| 65160 - SILL ASSY, CROSS, NO.2 | ||||
| 65160-37140 |
XZU347..DCB..5F..CBU;XZU347..DCB..T4..4FC..CBU;XZU347,372..SCB..(T3,T4)..CBU;BZU300,RZU300,XZU300,301,302..T3..CBU;BU346,BZU340,RZU340,XZU330,331,340,341,342,346,382..(T3,T4)..CBU |
1 | ||
| 65160-37140 |
XZU378..SCB..CBU;XZU346,388..DCB..CBU;BZU300,RZU300..T3..CBU;XZU301,304,331,334..30T..CBU..1NO |
1 | ||
| 65170 - SILL ASSY, CROSS, NO.2 | ||||
| 65160-37260 |
BZU340..CNG;XZU347..DCB..5F..CBU;XZU347..SCB..(T3,T4)..CBU;XZU347..DCB..T4..4FC..CBU;BZU300,RZU300,XZU300,301,302..T3..CBU;BU346,BZU340,RZU340,XZU330,331,340,341,342,346,372,382..(T3,T4)..CBU |
1 | ||
| 65160-37260 |
BZU340..CNG;BZU300,RZU300,XZU334..T3..CBU;BZU340,RZU340,XZU301,304,331,34#,378,388..(T3,T4)..CBU..1NO |
1 | ||
| 65180 - SILL ASSY, CROSS, NO.4 | ||||
| 65180-37440 |
BZU300,RZU300,XZU301,304..T3..CBU |
1 | ||
| 65190 - SILL ASSY, CROSS, NO.5 | ||||
| 65190-37040 |
BZU340..CNG;BZU300,RZU300,XZU334..T3..CBU;BZU340,RZU340,XZU301,304,331,34#,378,388..(T3,T4)..CBU..1NO |
1 | ||
| 65190-37040 |
BZU340..CNG;XZU347..DCB..5F..CBU;XZU347..SCB..(T3,T4)..CBU;XZU347..DCB..T4..4FC..CBU;BZU300,RZU300,XZU300,301,302..T3..CBU;BU346,BZU340,RZU340,XZU330,331,340,341,342,346,372,382..(T3,T4)..CBU |
1 | ||
| 65220 - SILL ASSY, CROSS, NO.4 | ||||
| 65180-37440 |
BZU340..CNG;BZU300,RZU300,XZU334..T3..CBU;BZU340,RZU340,XZU301,304,331,34#,378,388..(T3,T4)..CBU..1NO |
1 | ||
| 65250 - SILL ASSY, CROSS, NO.2 | ||||
| 65160-37140 |
BZU340..CNG;XZU347..DCB..5F..CBU;XZU347..SCB..(T3,T4)..CBU;XZU347..DCB..T4..4FC..CBU;BZU300,RZU300,XZU300,301,302..T3..CBU;BU346,BZU340,RZU340,XZU330,331,340,341,342,346,372,382..(T3,T4)..CBU |
1 | ||
| 65160-37140 |
BZU340..CNG;BZU300,RZU300,XZU334..T3..CBU;BZU340,RZU340,XZU301,304,331,34#,378,388..(T3,T4)..CBU..1NO |
1 | ||
| 65307A - FRAME SUB-ASSY, FLOOR, REAR | ||||
| 65307-37220 |
BZU340..CNG;XZU372..T3..CBU;XZU347..DCB..T3..5F..CBU;BU346,BZU300,340,RZU300,XZU300,301,302,330,331,340,341,342,346,347..SCB..T3..CBU |
1 | ||
| 65307-37220 |
BZU340..CNG;BZU300,340,RZU300,XZU301,304,331,334,341,344,346,378,388..T3..CBU |
1 | ||
| 65307-37540 |
BZU340..CNG;BZU300,340,RZU300,XZU301,304,331,334,341,344,346,378,388..T3..CBU |
1 | ||
| 65322 - NAIL | ||||
| 90290-05001 |
BZU300..T4..CNG;BZU300,RZU300,XZU301,304..T3..CBU |
11 | ||
| 65349 - FENDER, FLOOR SIDE | ||||
| 65349-37010 |
RZU300..LPG;BZU300,340..T4..CNG;BZU300,340,RZU30#,340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..CBU |
2 | ||
| 66219A - EXTENSION, REAR FENDER | ||||
| 66219-37080 |
RZU300..LPG;BZU300,340..T4..CNG;BZU300,340,RZU30#,340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..CBU |
1 | ||
| 66219B - EXTENSION, REAR FENDER | ||||
| 66219-37080 |
RZU300..LPG;BZU300,340..T4..CNG;BZU300,340,RZU30#,340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..CBU |
1 | ||
| 66225A - SUPPORT, BAFFLE RUBBER | ||||
| 66242-37220 |
BZU340..CNG;BZU300,RZU300..T3..CBU;BZU340,RZU340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..WT..CBU 長さ=330 |
1 | ||
| 66225A - SUPPORT, BAFFLE RUBBER | ||||
| 66242-37220 |
BZU340..CNG;BZU300,RZU300..T3..CBU;BZU340,RZU340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..WT..CBU 長さ=330 |
1 | ||
| 66225B - SUPPORT, BUFFLE RUBBER | ||||
| 66242-37220 |
RZU300..LPG;BZU300,340..T4..CNG;BZU300,340,RZU30#,340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..WT..CBU 長さ=330 |
1 | ||
| 66241B - BAFFLE, RUBBER | ||||
| 66241-3V150 |
BZU300,RZU300..T3..CBU TOYOTA |
1 | ||
| 66241-3V310 |
BZU300,RZU300..T3..CBU HINO |
1 | ||
| 66241B - BAFFLE, RUBBER | ||||
| 66241-3V150 |
BZU300,RZU300..T3..CBU TOYOTA |
1 | ||
| 66241-3V310 |
BZU300,RZU300..T3..CBU HINO |
1 | ||
| 66241C - BUFFLE, RUBBER | ||||
| 66241-3V190 |
XZU378,388..T4..CBU;XZU331,341,344..T4..30T..CBU;BZU300,RZU300,XZU301,304,306,308..(T3,T5)..WT..CBU TOYOTA |
1 | ||
| 66241-3V350 |
XZU378,388..T4..CBU;XZU331,341,344..T4..30T..CBU;BZU300,RZU300,XZU301,304,306,308..(T3,T5)..WT..CBU HINO |
1 | ||
| 66259A - COVER, REAR BODY FLOOR, REAR | ||||
| 66259-37010 |
RZU300..LPG;BZU300,340..T4..CNG;BZU300,340,RZU30#,340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..CBU |
2 | ||
| 66312D - HOOK, ROPE, NO.2 | ||||
| 66311-37020 |
RZU300..LPG;BZU300..T4..CNG;BZU300,RZU30#,XZU301,304,306,308,33#,368,378..SCB..(T2,T3,T4,T5)..CBU |
6 | ||
| 66312E - HOOK, ROPE, NO.2 | ||||
| 66312-37020 |
RZU300..LPG;BZU300,340..T4..CNG;BZU300,340,RZU30#,340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..CBU |
1 | ||
| 66312F - HOOK, ROPE, NO.2 | ||||
| 66311-37020 |
RZU300..LPG;BZU300..T4..CNG;BZU300,RZU30#,XZU301,304,306,308,33#,368,378..SCB..(T2,T3,T4,T5)..CBU |
6 | ||
| 66312G - HOOK, ROPE, NO.2 | ||||
| 66312-37020 |
RZU300..LPG;BZU300,340..T4..CNG;BZU300,340,RZU30#,340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..CBU |
1 | ||
| 66315A - HOOK, ROPE | ||||
| 66315-37010 |
BZU340..CNG;BZU300,340,RZU300,XZU301,304,331,334,341,344,346,378,388..T3..CBU |
4 | ||
| 66321E - BUMPER, GATE RUBBER | ||||
| 66321-92803 |
RZU300..LPG;BZU300,340..T4..CNG;BZU300,340,RZU30#,340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..CBU |
2 | ||
| 66321G - BUMPER, GATE RUBBER | ||||
| 66321-92805 |
RZU300..LPG;BZU300,340..T4..CNG;BZU300,340,RZU30#,340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..CBU |
4 | ||
| 66321G - BUMPER, GATE RUBBER | ||||
| 66321-92805 |
RZU300..LPG;BZU300,340..T4..CNG;BZU300,340,RZU30#,340,XZU301,304,306,308,33#,34#,368,378,388..(T2,T3,T4,T5)..CBU |
4 | ||
| Common parts | ||||
| 90119-08B66 | ||||
| 90149-50065 | ||||
| 90179-10036 | ||||
| 90241-09002 | ||||
| 90241-09003 | ||||
| 90241-09004 | ||||
| 91611-G0820 | ||||
| 91642-81025 | ||||
| 93210-16016 | ||||
| 93540-15016 | ||||
| 94150-80600 | ||||
| 94184-01001 | ||||
(0610- )XZU504..DCRTJ,DCRUD..CBU ; (0610-)XZU508..T4..5F..DCRTH,DCRUD..CBU ;
TECS=ﾊﾟﾜｰﾘﾌﾄ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-08B66 | ||||
| 90149-50065 | ||||
| 90179-10036 | ||||
| 90241-09002 | ||||
| 90241-09003 | ||||
| 91611-G0820 | ||||
| 91642-81025 | ||||
| 93210-16016 | ||||
| 94150-80600 | ||||
| 94184-01001 | ||||
(0610- )BZU300,TRU300,XZU304..T3..CBU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-08B66 | ||||
| 90149-50065 | ||||
| 90179-10036 | ||||
| 90241-09004 | ||||
| 91642-81025 | ||||
| 93210-16016 | ||||
| 93540-15016 | ||||
| 94150-80600 | ||||
| 94184-01001 | ||||
(0610- )XZU504..DCRTJ,DCRUD..CBU ; (0610-)XZU304..T5..20T..DCRUE..CBU ; (061
TECS=ﾊﾟﾜｰｹﾞｰﾄ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-08B66 | ||||
| 90149-50065 | ||||
| 90179-10036 | ||||
| 90241-09002 | ||||
| 90241-09003 | ||||
| 91611-G0820 | ||||
| 91642-81025 | ||||
| 93210-16016 | ||||
| 93540-15016 | ||||
| 94150-80600 | ||||
| 94184-01001 | ||||
