Toyota Dyna/toyoace BU95 SIDE BUMPER & BUMPER STAY - JDM Part Detective

Home Blog About Contact Search

Manufacturers Home
Toyota
JP
DYNA/TOYOACE
BU95-MDDTX3 (1984)
5254 - SIDE BUMPER & BUMPER STAY

BU95-MDDTX3 (1984)

Toyota Dyna/Toyoace

Production Sep 1984 - Aug 1987

Engine 13BT

Transmission

Displacement 2500cc

Power 168 HP (125 kW)

(8409- )BU93,95

Click highlighted areas on diagram

diagram

Part #	Description	Period	Qty	Price
52901 - BUMPER SUB-ASSY, SIDE, RH NO.1
52901-92806	BU93,95	09/1984 - 08/1987	1
52901 - BUMPER SUB-ASSY, SIDE, RH NO.1
52901-92806	BU93,95	09/1984 - 08/1987	1
52902 - BUMPER SUB-ASSY, SIDE, LH NO.1
52902-92806	BU93,95	09/1984 - 08/1987	1
52902 - BUMPER SUB-ASSY, SIDE, LH NO.1
52902-92806	BU93,95	09/1984 - 08/1987	1
52914 - STAY, SIDE BUMPER REAR, RH NO.1
52913-92701	BU85..T3,TW1;BU82..06S..ATP;BU77,82,90,93,95..03S	09/1984 - 08/1987	1
52914 - STAY, SIDE BUMPER REAR, RH NO.1
52913-92701	BU85..T3,TW1;BU82..06S..ATP;BU77,82,90,93,95..03S	09/1984 - 08/1987	1
52915 - STAY, SIDE BUMPER REAR, LH NO.1
52913-92701	BU85..T3,TW1;BU82..06S..ATP;BU82,90,93,95..03S	09/1984 - 08/1987	1
52915 - STAY, SIDE BUMPER REAR, LH NO.1
52913-92701	BU85..T3,TW1;BU82..06S..ATP;BU82,90,93,95..03S	09/1984 - 08/1987	1
52917 - STAY, SIDE BUMPER CENTER, NO.1
52915-92802	BU93,95	09/1984 - 08/1987	4
52917 - STAY, SIDE BUMPER CENTER, NO.1
52915-92802	BU93,95	09/1984 - 08/1987	4
52917 - STAY, SIDE BUMPER CENTER, NO.1
52915-92802	BU93,95	09/1984 - 08/1987	4
52923 - STAY, SIDE BUMPER, FRONT RH
52913-92701	BU62,77,82,85,90,93,95..T3,TW1	09/1984 - 08/1987	1
52924 - STAY, SIDE BUMPER, FRONT LH
52913-92701	BU62,77,82,85,90,93,95..T3,TW1	09/1984 - 08/1987	1
52924 - STAY, SIDE BUMPER, FRONT LH
52913-92701	BU62,77,82,85,90,93,95..T3,TW1	09/1984 - 08/1987	1
Common parts
90201-11369
91111-40820
91111-41065
91111-50820
91611-41020
94110-40800
94110-41000
94180-41000
