BU88-PDGT3 (1988)
Toyota Dyna/Toyoace
(8808- )BU78,85,88,9#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55301 - PANEL SUB-ASSY, INSTRUMENT | ||||
| 55311-9542306 |
BU88,96..DYN..4FC BROWN,TRIM4# |
1 | ||
| 55311-95423B0 |
BU88,96..4FC GRAY,TRIM1# |
1 | ||
| 55302B - PANEL SUB-ASSY, INSTRUMENT SIDE | ||||
| 55302-9540806 |
BU87..DYN..03S..IV3;BU60,61,66,67,72,74,78,83,84,85,88,9#..DYN..(DM1,T1,T2,T3,T4)..IV3 BROWN,TRIM4# |
1 | ||
| 55302-95408B0 |
BU87..03S..IV3;BU60,61,66,67,72,73,74,78,83,84,88,9#..(DM1,T1,T2,T3,T4)..IV3 GRAY,TRIM1# |
1 | ||
| 55306B - BRACE SUB-ASSY, INSTRUMENT PANEL TO COWL | ||||
| 55306-95405 |
BU6#,7#,8#,9# |
1 | ||
| 55307 - REINFORCEMENT SUB-ASSY, INSTRUMENT PANEL, LOWER | ||||
| 55307-95405 |
BU78,85,88,9# |
1 | ||
| 55321B - BRACKET, INSTRUMENT PANEL, NO.1 | ||||
| 55321-95404 |
BU87..03S..IV3;BU60,61,66,67,72,73,74,78,83,84,85,88,9#..(DM1,T1,T2,T3,T4)..IV3 |
2 | ||
| 55321B - BRACKET, INSTRUMENT PANEL, NO.1 | ||||
| 55321-95404 |
BU87..03S..IV3;BU60,61,66,67,72,73,74,78,83,84,85,88,9#..(DM1,T1,T2,T3,T4)..IV3 |
2 | ||
| 55359B - BOX, INSTRUMENT PANEL, CENTER | ||||
| 55359-9540401 |
BU78,85,88,9#..DYN BLACK,TRIM4# |
1 | ||
| 55359-9540401 |
BU78,88,9# BLACK,TRIM1# |
1 | ||
| 55366B - BRACKET, RADIO TUNER MOUNTING, RH | ||||
| 55366-37010 |
BU78,88,9# |
1 | ||
| 55366-95400 |
BU78,85,88,9# |
1 | ||
| 55366-37011 |
BU78,88,9# |
1 | ||
| 55401E - PAD SUB-ASSY, INSTRUMENT PANEL SAFETY | ||||
| 55401-9542606 |
BU88,96..DYN..4FC BROWN,TRIM4# |
1 | ||
| 55401-95426B0 |
BU88,96..4FC GRAY,TRIM1# |
1 | ||
| 55402D - PAD SUB-ASSY, INSTRUMENT PANEL SAFETY, NO.1 | ||||
| 55402-9541906 |
BU88,96..DYN..4FC BROWN,TRIM4# |
1 | ||
| 55402-95419B0 |
BU88,96..4FC GRAY,TRIM1# |
1 | ||
| 55403 - HOOD SUB-ASSY, METER | ||||
| 55403-95B2106 |
BU6#,7#,8#,9#..DYN BROWN,TRIM4# |
1 | ||
| 55403-95B22B0 |
BU6#,7#,8#,9# GRAY,TRIM1# |
1 | ||
| 55403-95B2206 |
BU96..DYN..4FC..TD;BU87,96..DYN..TR..5F..03S;BU66..DYN..(DM2,DM3,DM5,T2,T3,T4);BU67,72,74,78,85,88,90,91,94,95..DYN..03S ｱﾘ(ｱﾗ-ﾑ ﾂｷ ｸﾛﾂｸ),BROWN,TRIM4# |
1 | ||
| 55403-95B28B0 |
BU96..4FC..TD;BU87,96..TR..5F..03S;BU66..DM2,DM3,DM5,T2,T3,T4;BU67,72,73,74,78,88,91,94..03S ｱﾘ(ｱﾗ-ﾑ ﾂｷ ｸﾛﾂｸ & ﾀｺｸﾞﾗﾌ),GRAY,TRIM1# |
1 | ||
| 55403-95B22B0 |
BU96..4FC..TD;BU87,96..TR..5F..03S;BU66..DM2,DM3,DM5,T2,T3,T4;BU67,72,73,74,78,88,91,94..03S ｱﾘ(ｱﾗ-ﾑ ﾂｷ ｸﾛﾂｸ),GRAY,TRIM1# |
1 | ||
| 55403-95B28B0 |
BU6#,7#,8#,9#..(DSL,TD)..(CBU,IV3) ｱﾘ(ﾀｺｸﾞﾗﾌ),GRAY,TRIM1# |
1 | ||
| 55403-95B23B0 |
BU6#,7#,8#,9#..CBU,IV3 ｱﾘ(ﾀｺｸﾞﾗﾌ),GRAY,TRIM1# |
1 | ||
| 55403-95B21B0 |
BU6#,7#,8#,9# GRAY,TRIM1# |
1 | ||
| 55403-95B28B0 |
BU96..4FC..TD;BU87,96..TR..5F..03S;BU66..DM2,DM3,DM5,T2,T3,T4;BU67,72,73,74,78,88,91,94..03S ｱﾘ(ｱﾗ-ﾑ ﾂｷ ｸﾛﾂｸ & ﾀｺｸﾞﾗﾌ),GRAY,TRIM1# |
1 | ||
| 55403-95B22B0 |
BU96..4FC..TD;BU87,96..TR..5F..03S;BU66..DM2,DM3,DM5,T2,T3,T4;BU67,72,73,74,78,88,91,94..03S ｱﾘ(ｱﾗ-ﾑ ﾂｷ ｸﾛﾂｸ),GRAY,TRIM1# |
1 | ||
| 55413D - PANEL, INSTRUMENT CLUSTER FINISH, CENTER LOWER | ||||
| 55413-95404B0 |
BU78,88,9# GRAY,TRIM1# |
1 | ||
| 55413-9540406 |
BU78,85,88,9#..DYN BROWN,TRIM4# |
1 | ||
| 55414 - BEZEL, CIGAR LIGHTER HOLE | ||||
| 55414-95J00 |
BU6#,7#,8#,9# |
1 | ||
| 55425C - BRACKET, METER HOOD SET, NO.1 | ||||
| 55425-95404 |
BU6#,7#,8#,9# |
2 | ||
| 55427F - BRACKET, METER HOOD SET, NO.3 | ||||
| 55427-95402 |
BU6#,7#,8#,9# |
1 | ||
| 55441C - BOX, INSTRUMENT PANEL COIN | ||||
| 55441-95418B0 |
BU78,88,9# GRAY,TRIM1# |
1 | ||
| 55441-9541806 |
BU78,85,88,9#..DYN BROWN,TRIM4# |
1 | ||
| 55445C - PLATE, INSTRUMENT PANEL BOX | ||||
| 55445-95403 |
BU78,85,88,9# |
1 | ||
| 55475B - GARNISH, INSTRUMENT CLUSTER FINISH PANEL, CENTER | ||||
| 55475-95402E0 |
BU88,96..DYN..4FC BROWN,TRIM4# |
1 | ||
| 55475-95402R5 |
BU88,96..DYN..4FC BLUE,TRIM4# |
1 | ||
| 55475-37020B0 |
BU88,96..4FC GRAY,TRIM1# |
1 | ||
| 55476D - GARNISH, INSTRUMENT PANEL FINISH PLATE | ||||
| 55476-95401 |
BU88,96..4FC |
1 | ||
| 55476-37020B0 |
BU88,96..4FC GRAY,TRIM1# |
1 | ||
| 55501A - DOOR SUB-ASSY, GLOVE COMPARTMENT | ||||
| 55501-9541206 |
BU6#,7#,8#,9#..DYN BROWN,TRIM4# |
1 | ||
| 55501-95412B0 |
BU6#,7#,8#,9# GRAY,TRIM1# |
1 | ||
| 55510A - CUSHION(FOR GLOVE COMPARTMENT DOOR) | ||||
| 90541-03015 |
BU6#,7#,8#,9# 外径=7 |
1 | ||
| 90541-05080 |
BU6#,7#,8#,9# OD=10 |
2 | ||
| 55521C - COVER, STEREO OPENING | ||||
| 55521-1405001 |
BU72..DM4,DM5,T3,T4;BU60,61,67,70,73,74,78,8#,9#;BU66..DM2,DM3,DM5,T2,T3,T4,TW1,TW4 BLACK,TRIM1# |
1 | ||
| 55521-1405001 |
BU6#,7#,8#,9#..DYN BLACK,TRIM4# |
1 | ||
| 55522B - COVER, RADIO TUNER OPENING | ||||
| 55522-20040 |
BU60,61,67,7#,8#,9#;BU66..DM2,DM3,DM5,T2,T3,T4,TW1,TW4 |
1 | ||
| 55526 - COVER, INSTRUMENT PANEL REGISTER OPENING | ||||
| 55526-95400B0 |
BU78,88,9# GRAY,TRIM1# |
1 | ||
| 55526-9540006 |
BU78,85,88,9#..DYN BROWN,TRIM4# |
1 | ||
| 55537A - COVER, THROTTLE KNOB HOLE | ||||
| 55537-9501016 |
BU6#,7#,8#,9#..DYN BROWN,TRIM4# |
1 | ||
| 55537-95010B0 |
BU6#,7#,8#,9#..DSL,TD GRAY,TRIM1# |
1 | ||
| 55539 - COVER, SPARE SWITCH HOLE | ||||
| 55539-95J0006 |
BU67..DYN..4FC;BU67,72..DYN..TR;BU66..DYN..TR..CBU;BU72..DYN..DMP..IV3;BU66..DYN..(IV3,IV4);BU60,61,68,70,74,78,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J0006 |
BU6#,70,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J0006 |
BU6#,7#,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
1 | ||
| 55539-95J00B0 |
BU73..03S;BU6#,70,72,74,78,8#,9# GRAY,TRIM1#,42.6 X 24.6 |
1 | ||
| 55539-95J0006 |
BU67,72..DYN..TR;BU66..DYN..TR..CBU;BU72..DYN..DMP..IV3;BU66..DYN..(IV3,IV4);BU60,61,68,70,74,78,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J00B0 |
BU73..03S;BU6#,70,72,74,78,8#,9# GRAY,TRIM1# |
1 | ||
| 55539-95J00B0 |
BU66..TR..CBU;BU72..DMP..IV3;BU66,68..IV3,IV4;BU60,61,67,7#,8#,9#..TR,V GRAY,TRIM1#,42.6 X 24.6 |
2 | ||
| 55539-95J00B0 |
BU66,72..TR..CBU;BU66,68,72..IV3,IV4;BU60,61,67,70,73,74,78,8#,9#..TR,V GRAY,TRIM1# |
2 | ||
| 55539 - COVER, SPARE SWITCH HOLE | ||||
| 55539-95J0006 |
BU67..DYN..4FC;BU67,72..DYN..TR;BU66..DYN..TR..CBU;BU72..DYN..DMP..IV3;BU66..DYN..(IV3,IV4);BU60,61,68,70,74,78,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J0006 |
BU6#,70,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J0006 |
BU6#,7#,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
1 | ||
| 55539-95J00B0 |
BU73..03S;BU6#,70,72,74,78,8#,9# GRAY,TRIM1#,42.6 X 24.6 |
1 | ||
| 55539-95J0006 |
BU67,72..DYN..TR;BU66..DYN..TR..CBU;BU72..DYN..DMP..IV3;BU66..DYN..(IV3,IV4);BU60,61,68,70,74,78,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J00B0 |
BU73..03S;BU6#,70,72,74,78,8#,9# GRAY,TRIM1# |
1 | ||
| 55539-95J00B0 |
BU66..TR..CBU;BU72..DMP..IV3;BU66,68..IV3,IV4;BU60,61,67,7#,8#,9#..TR,V GRAY,TRIM1#,42.6 X 24.6 |
2 | ||
| 55539-95J00B0 |
BU66,72..TR..CBU;BU66,68,72..IV3,IV4;BU60,61,67,70,73,74,78,8#,9#..TR,V GRAY,TRIM1# |
2 | ||
| 55539 - COVER, SPARE SWITCH HOLE | ||||
| 55539-95J0006 |
BU67..DYN..4FC;BU67,72..DYN..TR;BU66..DYN..TR..CBU;BU72..DYN..DMP..IV3;BU66..DYN..(IV3,IV4);BU60,61,68,70,74,78,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J0006 |
BU6#,70,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J0006 |
BU6#,7#,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
1 | ||
| 55539-95J00B0 |
BU73..03S;BU6#,70,72,74,78,8#,9# GRAY,TRIM1#,42.6 X 24.6 |
1 | ||
| 55539-95J0006 |
BU67,72..DYN..TR;BU66..DYN..TR..CBU;BU72..DYN..DMP..IV3;BU66..DYN..(IV3,IV4);BU60,61,68,70,74,78,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J00B0 |
BU73..03S;BU6#,70,72,74,78,8#,9# GRAY,TRIM1# |
1 | ||
| 55539-95J00B0 |
BU66..TR..CBU;BU72..DMP..IV3;BU66,68..IV3,IV4;BU60,61,67,7#,8#,9#..TR,V GRAY,TRIM1#,42.6 X 24.6 |
2 | ||
| 55539-95J00B0 |
BU66,72..TR..CBU;BU66,68,72..IV3,IV4;BU60,61,67,70,73,74,78,8#,9#..TR,V GRAY,TRIM1# |
2 | ||
| 55539 - COVER, SPARE SWITCH HOLE | ||||
| 55539-95J0006 |
BU67..DYN..4FC;BU67,72..DYN..TR;BU66..DYN..TR..CBU;BU72..DYN..DMP..IV3;BU66..DYN..(IV3,IV4);BU60,61,68,70,74,78,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J0006 |
BU6#,70,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J0006 |
BU6#,7#,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
1 | ||
| 55539-95J00B0 |
BU73..03S;BU6#,70,72,74,78,8#,9# GRAY,TRIM1#,42.6 X 24.6 |
1 | ||
| 55539-95J0006 |
BU67,72..DYN..TR;BU66..DYN..TR..CBU;BU72..DYN..DMP..IV3;BU66..DYN..(IV3,IV4);BU60,61,68,70,74,78,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J00B0 |
BU73..03S;BU6#,70,72,74,78,8#,9# GRAY,TRIM1# |
1 | ||
| 55539-95J00B0 |
BU66..TR..CBU;BU72..DMP..IV3;BU66,68..IV3,IV4;BU60,61,67,7#,8#,9#..TR,V GRAY,TRIM1#,42.6 X 24.6 |
2 | ||
| 55539-95J00B0 |
BU66,72..TR..CBU;BU66,68,72..IV3,IV4;BU60,61,67,70,73,74,78,8#,9#..TR,V GRAY,TRIM1# |
2 | ||
| 55539 - COVER, SPARE SWITCH HOLE | ||||
| 55539-95J0006 |
BU67..DYN..4FC;BU67,72..DYN..TR;BU66..DYN..TR..CBU;BU72..DYN..DMP..IV3;BU66..DYN..(IV3,IV4);BU60,61,68,70,74,78,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J0006 |
BU6#,70,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J0006 |
BU6#,7#,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
1 | ||
| 55539-95J00B0 |
BU73..03S;BU6#,70,72,74,78,8#,9# GRAY,TRIM1#,42.6 X 24.6 |
1 | ||
| 55539-95J0006 |
BU67,72..DYN..TR;BU66..DYN..TR..CBU;BU72..DYN..DMP..IV3;BU66..DYN..(IV3,IV4);BU60,61,68,70,74,78,8#,9#..DYN BROWN,TRIM4#,42.6 X 24.6 |
2 | ||
| 55539-95J00B0 |
BU73..03S;BU6#,70,72,74,78,8#,9# GRAY,TRIM1# |
1 | ||
| 55539-95J00B0 |
BU66..TR..CBU;BU72..DMP..IV3;BU66,68..IV3,IV4;BU60,61,67,7#,8#,9#..TR,V GRAY,TRIM1#,42.6 X 24.6 |
2 | ||
| 55539-95J00B0 |
BU66,72..TR..CBU;BU66,68,72..IV3,IV4;BU60,61,67,70,73,74,78,8#,9#..TR,V GRAY,TRIM1# |
2 | ||
| 55541B - RETAINER, RADIO TUNER OPENING, NO.1 | ||||
| 55541-95407 |
BU6#,7#,8#,9# |
1 | ||
| 55542B - RETAINER, RADIO TUNER OPENING, NO.2 | ||||
| 55542-95408 |
BU78,85,88,9# |
1 | ||
| 55557B - STOPPER, GLOVE COMPERTMENT DOOR CHECK | ||||
| 55557-9540001 |
BU6#,7#,8#,9#..DYN BLACK,TRIM4# |
2 | ||
| 55557-9540001 |
BU6#,7#,8#,9# BLACK,TRIM1# |
2 | ||
| 55561A - STRIKER, GLOVE COMPARTMENT DOOR LOCK | ||||
| 55561-9540101 |
BU6#,7#,8#,9#..DYN BLACK,TRIM4# |
1 | ||
| 55561-9540101 |
BU6#,7#,8#,9# BLACK,TRIM1# |
1 | ||
| 55581A - COMPARTMENT, GLOVE | ||||
| 55581-9540001 |
BU6#,7#,8#,9#..DYN BLACK,TRIM4# |
1 | ||
| 55581-9540001 |
BU6#,7#,8#,9# BLACK,TRIM1# |
1 | ||
| 55611 - TRAY, INSTRUMENT PANEL UNDER | ||||
| 55611-26010 |
BU6#,7#,8#,9# |
1 | ||
| 55620 - HOLDER ASSY, INSTRUMENT PANEL CUP | ||||
| 55620-37010 |
BU6#,7#,8#,9# |
1 | ||
| 55650 - REGISTER ASSY, INSTRUMENT PANEL, NO.1 | ||||
| 55650-26010B0 |
BU6#,7#,8#,9# GRAY,TRIM1# |
2 | ||
| 55650-9540001 |
BU6#,7#,8#,9#..DYN BLACK,TRIM4# |
2 | ||
| 55650 - REGISTER ASSY, INSTRUMENT PANEL, NO.1 | ||||
| 55650-26010B0 |
BU6#,7#,8#,9# GRAY,TRIM1# |
2 | ||
| 55650-9540001 |
BU6#,7#,8#,9#..DYN BLACK,TRIM4# |
2 | ||
| 55660 - REGISTER ASSY, INSTRUMENT PANEL, NO.2 | ||||
| 55650-9540101 |
BU78,85,88,9#..DYN BLACK,TRIM4# |
1 | ||
| 55650-37010B0 |
BU78,88,9# GRAY,TRIM1# |
1 | ||
| 55670 - REGISTER ASSY, INSTRUMENT PANEL, NO.3 | ||||
| 55670-9540101 |
BU78,85,88,9#..DYN BLACK,TRIM4# |
1 | ||
| 55670-37010B0 |
BU78,88,9# GRAY,TRIM1# |
1 | ||
| 55905E - KNOB SUB-ASSY, CONTROL | ||||
| 55905-1205001 |
BU6#,7#,8#,9#..DYN BLACK,TRIM4# |
1 | ||
| 55905-37010B0 |
BU6#,7#,8#,9# GRAY,TRIM1# |
1 | ||
| 55950B - NOZZLE ASSY, DEFROSTER, RH | ||||
| 55950-95010 |
BU6#,7#,8#,9# |
1 | ||
| 55953A - REGISTER, DEFROSTER, CENTER | ||||
| 55953-95410 |
BU78,85,88,9# |
1 | ||
| 55960 - NOZZLE ASSY, DEFLOSTER, LH | ||||
| 55960-95010 |
BU6#,7#,8#,9# |
1 | ||
| Common parts | ||||
| 90119-06257 | ||||
| 90159-50150 | ||||
| 90159-50168 | ||||
| 90159-50172 | ||||
| 90159-50174 | ||||
| 90159-60077 | ||||
| 90167-50021 | ||||
| 90168-50026 | ||||
| 90179-05095 | ||||
| 90183-05103 | ||||
| 90468-04036 | ||||
| 91656-40820 | ||||
| 91656-40825 | ||||
| 93249-55016 | ||||
| 93510-55016 | ||||
| 93560-15016 | ||||
| 93560-55016 | ||||
| 93568-15012 | ||||
| 93568-55018 | ||||
| Linked diagrams | ||||
| 7455 | ||||
| 8302 | ||||
Part Price Details
Loading price information...
Part Number:
Price:
