BU84-MDFTJ3 (1988)
Toyota Dyna/Toyoace
ILLUST NO. 1 OF 2(8808- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 67913 - PLATE, FRONT DOOR SCUFF, RH | ||||
| 67913-95403B0 |
BU6#,7#,8#,9# GRAY,TRIM1# |
1 | ||
| 67913-9540304 |
BU6#,72,74,78,8#,9#..TOY BLUE,TRIM8# |
1 | ||
| 67914 - PLATE, FRONT DOOR SCUFF, LH | ||||
| 67914-95403B0 |
BU6#,7#,8#,9# GRAY,TRIM1# |
1 | ||
| 67914-9540304 |
BU6#,72,74,78,8#,9#..TOY BLUE,TRIM8# |
1 | ||
| 67914 - PLATE, FRONT DOOR SCUFF, LH | ||||
| 67914-95403B0 |
BU6#,7#,8#,9# GRAY,TRIM1# |
1 | ||
| 67914-9540304 |
BU6#,72,74,78,8#,9#..TOY BLUE,TRIM8# |
1 | ||
| Common parts | ||||
| 90189-05055 | ||||
| 93560-55016 | ||||
ILLUST NO. 2 OF 2(8808- )DMP,TR
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55211 - SILENCER, FRONT PANEL | ||||
| 55211-95404 |
BU6#,70,72,73,74,83,84,87 |
1 | ||
| 55211 - SILENCER, FRONT PANEL | ||||
| 55211-95404 |
BU6#,70,72,73,74,83,84,87 |
1 | ||
| 55211 - SILENCER, FRONT PANEL | ||||
| 55211-95404 |
BU6#,70,72,73,74,83,84,87 |
1 | ||
| 55213A - PAD, DASH PANEL SILENCER | ||||
| 55213-95401 |
BU6#,70,72,73,74,83,84,87 100 X 60 X 15 |
1 | ||
| 55213-95400 |
BU6#,70,72,73,74,83,84,87 130 X 70 X 25 |
1 | ||
| 55213A - PAD, DASH PANEL SILENCER | ||||
| 55213-95401 |
BU6#,70,72,73,74,83,84,87 100 X 60 X 15 |
1 | ||
| 55213-95400 |
BU6#,70,72,73,74,83,84,87 130 X 70 X 25 |
1 | ||
| 58288 - SEAL, SHIFT LEVER BOOT | ||||
| 58288-95400 |
BU6#,70,78,8#,9# |
1 | ||
| 58509B - MAT SUB-ASSY, SEAT FLOOR | ||||
| 58509-9546804 |
BU6#,83,84,87..TOY..03S BLUE,TRIM8# |
1 | ||
| 58509-37030B0 |
BU60,61,66,67,84,87..(TR,V)..03S 2ｻﾞｾｷ ｼ-ﾄ,GRAY,TRIM1# |
1 | ||
| 58509-95468B0 |
BU6#,83,84,87..03S GRAY,TRIM1# |
1 | ||
| 58509B - MAT SUB-ASSY, SEAT FLOOR | ||||
| 58509-9546804 |
BU6#,83,84,87..TOY..03S BLUE,TRIM8# |
1 | ||
| 58509-37030B0 |
BU60,61,66,67,84,87..(TR,V)..03S 2ｻﾞｾｷ ｼ-ﾄ,GRAY,TRIM1# |
1 | ||
| 58509-95468B0 |
BU6#,83,84,87..03S GRAY,TRIM1# |
1 | ||
| 58509B - MAT SUB-ASSY, SEAT FLOOR | ||||
| 58509-9546804 |
BU6#,83,84,87..TOY..03S BLUE,TRIM8# |
1 | ||
| 58509-37030B0 |
BU60,61,66,67,84,87..(TR,V)..03S 2ｻﾞｾｷ ｼ-ﾄ,GRAY,TRIM1# |
1 | ||
| 58509-95468B0 |
BU6#,83,84,87..03S GRAY,TRIM1# |
1 | ||
| 58510B - MAT, FRONT FLOOR, FRONT | ||||
| 58510-95B4104 |
BU6#,83,84,87..TOY BLUE,TRIM8# |
1 | ||
| 58510-95B4104 |
BU67..TOY..(DM4,T3);BU60,61,66,68,83,84,87..TOY BLUE,TRIM8# |
1 | ||
| 58510-95B41B0 |
BU67..DM4,T3;BU60,61,66,68,70,83,84,87..DSL GRAY,TRIM1# |
1 | ||
| 58515C - MAT, FRONT FLOOR, REAR NO.1 | ||||
| 58515-9540404 |
BU6#,72,74,78,8#,9#..TOY BLUE,TRIM8# |
1 | ||
| 58515-95404B0 |
BU6#,7#,8#,9# GRAY,TRIM1# |
1 | ||
| 58520F - MAT ASSY, ENGINE COVER | ||||
| 58520-9541004 |
BU6#,83,84,87..TOY BLUE,TRIM8# |
1 | ||
| 58520-95410B0 |
BU6#,70,83,84,87 GRAY,TRIM1# |
1 | ||
| 58520F - MAT ASSY, ENGINE COVER | ||||
| 58520-9541004 |
BU6#,83,84,87..TOY BLUE,TRIM8# |
1 | ||
| 58520-95410B0 |
BU6#,70,83,84,87 GRAY,TRIM1# |
1 | ||
| 58540C - MAT ASSY, FLOOR, REAR | ||||
| 58540-9541004 |
BU6#,83,84,87..TOY BLUE,TRIM8# |
1 | ||
| 58540-9540904 |
BU6#,83,84,87..TOY ｱﾘ(ｻｽﾍﾟﾝｼﾖﾝ ｼ-ﾄ),BLUE,TRIM8# |
1 | ||
| 58540-95410B0 |
BU6#,70,83,84,87 GRAY,TRIM1# |
1 | ||
| 58540-95409B0 |
BU6#,70,83,84,87..CBU,IV3 ｱﾘ(ｻｽﾍﾟﾝｼﾖﾝ ｼ-ﾄ),GRAY,TRIM1# |
1 | ||
| 58540C - MAT ASSY, FLOOR, REAR | ||||
| 58540-9541004 |
BU6#,83,84,87..TOY BLUE,TRIM8# |
1 | ||
| 58540-9540904 |
BU6#,83,84,87..TOY ｱﾘ(ｻｽﾍﾟﾝｼﾖﾝ ｼ-ﾄ),BLUE,TRIM8# |
1 | ||
| 58540-95410B0 |
BU6#,70,83,84,87 GRAY,TRIM1# |
1 | ||
| 58540-95409B0 |
BU6#,70,83,84,87..CBU,IV3 ｱﾘ(ｻｽﾍﾟﾝｼﾖﾝ ｼ-ﾄ),GRAY,TRIM1# |
1 | ||
| Common parts | ||||
| 90159-40041 | ||||
| 90189-04013 | ||||
| 90530-04007 | ||||
| 90530-06001 | ||||
| 90530-24002 | ||||
ILLUST NO. 2 OF 2(8808- )V
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55211 - SILENCER, FRONT PANEL | ||||
| 55211-95404 |
BU6#,70,72,73,74,83,84,87 |
1 | ||
| 55213A - PAD, DASH PANEL SILENCER | ||||
| 55213-95401 |
BU6#,70,72,73,74,83,84,87 100 X 60 X 15 |
1 | ||
| 55213-95400 |
BU6#,70,72,73,74,83,84,87 130 X 70 X 25 |
1 | ||
| 55213A - PAD, DASH PANEL SILENCER | ||||
| 55213-95401 |
BU6#,70,72,73,74,83,84,87 100 X 60 X 15 |
1 | ||
| 55213-95400 |
BU6#,70,72,73,74,83,84,87 130 X 70 X 25 |
1 | ||
| 58288 - SEAL, SHIFT LEVER BOOT | ||||
| 58288-95400 |
BU6#,70,78,8#,9# |
1 | ||
| 58509B - MAT SUB-ASSY, SEAT FLOOR | ||||
| 58509-9546804 |
BU6#,83,84,87..TOY..03S BLUE,TRIM8# |
1 | ||
| 58509-37030B0 |
BU60,61,66,67,84,87..(TR,V)..03S 2ｻﾞｾｷ ｼ-ﾄ,GRAY,TRIM1# |
1 | ||
| 58509-95468B0 |
BU6#,83,84,87..03S GRAY,TRIM1# |
1 | ||
| 58510B - MAT, FRONT FLOOR, FRONT | ||||
| 58510-95B4104 |
BU6#,83,84,87..TOY BLUE,TRIM8# |
1 | ||
| 58510-95B4104 |
BU67..TOY..(DM4,T3);BU60,61,66,68,83,84,87..TOY BLUE,TRIM8# |
1 | ||
| 58510-95B41B0 |
BU67..DM4,T3;BU60,61,66,68,70,83,84,87..DSL GRAY,TRIM1# |
1 | ||
| 58515C - MAT, FRONT FLOOR, REAR NO.1 | ||||
| 58515-9540404 |
BU6#,72,74,78,8#,9#..TOY BLUE,TRIM8# |
1 | ||
| 58515-95404B0 |
BU6#,7#,8#,9# GRAY,TRIM1# |
1 | ||
| 58520F - MAT ASSY, ENGINE COVER | ||||
| 58520-9541004 |
BU6#,83,84,87..TOY BLUE,TRIM8# |
1 | ||
| 58520-95410B0 |
BU6#,70,83,84,87 GRAY,TRIM1# |
1 | ||
| 58540C - MAT ASSY, FLOOR, REAR | ||||
| 58540-9541004 |
BU6#,83,84,87..TOY BLUE,TRIM8# |
1 | ||
| 58540-9540904 |
BU6#,83,84,87..TOY ｱﾘ(ｻｽﾍﾟﾝｼﾖﾝ ｼ-ﾄ),BLUE,TRIM8# |
1 | ||
| 58540-95410B0 |
BU6#,70,83,84,87 GRAY,TRIM1# |
1 | ||
| 58540-95409B0 |
BU6#,70,83,84,87..CBU,IV3 ｱﾘ(ｻｽﾍﾟﾝｼﾖﾝ ｼ-ﾄ),GRAY,TRIM1# |
1 | ||
| Common parts | ||||
| 90159-40041 | ||||
| 90189-04013 | ||||
| 90530-04007 | ||||
| 90530-06001 | ||||
| 93530-14014 | ||||
