BU84-MDFT3 (1988)
Toyota Dyna/Toyoace
(8808- )DYN
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 53001 - RADIATOR GRILLE SET | ||||
| 53001-95401 |
BU6#,70,83,84,87..DYN *** |
1 | ||
| 53001-95403 |
BU74,83,84,87..DYN..TR..IV3 ***,ﾒﾂｷ & ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) |
1 | ||
| 53001-37070 |
BU87..DYN..T3..20T..CBU;BU74,83,84,87..DYN..TR..IV3 ***,ﾒﾂｷ & ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) |
1 | ||
| 53001-95401 |
BU74,83,84,87..DYN..TR..IV3 ***,ﾒﾂｷ |
1 | ||
| 53001-37050 |
BU87..DYN..T3..20T..CBU;BU74,83,84,87..DYN..TR..IV3 ***,ﾒﾂｷ |
1 | ||
| 53001-37070 |
BU74,83,84,87..DYN..TR..IV3 ***,ﾒﾂｷ & ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) |
1 | ||
| 53001-37050 |
BU74,84,87..DYN..TR..IV3 ***,ﾒﾂｷ & ﾅｼ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) |
1 | ||
| 53001-37070 |
BU74,84,87..DYN..TR..IV3 ***,ﾒﾂｷ |
1 | ||
| 53105B - GARNISH SUB-ASSY, RADIATOR GRILLE | ||||
| 53105-95410 |
BU6#,70,72,73,74,83,84,87..DYN BEIGE M |
1 | ||
| 53105-37040E0 |
BU87..V;BU73..DYN..20T;BU87..DYN..T4..5F;BU73..DYN..30T..IV3;BU87..DYN..(T2,T3,TW1);BU72..DYN..(DM4,DM5,T3,T4);BU6#,74,83,84..DYN..(CBU,IV3) GRAY M,048 ,705 |
1 | ||
| 53105-95412 |
BU73..DYN..(CBU,IV3);BU6#,70,72,74,83,84,87..DYN..DSL ﾒﾂｷ |
1 | ||
| 53105-95411 |
BU6#,70,72,73,74,83,84,87..DYN GRAY M |
1 | ||
| 53111 - GRILLE, RADIATOR | ||||
| 53111-95423 |
BU6#,70,72,73,74,83,84,87..DYN GRAY M |
1 | ||
| 53111-95421 |
BU6#,70,72,73,74,83,84,87..DYN BEIGE M |
1 | ||
| 53111-95425 |
BU73..DYN..(CBU,IV3);BU6#,70,72,74,83,84,87..DYN..DSL ﾒﾂｷ |
1 | ||
| 53111-37030E0 |
BU87..V;BU73..DYN..20T;BU87..DYN..T4..5F;BU73..DYN..30T..IV3;BU87..DYN..(T2,T3,TW1);BU72..DYN..(DM4,DM5,T3,T4);BU6#,74,83,84..DYN..(CBU,IV3) GRAY M,048 ,705 |
1 | ||
| 53112B - GRILLE, RADIATOR SIDE, RH | ||||
| 53112-95408 |
BU6#,70,72,74,83,84,87..DYN ﾒﾂｷ |
1 | ||
| 53112-95407 |
BU83,84..DYN..IV3;BU88..DYN..T4..5F..IV3 TECS=ﾊﾞﾝ ｹｲ ｼﾔ,GRAY M |
1 | ||
| 53112-95405 |
BU83,84..DYN..IV3;BU88..DYN..T4..5F..IV3 TECS=ﾊﾞﾝ ｹｲ ｼﾔ,BEIGE M |
1 | ||
| 53112-95409 |
BU74,83,84,87..DYN..TR..IV3 ﾒﾂｷ & ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) |
1 | ||
| 53112-95406 |
BU6#,7#,8#,90,91..DYN GRAY M |
1 | ||
| 53112-95405 |
BU83,84..DYN..IV3 ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) OR TECS=ﾊﾞﾝ ｹｲ ｼﾔ,BEIGE M |
1 | ||
| 53112-95404 |
BU6#,7#,8#,90,91..DYN BEIGE M |
1 | ||
| 53112-37020H0 |
BU87..DYN..T3..20T..CBU;BU88..DYN..T4..30T..IV3;BU88..DYN..(T2,T3,TW1)..IV3;BU88..DYN..T4..5F..20T..IV3;BU88..DYN..T3..30T..DSL..CBU;BU74,83,84,87,91..DYN..TR..IV3;BU88..DYN..(T3,T4)..5F..20T..DSL..CBU ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ),TURCUOISE,705 |
1 | ||
| 53112-37020A0 |
BU88..T4..5F..20T;BU87..T3..20T..CBU;BU88..T4..30T..IV3;BU88..(T2,T3,TW1)..IV3;BU74,83,84,87,91..TR..IV3;BU88..T3..5F..(20T,30T)..DSL..CBU ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ),WHITE,048 |
1 | ||
| 53112-95409 |
BU88..DYN..T4..30T..IV3;BU88..DYN..(T2,T3,TW1)..IV3;BU74,83,84,87,91..DYN..TR..IV3 ﾒﾂｷ & ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) |
1 | ||
| 53112-95408 |
BU73..DYN..(CBU,IV3);BU6#,70,72,74,78,8#,91..DYN ﾒﾂｷ |
1 | ||
| 53112-95407 |
BU83,84..DYN..IV3 ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) OR TECS=ﾊﾞﾝ ｹｲ ｼﾔ,GRAY M |
1 | ||
| 53112-37010A0 |
BU6#,7#,8#,91..CBU,IV3 WHITE,048 |
1 | ||
| 53112-95409 |
BU87..DYN..T3..20T..CBU;BU88..DYN..T4..30T..IV3;BU88..DYN..(T2,T3,TW1)..IV3;BU88..DYN..T4..5F..20T..IV3;BU88..DYN..T3..30T..DSL..CBU;BU74,83,84,87,91..DYN..TR..IV3;BU88..DYN..(T3,T4)..5F..20T..DSL..CBU ﾒﾂｷ & ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) |
1 | ||
| 53112-37020H0 |
BU88..DYN..T4..30T..IV3;BU88..DYN..(T2,T3,TW1)..IV3;BU88..DYN..T4..5F..20T..IV3;BU74,83,84,87,91..DYN..TR..IV3 ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ),TURCUOISE,705 |
1 | ||
| 53112-37020A0 |
BU88..T4..5F..IV3;BU88..4FC..30T..IV3;BU88..(T2,T3,TW1)..IV3;BU74,83,84,87,91..TR..IV3 ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ),WHITE,048 |
1 | ||
| 53112-95409 |
BU88..DYN..T4..30T..IV3;BU88..DYN..(T2,T3,TW1)..IV3;BU88..DYN..T4..5F..20T..IV3;BU74,83,84,87,91..DYN..TR..IV3 ﾒﾂｷ & ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) |
1 | ||
| 53112-37010A0 |
BU74,8#,91..TR..IV3 ﾅｼ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ),WHITE,048 |
1 | ||
| 53112-37010H0 |
BU74,8#,91..DYN..TR..IV3 ﾅｼ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ),TURCUOISE,705 |
1 | ||
| 53112-37010H0 |
BU73..DYN..20T;BU73..DYN..30T..IV3;BU6#,72,74,78,8#,91..DYN..(CBU,IV3) TURCUOISE,705 |
1 | ||
| 53112-37020A0 |
BU94,96;BU74,8#,91..TR..IV3 WHITE,048 |
1 | ||
| 53112-37020H0 |
BU94,96..DYN;BU74,8#,91..DYN..TR..IV3 TURCUOISE,705 |
1 | ||
| 53112-95408 |
BU74,8#,91..DYN..TR..IV3 ﾅｼ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) & ﾒﾂｷ |
1 | ||
| 53112-95409 |
BU94,96..DYN;BU74,8#,91..DYN..TR..IV3 ﾒﾂｷ & ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ);ﾒﾂｷ |
1 | ||
| 53113B - GRILLE, RADIATOR SIDE, LH | ||||
| 53113-95407 |
BU83,84..DYN..IV3;BU88..DYN..T4..5F..IV3 TECS=ﾊﾞﾝ ｹｲ ｼﾔ,BEIGE M |
1 | ||
| 53113-95406 |
BU6#,7#,8#,90,91..DYN BEIGE M |
1 | ||
| 53113-95409 |
BU83,84..DYN..IV3;BU88..DYN..T4..5F..IV3 TECS=ﾊﾞﾝ ｹｲ ｼﾔ,GRAY M |
1 | ||
| 53113-95410 |
BU6#,70,72,74,83,84,87..DYN ﾒﾂｷ |
1 | ||
| 53113-95411 |
BU74,83,84,87..DYN..TR..IV3 ﾒﾂｷ &ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) |
1 | ||
| 53113-95409 |
BU83,84..DYN..IV3 ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) OR TECS=ﾊﾞﾝｹｲ ｼﾔ,GRAY M |
1 | ||
| 53113-37020H0 |
BU87..DYN..T3..20T..CBU;BU88..DYN..T4..30T..IV3;BU88..DYN..(T2,T3,TW1)..IV3;BU88..DYN..T4..5F..20T..IV3;BU88..DYN..T3..30T..DSL..CBU;BU74,83,84,87,91..DYN..TR..IV3;BU88..DYN..(T3,T4)..5F..20T..DSL..CBU ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ),TURCUOISE,705 |
1 | ||
| 53113-95411 |
BU87..DYN..T3..20T..CBU;BU88..DYN..T4..30T..IV3;BU88..DYN..(T2,T3,TW1)..IV3;BU88..DYN..T4..5F..20T..IV3;BU88..DYN..T3..30T..DSL..CBU;BU74,83,84,87,91..DYN..TR..IV3;BU88..DYN..(T3,T4)..5F..20T..DSL..CBU ﾒﾂｷ &ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) |
1 | ||
| 53113-95411 |
BU88..DYN..T4..30T..IV3;BU88..DYN..(T2,T3,TW1)..IV3;BU74,83,84,87,91..DYN..TR..IV3 ﾒﾂｷ &ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) |
1 | ||
| 53113-95407 |
BU83,84..DYN..IV3 ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) OR TECS=ﾊﾞﾝｹｲ ｼﾔ,BEIGE M |
1 | ||
| 53113-95408 |
BU6#,7#,8#,90,91..DYN GRAY M |
1 | ||
| 53113-37020A0 |
BU88..T4..5F..20T;BU87..T3..20T..CBU;BU88..T4..30T..IV3;BU88..(T2,T3,TW1)..IV3;BU74,83,84,87,91..TR..IV3;BU88..T3..5F..(20T,30T)..DSL..CBU ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ),WHITE,048 |
1 | ||
| 53113-37010H0 |
BU60,61,67,68,72,74,78,8#,91..DYN TURCUOISE,705 |
1 | ||
| 53113-37010A0 |
BU6#,7#,8#,91..CBU,IV3 WHITE,048 |
1 | ||
| 53113-37020H0 |
BU88..DYN..T4..30T..IV3;BU88..DYN..(T2,T3,TW1)..IV3;BU88..DYN..T4..5F..20T..IV3;BU74,83,84,87,91..DYN..TR..IV3 ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ),TURCUOISE,705 |
1 | ||
| 53113-95410 |
BU6#,72,74,78,8#,91..DYN ﾒﾂｷ |
1 | ||
| 53113-37010A0 |
BU74,8#,91..TR..IV3 ﾅｼ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ),WHITE,048 |
1 | ||
| 53113-95411 |
BU88..DYN..T4..30T..IV3;BU88..DYN..(T2,T3,TW1)..IV3;BU88..DYN..T4..5F..20T..IV3;BU74,83,84,87,91..DYN..TR..IV3 ﾒﾂｷ &ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) |
1 | ||
| 53113-37020A0 |
BU88..T4..5F..IV3;BU88..4FC..30T..IV3;BU88..(T2,T3,TW1)..IV3;BU74,83,84,87,91..TR..IV3 ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ),WHITE,048 |
1 | ||
| 53113-37010H0 |
BU74,8#,91..DYN..TR..IV3 ﾅｼ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ),TURCUOISE,705 |
1 | ||
| 53113-37020A0 |
BU94,96;BU74,8#,91..TR..IV3 WHITE,048 |
1 | ||
| 53113-37020H0 |
BU94,96..DYN;BU74,8#,91..DYN..TR..IV3 TURCUOISE,705 |
1 | ||
| 53113-95410 |
BU74,8#,91..DYN..TR..IV3 ﾅｼ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) & ﾒﾂｷ |
1 | ||
| 53113-95411 |
BU94,96..DYN;BU74,8#,91..DYN..TR..IV3 ﾒﾂｷ & ｱﾘ(ｻｲﾄﾞ ﾘﾌﾚｸﾀ) |
1 | ||
| 53116B - BRACKET, RADIATOR GRILLE, NO.2 | ||||
| 53116-95403 |
BU6#,70,72,73,74,83,84,87 |
1 | ||
| 53117B - BRACKET, RADIATOR GRILLE, LOWER | ||||
| 53117-95404 |
BU6#,70,72,73,74,83,84,87 |
1 | ||
| Common parts | ||||
| 62955-95700 | ||||
| 90105-08120 | ||||
| 90159-50214 | ||||
| 90179-08123 | ||||
| 90189-06018 | ||||
| 90467-09044 | ||||
| 90467-11023 | ||||
| 90467-13011 | ||||
| 90467-13041 | ||||
| 93540-75020 | ||||
| 93540-85016 | ||||
(9905-0206)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90159-60339 | ||||
| 90163-50011 | ||||
| 90189-05046 | ||||
| 90467-10161 | ||||
