BU82-MDPDT (1984)
Toyota Dyna/Toyoace
Production
Sep 1984
-
Aug 1987
Engine
13B
Transmission
Displacement
2500cc
Power
168 HP (125 kW)
ILLUST NO. 1 OF 2(8409- )BU80,81,82
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 65026 - BRACKET SUB-ASSY, GATE RUBBER BUMPER, RH | ||||
| 65026-92801 |
BU77,82 |
1 | ||
| 65026-92802 |
BU77,82 |
1 | ||
| 65027 - BRACKET SUB-ASSY, GATE RUBBER BUMPER, LH | ||||
| 65027-92801 |
BU77,82 |
1 | ||
| 65027-92802 |
BU77,82 |
1 | ||
| 65303A - FRAME SUB-ASSY, FLOOR SIDE, RH | ||||
| 65303-92817 |
BU82..06S |
1 | ||
| 65304A - FRAME SUB-ASSY, FLOOR SIDE, LH | ||||
| 65304-92818 |
BU82..06S |
1 | ||
| 65307 - BRACKET SUB-ASSY, GUAD FRAME, RH | ||||
| 65207-92801 |
BU82,85..06S |
1 | ||
| 65308 - BRACKET SUB-ASSY, GUAD FRAME, LH | ||||
| 65208-92702 |
BU82..06S |
1 | ||
| 65339 - FRAME, FLOOR, REAR | ||||
| 65339-92703 |
BU80,81,82 |
1 | ||
| 65339-92702 |
BU80,81,82 |
1 | ||
| 66010 - FENDER ASSY, REAR BODY, REAR RH | ||||
| 66210-92704 |
BU82..20T |
1 | ||
| 66020 - FENDER ASSY, REAR BODY, REAR LH | ||||
| 66220-92704 |
BU82..20T |
1 | ||
| 66210 - FENDER ASSY, REAR BODY, FRONT RH | ||||
| 66010-92702 |
BU82..20T |
1 | ||
| 66213 - STAY, REAR FENDER FRONT PLATE | ||||
| 66236-92702 |
BU82,85..06S |
2 | ||
| 66219A - EXTENSION, REAR FENDER | ||||
| 66219-92702 |
BU64,82..TR..20T |
2 | ||
| 66220 - FENDER ASSY, REAR BODY, FRONT LH | ||||
| 66020-92702 |
BU82..20T |
1 | ||
| 66223 - STAY, REAR FENDER REAR PLATE | ||||
| 66235-92701 |
BU82,85..06S |
2 | ||
| 66241 - MUDGUARD, REAR | ||||
| 66241-92808 |
BU77,8#..DYN..(T3,T4,TW1) RH |
1 | ||
| 66241-92803 |
BU77,8#..DYN..(T3,T4,TW1) LH |
1 | ||
| 66242 - PLATE, REAR MUDGUARD SET RETAINER | ||||
| 66242-92707 |
BU77,8#..T3,T4,TW1 LH |
1 | ||
| 66242-92805 |
BU77,8#..T3,T4,TW1 RH |
1 | ||
| Common parts | ||||
| 65321-92700 | ||||
| 90119-06272 | ||||
| 90119-06273 | ||||
| 90149-80008 | ||||
| 90151-80002 | ||||
| 90151-80007 | ||||
| 90159-60281 | ||||
| 90201-08019 | ||||
| 90541-07019 | ||||
| 91616-40614 | ||||
| 91621-40614 | ||||
| 93313-16014 | ||||
| 93590-16016 | ||||
| 94180-40800 | ||||
ILLUST NO. 2 OF 2(8409- )
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 66311A - HOOK, ROPE, NO.1 | ||||
| 66311-92801 |
BU77,8#,90,93,95..TR TYPE A |
1 | ||
| 66312-92802 |
BU77,8#,90,93,95..TR TYPE B |
1 | ||
| 66313-92801 |
BU77,8#,90,93,95..TR TYPE C |
1 | ||
