BU62-PDD (1984)

Toyota Dyna/Toyoace

Production Sep 1984 - Aug 1987
Engine 13B
Transmission
Displacement 2500cc
Power 168 HP (125 kW)

(8409- )BU64..T3 ; (8409- )BU85..T2 ; (8409- )BU60,61,62,80,81..T2,T4,TW1,

Click highlighted areas on diagram

diagram 66418 66418 66418B 6644195A01 6644195A01 6644195A01 9017910081 9017910081 9020110320 9020110320 9020110320 9020110320 9020111369 9020111369 9056410167 9056410167 9056410167 9056410167 9411041000 9411041000 9411041000 9411041000 9411041000 9411041000 9411041000 9411041000
Part # Description Qty Price
Common parts
66441-95A01
90179-10081
90201-10320
90201-11369
90564-10167
94110-41000

(8409- )BU60,61,62..T3

Click highlighted areas on diagram

diagram 66464A 66464A 66465A 66466A 66466B 66466C 66466C 66471A 66481 66482 9161161025 9165141025 9321018020 9411041000 9411041000 9411541200 9411541200 9411541200 9411541200 9411541200 9411541200 9411541200 9411541200 9461211000 9461211200
Part # Description Qty Price
66464A - PLATE, U BOLT
66466-92580

BU60,61,62..T3..ST

COLD SPEC

 2
66466-92580

BU60,61,62..T3..20T

 4
66464A - PLATE, U BOLT
66466-92580

BU60,61,62..T3..ST

COLD SPEC

 2
66466-92580

BU60,61,62..T3..20T

 4
66465A - PROTECTOR, U BOLT
66465-92700

BU60,61,62..T3..ST

 2
66466A - BOLT, U, NO.1
66461-92820

BU60,61,62..T3..ST

 2
66466B - BOLT, U, NO.2
90117-12021

BU60,61,62..T3..ST

 2
66466C - BOLT, U, NO.3
66463-92707

BU60,61,62..T3..ST

COLD SPEC

 2
66462-92820

BU60,61,62..T3..ST

 2
66466C - BOLT, U, NO.3
66463-92707

BU60,61,62..T3..ST

COLD SPEC

 2
66462-92820

BU60,61,62..T3..ST

 2
66471A - REINFORCEMENT, FRAME U BOLT
66471-92701

BU60,61,62..T3..20T

L=135

 2
66481 - BRACE, SILL TO FRAME, RH
66446-92701

BU60,61,62..T3..20T

 1
66482 - BRACE, SILL TO FRAME, LH
66446-92701

BU60,61,62..T3..20T

 1
Common parts
91611-61025
91651-41025
93210-18020
94110-41000
94115-41200
94612-11000
94612-11200
