BU301-PSMJS3 (1999)
Toyota Dyna/Toyoace
(9905-0406)BU30#,346
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 78010A - BUSH (FOR ACCELERATOR LINK) | ||||
| 90386-08065 |
XZU301,302,341,342..CNG,LPG;BU30#,346,BZU300,340,RZU30#,340,XZU300,320,330,340,350 |
2 | ||
| 78010A - BUSH (FOR ACCELERATOR LINK) | ||||
| 90386-08065 |
XZU301,302,341,342..CNG,LPG;BU30#,346,BZU300,340,RZU30#,340,XZU300,320,330,340,350 |
2 | ||
| 78100 - LINK ASSY, ACCELERATOR | ||||
| 78100-37600 |
BU30#,346 |
1 | ||
| 78110A - SPRING (FOR ACCELERATOR PEDAL ROD) | ||||
| 90959-03243 |
BU30#,346,XZU300,320,330,340,350 |
1 | ||
| 90959-03243 |
XZU301,302,341,342..CNG,LPG;BU30#,346,BZU300,340,RZU30#,340 |
1 | ||
| 78111 - PEDAL, ACCELERATOR | ||||
| 78110-95410 |
BU30#,346,BZU300,340,RZU30#,340,XZU300,301,302,306,307,31#,32#,33#,340,341,342,346,347,35#,362,37#,382 |
1 | ||
| 78117 - CUSHION (FOR ACCELERATOR ROD) | ||||
| 90541-06038 |
BU30#,346,BZU300,340,RZU30#,340,XZU300,301,302,306,307,31#,32#,33#,340,341,342,346,347,35#,362,37#,382 |
1 | ||
| 90541-06036 |
BU30#,346,RZU300,340,XZU30#,31#,32#,33#,34#,35#,362,37#,382 |
1 | ||
| 78150C - WIRE ASSY, ACCELERATOR FLEXIBLE | ||||
| 78150-37470 |
BU30#,346 |
1 | ||
| 78150-37471 |
BU30#,346 |
1 | ||
| 78150-37472 |
BU30#,346 |
1 | ||
| 78183B - CLAMP, ACCELERATOR CONTROL CABLE | ||||
| 78183-37300 |
BU30#,346,RZU300,340;XZU301,302,341,342..CNG,LPG TYPE E:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37260 |
BU30#,346,RZU30#,340 TYPE A:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37300 |
BU30#,346,RZU30#,340..DCB,SCB TYPE E:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37290 |
BU306,346;BU301..DM6,T1,T5 TYPE C:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183B - CLAMP, ACCELERATOR CONTROL CABLE | ||||
| 78183-37300 |
BU30#,346,RZU300,340;XZU301,302,341,342..CNG,LPG TYPE E:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37260 |
BU30#,346,RZU30#,340 TYPE A:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37300 |
BU30#,346,RZU30#,340..DCB,SCB TYPE E:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37290 |
BU306,346;BU301..DM6,T1,T5 TYPE C:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183B - CLAMP, ACCELERATOR CONTROL CABLE | ||||
| 78183-37300 |
BU30#,346,RZU300,340;XZU301,302,341,342..CNG,LPG TYPE E:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37260 |
BU30#,346,RZU30#,340 TYPE A:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37300 |
BU30#,346,RZU30#,340..DCB,SCB TYPE E:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37290 |
BU306,346;BU301..DM6,T1,T5 TYPE C:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183B - CLAMP, ACCELERATOR CONTROL CABLE | ||||
| 78183-37300 |
BU30#,346,RZU300,340;XZU301,302,341,342..CNG,LPG TYPE E:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37260 |
BU30#,346,RZU30#,340 TYPE A:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37300 |
BU30#,346,RZU30#,340..DCB,SCB TYPE E:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37290 |
BU306,346;BU301..DM6,T1,T5 TYPE C:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183B - CLAMP, ACCELERATOR CONTROL CABLE | ||||
| 78183-37300 |
BU30#,346,RZU300,340;XZU301,302,341,342..CNG,LPG TYPE E:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37260 |
BU30#,346,RZU30#,340 TYPE A:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37300 |
BU30#,346,RZU30#,340..DCB,SCB TYPE E:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78183-37290 |
BU306,346;BU301..DM6,T1,T5 TYPE C:ｲﾗｽﾄｻﾝｼﾖｳ |
1 | ||
| 78189 - BOLT, ACCELERATOR PEDAL STOPPER | ||||
| 78208-37060 |
XZU301,302,341,342..CNG,LPG;BU30#,346,BZU300,340,RZU30#..CNG,DSL,LPG |
1 | ||
| 78190 - CABLE ASSY, ACCEL CONTROL W/THROTTLE | ||||
| 78190-37010 |
XZU301,302,341,342..CNG,LPG;BU30#,346,BZU300,340,RZU30#,XZU300,320,330,340,350..CNG,DSL,LPG |
1 | ||
| 78410D - NUT, THROTTLE | ||||
| 78314-95010 |
XZU301,302,341,342..CNG,LPG;BU30#,346,BZU300,340,RZU30#,XZU300,320,330,340,350..CNG,DSL,LPG |
1 | ||
| 78411A - KNOB, THROTTLE CONTROL CABLE | ||||
| 78411-95J01 |
XZU301,302,341,342..CNG,LPG;BU30#,346,BZU300,340,RZU30#,XZU300,320,330,340,350..CNG,DSL,LPG |
1 | ||
| Common parts | ||||
| 90119-06899 | ||||
| 90170-10054 | ||||
| 90464-00731 | ||||
| 90468-06063 | ||||
| 91631-J0612 | ||||
| 91651-B0616 | ||||
| 91651-B0814 | ||||
| 94130-00602 | ||||
ILLUST NO. 3 OF 3(7708- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90461-08008 | ||||
| 90461-08109 | ||||
| 90461-08240 | ||||
| 90461-08269 | ||||
| 90461-08271 | ||||
| 90461-08279 | ||||
| 90461-08280 | ||||
| 90461-08523 | ||||
| 90461-10128 | ||||
| 90461-10310 | ||||
| 90461-10317 | ||||
| 90461-10318 | ||||
| 90461-10332 | ||||
| 90461-10383 | ||||
| 90461-10866 | ||||
| 90462-10046 | ||||
| 90462-10062 | ||||
| 90463-10337 | ||||
| 90463-12005 | ||||
| 90463-12011 | ||||
| 90463-15298 | ||||
| 90464-00020 | ||||
| 90464-00034 | ||||
| 90468-08001 | ||||
| 90480-01053 | ||||
| 90959-01024 | ||||
| 90959-01026 | ||||
| 91611-40816 | ||||
| 91615-40816 | ||||
| 91651-40614 | ||||
| 91651-40820 | ||||
| 93385-16016 | ||||
| 93386-15014 | ||||
| 94110-40800 | ||||
ILLUST NO. 1 OF 3(7708- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90386-08077 | ||||
| 90541-06008 | ||||
| 90541-11001 | ||||
| 91131-40660 | ||||
| 91611-40614 | ||||
| 94110-40600 | ||||
| 94611-10800 | ||||
| 95381-02015 | ||||
