YS130-AEMRP (1987)
Toyota Crown
(8709- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85035-3004008 |
GS13#,LS13#,MS13#,YS130..SED,V,WG WHITE,040 |
2 | ||
| 85035-3004001 |
GS130,LS130,YS130..STD BLACK,103 ,202 ,606 |
2 | ||
| 85035-3004001 |
GS130,LS130,YS130..STD BLACK,103 ,202 ,606 |
2 | ||
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85035-3004008 |
GS13#,LS13#,MS13#,YS130..SED,V,WG WHITE,040 |
2 | ||
| 85035-3004001 |
GS130,LS130,YS130..STD BLACK,103 ,202 ,606 |
2 | ||
| 85035-3004001 |
GS130,LS130,YS130..STD BLACK,103 ,202 ,606 |
2 | ||
| 85310 - MOTOR AND PUMP ASSY, WINDSHIELD WASHER | ||||
| 85310-30070 |
GS13#,LS13#,MS13#,YS130 |
1 | ||
| 85330 - JAR ASSY, WINDSHIELD WASHER | ||||
| 85331-30260 |
GS13#,LS13#,MS13#,YS130 |
1 | ||
| 85330A - BUSH, WINDSHIELD WASHER JAR | ||||
| 90099-32089 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| 85332 - CAP, WINDSHIELD WASHER JAR | ||||
| 85332-12320 |
GS13#,LS13#,MS13#,YS130 |
1 | ||
| 85339 - CAP SUB-ASSY, RESERVE TANK | ||||
| 85339-30260 |
GS13#,LS13#,MS13#,YS130 |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85349-89122 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 NO.2 |
1 | ||
| 85348-12250 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 NO.3 |
1 | ||
| 85338-16020 |
GS13#,LS13#,MS13#,YS130 NO.1 |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85349-89122 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 NO.2 |
1 | ||
| 85348-12250 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 NO.3 |
1 | ||
| 85338-16020 |
GS13#,LS13#,MS13#,YS130 NO.1 |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85349-89122 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 NO.2 |
1 | ||
| 85348-12250 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 NO.3 |
1 | ||
| 85338-16020 |
GS13#,LS13#,MS13#,YS130 NO.1 |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85349-89122 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 NO.2 |
1 | ||
| 85348-12250 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 NO.3 |
1 | ||
| 85338-16020 |
GS13#,LS13#,MS13#,YS130 NO.1 |
1 | ||
| 85360 - BRACKET ASSY, WINDSHIELD WASHER | ||||
| 85361-30270 |
GS13#,MS13#,YS130 NO.1 |
1 | ||
| 88688-3A100 |
GS13#,LS13#,MS130,YS130..DLX,SAL,SALEX,SDX,SPE,SSL,STD NO.2 |
1 | ||
| 85360 - BRACKET ASSY, WINDSHIELD WASHER | ||||
| 85361-30270 |
GS13#,MS13#,YS130 NO.1 |
1 | ||
| 88688-3A100 |
GS13#,LS13#,MS130,YS130..DLX,SAL,SALEX,SDX,SPE,SSL,STD NO.2 |
1 | ||
| 85369 - CLAMP | ||||
| 85369-30270 |
GS13#,MS13#,YS130 |
1 | ||
| 85371 - HOSE, WINDSHIELD WASHER (FROM MOTOR TO JOINT) | ||||
| 90099-33299 |
GS13#,LS13#,MS13#,YS130 長さ=1000 |
1 | ||
| 85372 - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.1 | ||||
| 90099-33080 |
GS13#,LS13#,MS13#,YS130 L=1450 |
1 | ||
| 85373 - HOSE, WINDSHIELD WASHER (FROM JOINT TO NOZZLE) | ||||
| 90099-33080 |
GS131..SED..ROY;GS131..HT..(ROY,SALEX,SSL)..NOB;GS136,MS135..(DLX,ROY,SDX,STD)..(EFI,TWC);GS130,LS130,136,MS130,137,YS130..DSL,EFI,HTWC,LPG,SPC,TD,TDE,TWC L=1450,NO.2 |
1 | ||
| 90099-33080 |
GS13#,LS13#,MS13#,YS130 L=1450,NO.1 |
1 | ||
| 85373 - HOSE, WINDSHIELD WASHER (FROM JOINT TO NOZZLE) | ||||
| 90099-33080 |
GS131..SED..ROY;GS131..HT..(ROY,SALEX,SSL)..NOB;GS136,MS135..(DLX,ROY,SDX,STD)..(EFI,TWC);GS130,LS130,136,MS130,137,YS130..DSL,EFI,HTWC,LPG,SPC,TD,TDE,TWC L=1450,NO.2 |
1 | ||
| 90099-33080 |
GS13#,LS13#,MS13#,YS130 L=1450,NO.1 |
1 | ||
| Common parts | ||||
| 82711-10270 | ||||
| 85373-30010 | ||||
| 90959-01116 | ||||
| 91656-40816 | ||||
| 93385-18016 | ||||
| Linked diagrams | ||||
| 1603 | ||||
