LS131-ATPJJ (1989)

Toyota Crown

Production Aug 1989 - Oct 1991
Engine 2LTHE
Transmission 4FC ATM
Displacement 2500cc
Power 168 HP (125 kW)

(8908- )

Click highlighted areas on diagram

diagram 16361A 88310A
Part # Description Qty Price
16361A - BELT, V(FOR FAN & ALTERNATOR)
90916-02132

2L,2LT#..LS13#

 1
90916-02209

2L,2LT#..LS13#

 1
88310A - BELT, V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY), NO.1
99322-01230

LS130,131..(HT,SED)..(SALEX,SDX,SPE,SSL)

MITUBOSI

 1
99322-51230

LS130,131..(HT,SED)..(SALEX,SDX,SPE,SSL)

BANDO

 1
