LS131-ATMSX (1989)
Toyota Crown
(8908- )LS13#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 21960 - WIRE ASSY, ACCELERATOR LINK | ||||
| 21960-54011 |
2L,2LT..LS13#..MTM |
1 | ||
| 21960-54030 |
2L,2LT..LS13# |
1 | ||
| 78010B - SPRING, TORSION (FOR ACCELERATOR LINK) | ||||
| 90508-16053 |
LS13#..DSL,TD |
1 | ||
| 90508-16010 |
LS13#..DSL,TD |
1 | ||
| 78024 - BRACKET SUB-ASSY, ACCELERATOR CONTROL CABLE | ||||
| 78024-30041 |
LS13# |
1 | ||
| 78024-30140 |
LS13#..DSL,TD |
1 | ||
| 78024-30141 |
LS13#..DSL,TD |
1 | ||
| 78024 - BRACKET SUB-ASSY, ACCELERATOR CONTROL CABLE | ||||
| 78024-30041 |
LS13# |
1 | ||
| 78024-30140 |
LS13#..DSL,TD |
1 | ||
| 78024-30141 |
LS13#..DSL,TD |
1 | ||
| 78100 - LINK ASSY, ACCELERATOR | ||||
| 78100-30570 |
LS13#..DSL,TD |
1 | ||
| 78100-30490 |
LS13#..DSL,TD |
1 | ||
| 78104 - ROD SUB-ASSY, ACCELERATOR CONNECTING, NO.2 | ||||
| 78104-30120 |
LS13#..DSL,TD |
1 | ||
| 78104-22140 |
LS13#..DSL,TD |
1 | ||
| 78111 - PEDAL, ACCELERATOR | ||||
| 78111-30090 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78111-30080 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| 78111 - PEDAL, ACCELERATOR | ||||
| 78111-30090 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78111-30080 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| 78111A - SPRING (FOR ACCELERATOR PEDAL) | ||||
| 90508-18071 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78111C - PIN (FOR ACCELERATOR PEDAL) | ||||
| 90249-05043 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78114A - BRACKET, ACCELERATOR PEDAL SUPPORT | ||||
| 78114-30050 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| 78120A - SPRING, COMPRESSION (FOR ACCELERATOR LINK ROD) | ||||
| 90508-18066 |
LS13#;GS130,131,MS13#..ATM |
1 | ||
| 90508-23101 |
LS13#;GS130,131,MS13#..ATM ｶﾝﾚｲﾁ ｼﾖｳ |
2 | ||
| 90508-23026 |
GS130,131,MS13#,UZS131..ATM;GS130,LS13#..MTM..(DSL,TD,TWLPG) ｶﾝﾚｲﾁ ｼﾖｳ |
2 | ||
| 90508-23026 |
GS130,LS13#..MTM..(DSL,TD,TWLPG);GS130,131,JZS13#,MS13#,UZS131..ATM ｶﾝﾚｲﾁ ｼﾖｳ |
2 | ||
| 78120A - SPRING, COMPRESSION (FOR ACCELERATOR LINK ROD) | ||||
| 90508-18066 |
LS13#;GS130,131,MS13#..ATM |
1 | ||
| 90508-23101 |
LS13#;GS130,131,MS13#..ATM ｶﾝﾚｲﾁ ｼﾖｳ |
2 | ||
| 90508-23026 |
GS130,131,MS13#,UZS131..ATM;GS130,LS13#..MTM..(DSL,TD,TWLPG) ｶﾝﾚｲﾁ ｼﾖｳ |
2 | ||
| 90508-23026 |
GS130,LS13#..MTM..(DSL,TD,TWLPG);GS130,131,JZS13#,MS13#,UZS131..ATM ｶﾝﾚｲﾁ ｼﾖｳ |
2 | ||
| 78120G - ROD ASSY, ACCELERATOR PEDAL | ||||
| 78120-30540 |
GS130,131..ATM..(EFI,TWC);GS131,LS13#..(DLX,SALEX,SDX,SPE,SSL,STD)..(DSL,SPC,TD,TDE) ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78120-30550 |
GS130,131..ATM..(EFI,TWC);GS131,LS13#..(DLX,SALEX,SDX,SPE,SSL,STD)..(DSL,SPC,TD,TDE) |
1 | ||
| 78120-30541 |
LS13#..MTM;GS131..SSL..SPC;GS131..ATM..(HTWC,TWC);GS130,MS135,UZS131..ATM..(DLX,ROYG,SALEX,SDX)..(HTWC,TWC) ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78120-30730 |
JZS13#,LS13#..ATM ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78120-30541 |
LS136..MTM;GS131..SSL..SPC;GS131..ATM..(HTWC,TWC);JZS13#,LS130,131,UZS131..DSL,HTWC,TD,TWC;GS130,MS135..ATM..(DLX,SALEX,SDX)..(HTWC,TWC) ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78120G - ROD ASSY, ACCELERATOR PEDAL | ||||
| 78120-30540 |
GS130,131..ATM..(EFI,TWC);GS131,LS13#..(DLX,SALEX,SDX,SPE,SSL,STD)..(DSL,SPC,TD,TDE) ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78120-30550 |
GS130,131..ATM..(EFI,TWC);GS131,LS13#..(DLX,SALEX,SDX,SPE,SSL,STD)..(DSL,SPC,TD,TDE) |
1 | ||
| 78120-30541 |
LS13#..MTM;GS131..SSL..SPC;GS131..ATM..(HTWC,TWC);GS130,MS135,UZS131..ATM..(DLX,ROYG,SALEX,SDX)..(HTWC,TWC) ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78120-30730 |
JZS13#,LS13#..ATM ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78120-30541 |
LS136..MTM;GS131..SSL..SPC;GS131..ATM..(HTWC,TWC);JZS13#,LS130,131,UZS131..DSL,HTWC,TD,TWC;GS130,MS135..ATM..(DLX,SALEX,SDX)..(HTWC,TWC) ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78139A - SEAL, ACCELERATOR PEDAL ROD BRACKET, NO.2 | ||||
| 78139-30060 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| 78139A - SEAL, ACCELERATOR PEDAL ROD BRACKET, NO.2 | ||||
| 78139-30060 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| 78180P - CABLE ASSY, ACCELERATOR CONTROL | ||||
| 78180-30740 |
LS13# |
1 | ||
| 78180-30820 |
LS13# |
1 | ||
| 78180-30821 |
LS131,136 |
1 | ||
| 78183B - CLAMP, ACCELERATOR CONTROL CABLE | ||||
| 78183-30090 |
GS130,131,LS13#,MS13#,YS130..DSL,LPG,SPC,TD,TDE,TWC |
1 | ||
| 78183-30070 |
GS13#,JZS13#,LS13#,MS135,YS130 |
1 | ||
| 78186 - SUPPORT, ACCELERATOR CONTROL CABLE, NO.1 | ||||
| 78186-22040 |
LS130,131..TD NO.1 |
1 | ||
| 78186-30090 |
LS130,131..TD NO.2 |
1 | ||
| 78186 - SUPPORT, ACCELERATOR CONTROL CABLE, NO.1 | ||||
| 78186-22040 |
LS130,131..TD NO.1 |
1 | ||
| 78186-30090 |
LS130,131..TD NO.2 |
1 | ||
| 78472 - SUPPORT, THROTTLE CONTROL CABLE | ||||
| 78472-35010 |
LS13#..DSL,TD |
1 | ||
| Common parts | ||||
| 90119-08714 | ||||
| 90202-08028 | ||||
| 90202-10005 | ||||
| 90386-08077 | ||||
| 90386-10138 | ||||
| 90541-06002 | ||||
| 91111-40620 | ||||
| 91611-G0814 | ||||
| 91615-60614 | ||||
| 91621-F0812 | ||||
| 91666-40635 | ||||
| 94110-40600 | ||||
| 94141-41030 | ||||
| 94511-31000 | ||||
| 94611-10800 | ||||
| 94611-31001 | ||||
| 95381-02015 | ||||
| 95381-02518 | ||||
| 96160-00400 | ||||
