Toyota Crown LS130 EXHAUST PIPE - JDM Part Detective

Part #	Description	Period	Qty
17410 - PIPE ASSY, EXHAUST, FRONT
17410-54420	2L..LS130	09/1987 - 08/1989	1
17410-54880	2L..LS130	08/1989 - 10/1991	1
17410A - NUT, EXHAUST PIPE SET STUD BOLT
90179-10070	1GE,1GFE,1GG#,1JZGE,2L,2LT#,7MGE,MP..GS13#,JZS13#,LS13#,MS13#	09/1987 - 10/1991	3
17410B - GASKET, EXHAUST PIPE
90917-06004	2L,3YP..LS13#,YS130	09/1987 - 08/1989	1
90917-06042	2L,2LT#..LS13#	12/1990 - 10/1991	1
90917-06005	2L,2LT#..LS13#	08/1989 - 12/1990	1
17410E - CLAMP NO.1, EXHAUST PIPE FRONT (FOR FRONT)
90917-04007	2L..LS130,136	09/1987 - 10/1991	1
17410F - BOLT OR RING, EXHAUST PIPE FRONT (FOR FRONT)
90117-08016	2L..LS130,136	09/1987 - 10/1991	1
17430 - PIPE ASSY, EXHAUST, TAIL
17430-54880	2L..LS130	09/1987 - 01/1990	1
17430-54881	2L..LS130	01/1990 - 10/1991	1
17430 - PIPE ASSY, EXHAUST, TAIL
17430-54880	2L..LS130	09/1987 - 01/1990	1
17430-54881	2L..LS130	01/1990 - 10/1991	1
17430S - BRACKET, EXHAUST TAIL PIPE (FOR REAR)
17575-54010	2L,2LT#..LS130	09/1987 - 10/1991	1
17430V - BOLT OR RING, EXHAUST TAIL PIPE (FOR REAR)
90301-34207	1GE,1GGP,1GGZE,1JZGE,2L,2LT#,MP..GS130,JZS130,LS130,136,MS130	09/1987 - 10/1991	2
17430V - BOLT OR RING, EXHAUST TAIL PIPE (FOR REAR)
90301-34207	1GE,1GGP,1GGZE,1JZGE,2L,2LT#,MP..GS130,JZS130,LS130,136,MS130	09/1987 - 10/1991	2
17430V - BOLT OR RING, EXHAUST TAIL PIPE (FOR REAR)
90301-34207	1GE,1GGP,1GGZE,1JZGE,2L,2LT#,MP..GS130,JZS130,LS130,136,MS130	09/1987 - 10/1991	2
17430V - BOLT OR RING, EXHAUST TAIL PIPE (FOR REAR)
90301-34207	1GE,1GGP,1GGZE,1JZGE,2L,2LT#,MP..GS130,JZS130,LS130,136,MS130	09/1987 - 10/1991	2
17451 - GASKET, EXHAUST PIPE
90917-06039	2L..LS130,136	12/1990 - 10/1991	1
90917-06039	2L..LS130,136	09/1987 - 12/1990	1
17505E - SUPPORT SUB-ASSY, CATALYTIC CONVERTER
17505-54010	2L,2LT#..LS130	09/1987 - 10/1991	1
17565A - SUPPORT, EXHAUST PIPE, NO.4
17565-63020	2L,3YP..LS13#,YS130 NO.1	09/1987 - 08/1989	2
17565-45010	2L,3YP..LS13#,YS130 NO.2	09/1987 - 08/1989	2
17565-63020	2L,3YPE..LS130,136,YS130 NO.2	08/1989 - 10/1991	2
17565-45010	2L,3YPE..LS130,136,YS130 NO.1	08/1989 - 10/1991	2
17565A - SUPPORT, EXHAUST PIPE, NO.4
17565-63020	2L,3YP..LS13#,YS130 NO.1	09/1987 - 08/1989	2
17565-45010	2L,3YP..LS13#,YS130 NO.2	09/1987 - 08/1989	2
17565-63020	2L,3YPE..LS130,136,YS130 NO.2	08/1989 - 10/1991	2
17565-45010	2L,3YPE..LS130,136,YS130 NO.1	08/1989 - 10/1991	2
17565A - SUPPORT, EXHAUST PIPE, NO.4
17565-63020	2L,3YP..LS13#,YS130 NO.1	09/1987 - 08/1989	2
17565-45010	2L,3YP..LS13#,YS130 NO.2	09/1987 - 08/1989	2
17565-63020	2L,3YPE..LS130,136,YS130 NO.2	08/1989 - 10/1991	2
17565-45010	2L,3YPE..LS130,136,YS130 NO.1	08/1989 - 10/1991	2
17565A - SUPPORT, EXHAUST PIPE, NO.4
17565-63020	2L,3YP..LS13#,YS130 NO.1	09/1987 - 08/1989	2
17565-45010	2L,3YP..LS13#,YS130 NO.2	09/1987 - 08/1989	2
17565-63020	2L,3YPE..LS130,136,YS130 NO.2	08/1989 - 10/1991	2
17565-45010	2L,3YPE..LS130,136,YS130 NO.1	08/1989 - 10/1991	2
17571 - BRACKET, EXHAUST PIPE SUPPORT, NO.1
17571-54010	2L..LS130,136..MTM	08/1989 - 10/1991	1
17571-54010	2L..LS13#..MTM	09/1987 - 08/1989	1
17572B - BRACKET, EXHAUST PIPE SUPPORT, NO.2
17572-54090	2L,3YP#..LS130,136,YS130 NO.1	09/1987 - 10/1991	1
17573 - BRACKET, EXHAUST PIPE NO.1 SUPPORT, LOWER
17573-41040	1GE,1GFE,1GG#,1JZGE,2L,2LT#,7MGE,MP,3YP#..GS130,131,JZS131,LS130,131,MS13#,YS130..HT,SED	09/1987 - 10/1991	1
17591A - STOPPER, EXHAUST PIPE SUPPORT
17591-36010	1GE,1GG#,2L,2LT#,7MGE,MP,3YP..GS130,131,LS130,MS13#,YS130..HT,SED	09/1987 - 02/1988	1
17591-36011	1GE,1GFE,1GG#,1JZGE,2L,2LT#,7MGE,MP,3YP#..GS130,131,JZS131,LS130,131,MS13#,YS130..HT,SED	02/1988 - 10/1991	1
17591A - STOPPER, EXHAUST PIPE SUPPORT
17591-36010	1GE,1GG#,2L,2LT#,7MGE,MP,3YP..GS130,131,LS130,MS13#,YS130..HT,SED	09/1987 - 02/1988	1
17591-36011	1GE,1GFE,1GG#,1JZGE,2L,2LT#,7MGE,MP,3YP#..GS130,131,JZS131,LS130,131,MS13#,YS130..HT,SED	02/1988 - 10/1991	1
Common parts
90105-10023
90159-50207
91621-60825
91651-40614
91651-40616
91651-40816
91651-40820
91659-61230
93319-15010
93382-15012
94180-40800
94180-41000

LS130-AEMFS (1987)

(8709- )2L

(9110-9409)2L
