LS120-SEPFT (1983)
Toyota Crown
ILLUST NO. 3 OF 3(8308- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-08164 | ||||
| 90179-08143 | ||||
| 90389-06003 | ||||
| 90506-08006 | ||||
| 90506-12035 | ||||
| 91611-40616 | ||||
| 91611-60814 | ||||
| 94543-01000 | ||||
| Linked diagrams | ||||
| 8511 | ||||
ILLUST NO. 1 OF 3(8308-8408)HT,SED..SDX,SPE ; (8408- )HT,SED..DLX,SDX,SPE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE) | ||||
| 71075-3088005 |
GS120,LS120..SED..SDX FB,BEIGE,BEIGE,TRIM4# |
1 | ||
| 71075-3088004 |
GS120,LS120,MS120..SED..SDX FB,BEIGE,BLUE,TRIM4# |
1 | ||
| 71075W - WIRE, REAR SEAT CUSHION COVER | ||||
| 90580-20079 |
GS120,LS120,MS120,YS120..SED..(DLX,SDX,STD) L=960 |
2 | ||
| 90580-20105 |
GS120,LS120,MS120,YS120..SED..(DLX,SDX,STD) L=250 |
2 | ||
| 90580-20097 |
GS120,LS120,MS120,YS120..SED..(DLX,SDX,STD) L=1050 |
1 | ||
| 90580-29003 |
GS120,LS120,MS120,YS120..SED..(DLX,SDX,STD) L=300 |
2 | ||
| 71075W - WIRE, REAR SEAT CUSHION COVER | ||||
| 90580-20079 |
GS120,LS120,MS120,YS120..SED..(DLX,SDX,STD) L=960 |
2 | ||
| 90580-20105 |
GS120,LS120,MS120,YS120..SED..(DLX,SDX,STD) L=250 |
2 | ||
| 90580-20097 |
GS120,LS120,MS120,YS120..SED..(DLX,SDX,STD) L=1050 |
1 | ||
| 90580-29003 |
GS120,LS120,MS120,YS120..SED..(DLX,SDX,STD) L=300 |
2 | ||
| 71077B - COVER, REAR SEAT BACK (FOR BENCH TYPE) | ||||
| 71077-3A04004 |
GS120,LS120,MS120..SED..SDX FB,BEIGE,BLUE,TRIM4# |
1 | ||
| 71077-3A04005 |
GS120,LS120..SED..SDX FB,BEIGE,BEIGE,TRIM4# |
1 | ||
| 71077W - WIRE, REAR SEAT BACK COVER | ||||
| 90580-20015 |
GS120,LS120,MS120..SED..SDX L=900 |
2 | ||
| 90580-20020 |
GS120,LS120,MS120..SED..SDX L=420 |
2 | ||
| 90580-20122 |
GS120,LS120,MS120..SED..SDX L=200 |
2 | ||
| 90580-20130 |
GS120,LS120,MS120..SED..SDX L=700 |
2 | ||
| 90580-20168 |
GS120,LS120,MS120..SED..SDX L=1300 |
1 | ||
| 90580-20136 |
GS120,LS120,MS120..SED..SDX L=80 |
2 | ||
| 90580-29003 |
GS120,LS120,MS120..SED..SDX L=300 |
2 | ||
| 90580-29013 |
GS120,LS120,MS120..SED..SDX L=400 |
2 | ||
| 71077W - WIRE, REAR SEAT BACK COVER | ||||
| 90580-20015 |
GS120,LS120,MS120..SED..SDX L=900 |
2 | ||
| 90580-20020 |
GS120,LS120,MS120..SED..SDX L=420 |
2 | ||
| 90580-20122 |
GS120,LS120,MS120..SED..SDX L=200 |
2 | ||
| 90580-20130 |
GS120,LS120,MS120..SED..SDX L=700 |
2 | ||
| 90580-20168 |
GS120,LS120,MS120..SED..SDX L=1300 |
1 | ||
| 90580-20136 |
GS120,LS120,MS120..SED..SDX L=80 |
2 | ||
| 90580-29003 |
GS120,LS120,MS120..SED..SDX L=300 |
2 | ||
| 90580-29013 |
GS120,LS120,MS120..SED..SDX L=400 |
2 | ||
| 71460B - CUSHION ASSY, REAR SEAT (FOR BENCH TYPE) | ||||
| 71560-3020005 |
GS120,LS120..SED..SDX FB,BEIGE,BEIGE,TRIM4# |
1 | ||
| 71560-3020004 |
GS120,LS120,MS120..SED..SDX FB,BLUE,BLUE,TRIM8# |
1 | ||
| 71480B - BACK ASSY, REAR SEAT (FOR BENCH TYPE) | ||||
| 71480-3A11004 |
GS120,LS120,MS120..SED..SDX FB,BLUE,BLUE,TRIM8# |
1 | ||
| 71480-3A11005 |
GS120,LS120..SED..SDX FB,BEIGE,BEIGE,TRIM4# |
1 | ||
| 71611 - PAD, REAR SEAT CUSHION | ||||
| 71611-30500 |
GS120,LS120,MS120..SED..(SAL,SDX) |
1 | ||
| 71650 - SPRING ASSY, REAR SEAT CUSHION | ||||
| 71650-30280 |
GS120,LS120,MS120,YS120..SED |
1 | ||
| 71651B - PAD, REAR SEAT BACK(FOR BENCH TYPE) | ||||
| 71507-30040 |
GS120,LS120,MS120..SED..SDX |
1 | ||
| 71670 - SPRING ASSY, REAR SEAT BACK(FOR BENCH SEAT) | ||||
| 71670-30320 |
GS120,LS120,MS120..SED..SDX |
1 | ||
| 71812B - CLIP(FOR REAR SEAT CUSHION COVER) | ||||
| 90468-18071 |
GS12#,LS12#,MS12#,YS120 |
1 | ||
| 71812B - CLIP(FOR REAR SEAT CUSHION COVER) | ||||
| 90468-18071 |
GS12#,LS12#,MS12#,YS120 |
1 | ||
| 71953 - PAD, REAR SEAT HEADREST | ||||
| 71953-30070 |
GS120,LS120,MS120,YS120..SED..(DLX,SDX,STD) |
2 | ||
| 71953 - PAD, REAR SEAT HEADREST | ||||
| 71953-30070 |
GS120,LS120,MS120,YS120..SED..(DLX,SDX,STD) |
2 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-30011 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
2 | ||
| 72830 - ARMREST ASSY, REAR SEAT, CENTER | ||||
| 72830-3016005 |
GS120,LS120..SED..SDX BEIGE,BEIGE,TRIM4# |
1 | ||
| 72830-3016004 |
GS120,LS120,MS120..SED..SDX BLUE,BLUE,TRIM8# |
1 | ||
| 72830B - BUSH(FOR REAR SEAT CENTER ARMREST) | ||||
| 90386-06009 |
GS120,121,LS120,MS12#..(HT,SED)..(ROY,SAL,SDX,SPE) LH |
1 | ||
| 90386-06002 |
GS120,121,LS120,MS12#..(HT,SED)..(ROY,SAL,SDX,SPE) RH |
1 | ||
| 72830B - BUSH(FOR REAR SEAT CENTER ARMREST) | ||||
| 90386-06009 |
GS120,121,LS120,MS12#..(HT,SED)..(ROY,SAL,SDX,SPE) LH |
1 | ||
| 90386-06002 |
GS120,121,LS120,MS12#..(HT,SED)..(ROY,SAL,SDX,SPE) RH |
1 | ||
| Common parts | ||||
| 90119-06100 | ||||
| 90119-08164 | ||||
| 90468-12070 | ||||
ILLUST NO. 2 OF 3(8308- )HT,SED
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71621A - PAD, REAR SEAT CUSHION SILENCER, A | ||||
| 71621-30240 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
2 | ||
| 71621A - PAD, REAR SEAT CUSHION SILENCER, A | ||||
| 71621-30240 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
2 | ||
| 71621A - PAD, REAR SEAT CUSHION SILENCER, A | ||||
| 71621-30240 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
2 | ||
| 71621A - PAD, REAR SEAT CUSHION SILENCER, A | ||||
| 71621-30240 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
2 | ||
| 71621A - PAD, REAR SEAT CUSHION SILENCER, A | ||||
| 71621-30240 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
2 | ||
| 71621A - PAD, REAR SEAT CUSHION SILENCER, A | ||||
| 71621-30240 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
2 | ||
| 71621A - PAD, REAR SEAT CUSHION SILENCER, A | ||||
| 71621-30240 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
2 | ||
| 71621A - PAD, REAR SEAT CUSHION SILENCER, A | ||||
| 71621-30240 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
2 | ||
| 71624A - PAD, REAR SEAT CUSHION SILENCER, D | ||||
| 71523-30020 |
GS120,LS120,MS120,YS120..SED |
2 | ||
| 71624A - PAD, REAR SEAT CUSHION SILENCER, D | ||||
| 71523-30020 |
GS120,LS120,MS120,YS120..SED |
2 | ||
| 71624A - PAD, REAR SEAT CUSHION SILENCER, D | ||||
| 71523-30020 |
GS120,LS120,MS120,YS120..SED |
2 | ||
| 71624A - PAD, REAR SEAT CUSHION SILENCER, D | ||||
| 71523-30020 |
GS120,LS120,MS120,YS120..SED |
2 | ||
| 71624A - PAD, REAR SEAT CUSHION SILENCER, D | ||||
| 71523-30020 |
GS120,LS120,MS120,YS120..SED |
2 | ||
| 71624A - PAD, REAR SEAT CUSHION SILENCER, D | ||||
| 71523-30020 |
GS120,LS120,MS120,YS120..SED |
2 | ||
| 71662 - PAD, REAR SEAT BACK, UPPER B | ||||
| 71662-30110 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
1 | ||
| 71662 - PAD, REAR SEAT BACK, UPPER B | ||||
| 71662-30110 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
1 | ||
| 71667A - PAD, REAR SEAT BACK, CENTER A | ||||
| 71667-30020 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
1 | ||
| 71667A - PAD, REAR SEAT BACK, CENTER A | ||||
| 71667-30020 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
1 | ||
| 71681 - PAD, REAR SEAT BACK CORNER, A | ||||
| 71681-30020 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
2 | ||
| 71681 - PAD, REAR SEAT BACK CORNER, A | ||||
| 71681-30020 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
2 | ||
| 71681 - PAD, REAR SEAT BACK CORNER, A | ||||
| 71681-30020 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
2 | ||
| 71681 - PAD, REAR SEAT BACK CORNER, A | ||||
| 71681-30020 |
GS120,121,LS120,MS120,YS120..(HT,SED)..(DLX,SAL,SDX,SPE,SSL,STD) |
2 | ||
