JZS135-AEPUF (1991)
Toyota Crown
(9110- )1JZGE,2JZGE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11011 - WASHER SET, CRANKSHAFT THRUST | ||||
| 11011-46030 |
1JZGE,2JZGE..JZS13# STD |
1 | ||
| 11702 - BEARING SET, CRANKSHAFT | ||||
| 11704-46020 |
1JZGE,2JZGE..JZS13# U/S 0.25 |
1 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.1 |
1 | ||
| 11701-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.2 |
6 | ||
| 11701-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.2 |
6 | ||
| 11701-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.2 |
6 | ||
| 11701-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.2 |
6 | ||
| 11701-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.2 |
6 | ||
| 11071-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.1 |
1 | ||
| 11071-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.1 |
1 | ||
| 11071-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.1 |
1 | ||
| 11071-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.1 |
1 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.1 |
1 | ||
| 11701-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.2 |
6 | ||
| 11701-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.2 |
6 | ||
| 11701-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.2 |
6 | ||
| 11701-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.2 |
6 | ||
| 11701-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.2 |
6 | ||
| 11071-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.1 |
1 | ||
| 11071-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.1 |
1 | ||
| 11071-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.1 |
1 | ||
| 11071-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.1 |
1 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.1 |
1 | ||
| 11701-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.2 |
6 | ||
| 11701-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.2 |
6 | ||
| 11701-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.2 |
6 | ||
| 11701-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.2 |
6 | ||
| 11701-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.2 |
6 | ||
| 11071-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.1 |
1 | ||
| 11071-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.1 |
1 | ||
| 11071-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.1 |
1 | ||
| 11071-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.1 |
1 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.1 |
1 | ||
| 11701-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.2 |
6 | ||
| 11701-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.2 |
6 | ||
| 11701-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.2 |
6 | ||
| 11701-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.2 |
6 | ||
| 11701-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.2 |
6 | ||
| 11071-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.1 |
1 | ||
| 11071-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.1 |
1 | ||
| 11071-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.1 |
1 | ||
| 11071-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.1 |
1 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.1 |
1 | ||
| 11701-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.2 |
6 | ||
| 11701-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.2 |
6 | ||
| 11701-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.2 |
6 | ||
| 11701-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.2 |
6 | ||
| 11701-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.2 |
6 | ||
| 11071-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.1 |
1 | ||
| 11071-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.1 |
1 | ||
| 11071-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.1 |
1 | ||
| 11071-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.1 |
1 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.1 |
1 | ||
| 11701-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.2 |
6 | ||
| 11701-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.2 |
6 | ||
| 11701-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.2 |
6 | ||
| 11701-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.2 |
6 | ||
| 11701-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.2 |
6 | ||
| 11071-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.1 |
1 | ||
| 11071-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.1 |
1 | ||
| 11071-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.1 |
1 | ||
| 11071-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.1 |
1 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.1 |
1 | ||
| 11701-4601005 |
1JZGE,2JZGE..JZS13# MARK 5,NO.2 |
6 | ||
| 11701-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.2 |
6 | ||
| 11701-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.2 |
6 | ||
| 11701-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.2 |
6 | ||
| 11701-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.2 |
6 | ||
| 11071-4601003 |
1JZGE,2JZGE..JZS13# MARK 3,NO.1 |
1 | ||
| 11071-4601002 |
1JZGE,2JZGE..JZS13# MARK 2,NO.1 |
1 | ||
| 11071-4601001 |
1JZGE,2JZGE..JZS13# MARK 1,NO.1 |
1 | ||
| 11071-4601004 |
1JZGE,2JZGE..JZS13# MARK 4,NO.1 |
1 | ||
| 13011 - RING SET, PISTON | ||||
| 13011-46040 |
2JZGE..JZS133,135 STD |
1 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-4601001 |
1JZGE,2JZGE..JZS13# MARK 1 |
6 | ||
| 13041-4601005 |
1JZGE,2JZGE..JZS13# MARK 5 |
6 | ||
| 13041-4601002 |
1JZGE,2JZGE..JZS13# MARK 2 |
6 | ||
| 13041-4601003 |
1JZGE,2JZGE..JZS13# MARK 3 |
6 | ||
| 13041-4601004 |
1JZGE,2JZGE..JZS13# MARK 4 |
6 | ||
| 13101 - PISTON SUB-ASSY, W/PIN | ||||
| 13101-46030 |
2JZGE..JZS133,135 STD |
6 | ||
| 13101A - RING, HOLE SNAP(FOR PISTON PIN) | ||||
| 90521-25004 |
1JZGE,2JZGE..JZS13# |
12 | ||
| 13101A - RING, HOLE SNAP(FOR PISTON PIN) | ||||
| 90521-25004 |
1JZGE,2JZGE..JZS13# |
12 | ||
| 13201 - ROD SUB-ASSY, CONNECTING | ||||
| 13201-46040 |
2JZGE..JZS133,135 |
6 | ||
| 13201A - BUSH(FOR CONNECTING ROD SMALL END) | ||||
| 90999-73128 |
1JZGE,2JZGE..JZS13# |
6 | ||
| 13202 - BEARING SET, CONNECTING ROD | ||||
| 13204-46020 |
1JZGE,2JZGE..JZS13# U/S 0.25 |
1 | ||
| 13265 - BOLT, CONNECTING ROD | ||||
| 13265-46020 |
1JZGE,2JZGE..JZS13# |
12 | ||
| 13407 - DAMPER SUB-ASSY, CRANKSHAFT | ||||
| 13407-46020 |
2JZGE..JZS133,135 |
1 | ||
| 13411 - CRANKSHAFT | ||||
| 13401-46020 |
2JZGE..JZS133,135 |
1 | ||
| 13471A - KEY, CRANKSHAFT(FOR CRANKSHAFT PULLEY SET) | ||||
| 95161-20519 |
1JZGE,2JZGE..JZS13# |
1 | ||
| 13471C - BOLT(FOR CRANKSHAFT PULLEY SET) | ||||
| 90119-18002 |
1JZGE,2JZGE..JZS13# |
1 | ||
| 13521A - KEY(FOR CRANKSHAFT TIMING GEAR) | ||||
| 95161-20519 |
1JZGE,2JZGE..JZS13# |
1 | ||
| 13521P - PULLEY, CRANKSHAFT TIMING | ||||
| 13521-46020 |
1JZGE,2JZGE..JZS13# |
1 | ||
| 13566A - GUIDE, TIMING BELT | ||||
| 13566-46010 |
1JZGE,2JZGE..JZS13# |
1 | ||
