JZS133-AEPQF (1991)
Toyota Crown
(9110- )4FC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33058 - BRACKET SUB-ASSY, SHIFT LOCK SOLENOID | ||||
| 33058-30070 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33501G - BUSH (FOR FLOOR SHIFT CONTROL SHAFT) | ||||
| 90385-11003 |
GS13#,JZS13#,LS13#,YS130..4FC |
2 | ||
| 33501G - BUSH (FOR FLOOR SHIFT CONTROL SHAFT) | ||||
| 90385-11003 |
GS13#,JZS13#,LS13#,YS130..4FC |
2 | ||
| 33502 - PLATE SUB-ASSY, SHIFT LEVER | ||||
| 33502-30350 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33502-30360 |
JZS133..4FC ﾎﾝｺﾝ ｼﾖｳ OR ｼﾝｶﾞﾎﾟ-ﾙ ｼﾖｳ |
1 | ||
| 33502-30360 |
JZS133..4FC ﾎﾝｺﾝ ｼﾖｳ |
1 | ||
| 33502A - COLLAR (FOR FLOOR SHIFT SETTING) | ||||
| 90387-06065 |
GS13#,JZS13#,LS13#,YS130..4FC 外径=8.8 |
4 | ||
| 33503F - LEVER SUB-ASSY, SHIFT(FOR FLOOR SHIFT) | ||||
| 33055-30070 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33504F - KNOB SUB-ASSY, SHIFT LEVER | ||||
| 33542-30240E0 |
GS130,131,JZS130,131,133,LS130,131..4FC..(HTWC,TDEC,TWC) QUARTZ,TRIM4# |
1 | ||
| 33542-30230E1 |
JZS130,131,133..4FC..ROY ｱﾘ(ﾁﾙﾄ & ﾃﾚｽｺﾋﾟﾂｸ ﾃﾞﾝﾄﾞｳ ｼｷ ｴｱﾊﾞﾂｸ ﾀｲｵｳ ﾂｷ),QUARTZ,TRIM4# |
1 | ||
| 33542-30240J0 |
GS13#,JZS130,131,133,LS13#,YS130..4FC DARK BLUE,TRIM8# |
1 | ||
| 33542-30240J2 |
GS13#,JZS130,131,133,LS130,131,YS130..4FC DK.BLUE,TRIM8# |
1 | ||
| 33542-30240B0 |
JZS130,131,133..4FC..ROY SHAD0W GRAY,TRIM1# |
1 | ||
| 33542-30230J1 |
JZS130,131,133..4FC..ROY ｱﾘ(ﾁﾙﾄ & ﾃﾚｽｺﾋﾟﾂｸ ﾃﾞﾝﾄﾞｳ ｼｷ ｴｱﾊﾞﾂｸ ﾀｲｵｳ ﾂｷ),DK.BLUE,TRIM8# |
1 | ||
| 33542-30230B0 |
JZS130,131,133..4FC..ROY ｱﾘ(ﾁﾙﾄ & ﾃﾚｽｺﾋﾟﾂｸ ﾃﾞﾝﾄﾞｳ ｼｷ ｴｱﾊﾞﾂｸ ﾀｲｵｳ ﾂｷ),SHADOW,TRIM1# |
1 | ||
| 33511 - SHAFT, CONTROL (FOR FLOOR SHIFT) | ||||
| 33511-30390 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33511C - COLLAR (FOR CONTROL SHAFT) | ||||
| 90387-08142 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33542A - SCREW, W/WASHER(FOR SPRING BACK SHIFT LEVER KNOB) | ||||
| 90159-50312 |
GS13#,JZS13#,LS13#,YS130..4FC |
2 | ||
| 33550D - BULB, POSITION INDICATOR LAMP | ||||
| 99132-12034 |
GS13#,JZS13#,LS13#,YS130..4FC 12V 3.4W |
1 | ||
| 33554 - CAP, SHIFT LEVER | ||||
| 33554-30030 |
JZS133..4FC |
1 | ||
| 33555 - BOOT, SHIFT LEVER | ||||
| 33555-30161 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33563 - BUTTON, SHIFT LOCK RELEASE | ||||
| 33563-30010 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33563A - SPRING, COMPRESSION (FOR SHIFT LOCK RELEASE BUTTON) | ||||
| 90501-06058 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33569A - GUIDE, SHIFT LOCK RELEASE BUTTON | ||||
| 33569-30040 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33594 - PLATE, SHIFT LOCK (FOR FLOOR SHIFT) | ||||
| 33594-30070 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33623 - BUTTON, SHIFT LEVER KNOB | ||||
| 33623-30110E1 |
GS130,131,JZS13#,LS130,131..4FC..(HTWC,TDE,TDEC,TWC) DARK ROSE,TRIM4# |
1 | ||
| 33623-30110B0 |
JZS13#..4FC..(ROY,ROYG) SHADOW GRAY,TRIM1# |
1 | ||
| 33623-30110J0 |
GS13#,JZS13#,LS13#,YS130..4FC DARK BLUE,TRIM8# |
1 | ||
| 33623A - SPRING, COMPRESSION (FOR SHIFT LEVER KNOB BUTTON) | ||||
| 90501-07009 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33625 - SLEEVE, SHIFT LEVER KNOB | ||||
| 33625-30030 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33626 - STOPPER, SHIFT LEVER BUTTON | ||||
| 90256-02004 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33631 - ROD, DETENT | ||||
| 33631-30130 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33631A - SPRING, COMPRESSION (FOR DETENT ROD) | ||||
| 90501-08147 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33631B - PIN, SLOTTED SPRING (FOR DETENT ROD) | ||||
| 90256-02003 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33631D - PIN, GROOVED (FOR DETENT ROD) | ||||
| 90256-04003 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33635A - GUIDE, WIRE, NO.1 (FOR SHIFT LEVER) | ||||
| 33635-30100 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33675A - PIN, W/HOLE (FOR TRANSMISSION CONTROL ROD) | ||||
| 90240-08120 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33726-35010 |
GS13#,JZS13#,LS13#..4FC |
1 | ||
| 33675B - BUSH (FOR TRANSMISSION CONTROL ROD) | ||||
| 90389-08005 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33675C - GROMMET (FOR TRANSMISSION CONTROL ROD) | ||||
| 90480-17023 |
JZS13#,LS130,131..4FC |
1 | ||
| 33702B - ROD SUB-ASSY, GEAR SHIFTING, NO.1 (FOR FLOOR SHIFT) | ||||
| 33702-30310 |
JZS13#..4FC |
1 | ||
| 33723F - SWIVEL, CONNECTING ROD (FOR FLOOR SHIFT) | ||||
| 33723-22010 |
GS13#,JZS13#,LS13#..4FC |
1 | ||
| 33723-30070 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33723G - BUSH (FOR FLOOR SHIFT CONTROL SHAFT) | ||||
| 90389-08005 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 33723H - GROMMET (FOR FLOOR SHIFT CONTROL SHAFT) | ||||
| 33572-30040 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 90480-17177 |
GS13#,JZS13#,LS13#..4FC |
1 | ||
| 33886 - STOPPER, SHIFT LEVER | ||||
| 33886-30010 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 35906 - WIRE SUB-ASSY, INDICATOR LAMP | ||||
| 35906-30050 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 35921 - PLATE, CONTROL POSITION INDICATOR | ||||
| 35921-30350 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 35971A - HOUSING, POSITION INDICATOR, UPPER | ||||
| 35971-30220 |
JZS133..4FC ﾎﾝｺﾝ ｼﾖｳ |
1 | ||
| 35971-30240 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 35971-30220 |
JZS133..4FC ﾎﾝｺﾝ ｼﾖｳ OR ｼﾝｶﾞﾎﾟ-ﾙ ｼﾖｳ |
1 | ||
| 35974 - HOUSING, POSITION INDICATOR, LOWER | ||||
| 35974-30070 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 35975 - COVER, SLIDE (FOR POSITION INDICATOR) | ||||
| 35975-30180 |
GS13#,JZS13#,LS13#,YS130..4FC |
1 | ||
| 35976B - COVER, SHIFT LEVER KNOB (FOR FLOOR SHIFT) | ||||
| 35976-30060J0 |
GS13#,JZS13#,LS13#,YS130..4FC DK.BLUE,TRIM8# |
1 | ||
| 35976-30060B0 |
JZS13#..4FC..(ROY,ROYG) SHADOW GRAY,TRIM1# |
1 | ||
| 35976-30060E0 |
GS130,131,JZS13#,LS130,131..4FC..(HTWC,TDE,TDEC,TWC) QUARTZ,TRIM4# |
1 | ||
| Common parts | ||||
| 82711-14470 | ||||
| 90119-06144 | ||||
| 90179-08001 | ||||
| 90463-12570 | ||||
| 90468-14004 | ||||
| 90468-14033 | ||||
| 93315-15012 | ||||
| 93315-34012 | ||||
| 94110-40800 | ||||
| 94512-00800 | ||||
| 94613-10800 | ||||
| Linked diagrams | ||||
| 8401 | ||||
| 8410 | ||||
