JZS131-AESQF (1990)
Toyota Crown
(9008- )JZS13#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04446 - GASKET KIT, POWER STEERING PUMP | ||||
| 04446-30090 |
GS130,131,MS135,137..SPC,TWC |
1 | ||
| 04446-30110 |
JZS13# |
1 | ||
| 44302 - HOUSING SUB-ASSY, VANE PUMP, FRONT | ||||
| 44302-22061 |
JZS13# |
1 | ||
| 44302-22060 |
JZS13# |
1 | ||
| 44302-22031 |
GS130,131..TWC,TWLPG |
1 | ||
| 44302G - SEAL, OIL, NO.2(FOR VANE PUMP HOUSING) | ||||
| 90311-18008 |
GS130,131,MS135,137..SPC,TWC |
1 | ||
| 90311-17007 |
JZS13# |
1 | ||
| 44302H - RING, SNAP, NO.1(FOR VANE PUMP HOUSING) | ||||
| 90521-44002 |
JZS13#,LS13# |
1 | ||
| 90521-44002 |
JZS13#,LS13#,MS130,YS130 |
1 | ||
| 90521-32001 |
GS130,131,MS135,137..SPC,TWC,TWLPG |
1 | ||
| 44305 - CAP SUB-ASSY, VANE PUMP OIL RESERVOIR | ||||
| 44305-12010 |
GS136,LS13#,YS130;GS130,131,MS13#..DLX,ROY,ROYG,SAL,SALEX,SDX,SPE,SSL |
1 | ||
| 44308 - UNION SUB-ASSY, PRESSURE PORT | ||||
| 44308-30130 |
JZS13# |
1 | ||
| 44308-30140 |
JZS13# |
1 | ||
| 44311 - PULLEY, VANE PUMP | ||||
| 44311-30090 |
GS130,131..TWC,TWLPG |
1 | ||
| 44311-22090 |
JZS13# |
1 | ||
| 44311B - NUT(FOR VANE PUMP PULLEY) | ||||
| 90179-12022 |
GS131,136,JZS13#,MS135,137,UZS131..HTWC,SPC,TWC;GS130..(DLX,ROY,SAL,SALEX,SDX,SPE)..(HTWC,SPC,TWLPG) |
1 | ||
| 90179-12022 |
GS136,YS130;GS130,131,JZS13#,MS13#,UZS131..DLX,ROY,ROYG,SAL,SALEX,SDX,SPE,SSL |
1 | ||
| 44312 - SHAFT, VANE PUMP | ||||
| 44312-26010 |
JZS13# 外径=17.009−17.014 |
1 | ||
| 44312-12020 |
GS130,131,MS135,137..SPC,TWC,TWLPG |
1 | ||
| 44312-26020 |
JZS13# 外径=17.004−17.009 |
1 | ||
| 44312A - BEARING(FOR VANE PUMP SHAFT) | ||||
| 90363-17008 |
JZS13# |
1 | ||
| 44312B - RING, SNAP, NO.1(FOR VANE PUMP SHAFT) | ||||
| 90520-15001 |
JZS13#,LS13# |
1 | ||
| 90520-10003 |
GS136;GS130,131,MS135,137..DLX,ROY,ROYG,SAL,SALEX,SDX,SPE,SSL |
1 | ||
| 90520-15001 |
JZS13#,LS13#,MS130,YS130 |
1 | ||
| 44313 - ROTOR, VANE PUMP | ||||
| 44313-12010 |
GS136,LS13#,YS130;GS130,131,MS130,135..DLX,ROY,SAL,SALEX,SDX,SPE,SSL ﾏｰｸ無し |
1 | ||
| 44313-12050 |
GS136,LS13#,YS130;GS130,131,MS130,135..DLX,ROY,SAL,SALEX,SDX,SPE,SSL ﾏｰｸ 4 |
1 | ||
| 44313-12040 |
GS136,LS13#,YS130;GS130,131,MS130,135..DLX,ROY,SAL,SALEX,SDX,SPE,SSL ﾏｰｸ 3 |
1 | ||
| 44313-12020 |
GS136,LS13#,YS130;GS130,131,MS130,135..DLX,ROY,SAL,SALEX,SDX,SPE,SSL ﾏｰｸ 1 |
1 | ||
| 44313-12030 |
GS136,LS13#,YS130;GS130,131,MS130,135..DLX,ROY,SAL,SALEX,SDX,SPE,SSL ﾏｰｸ 2 |
1 | ||
| 44313-26080 |
JZS13# ﾏｰｸ 2 |
1 | ||
| 44313-26060 |
JZS13# ﾏｰｸ無し |
1 | ||
| 44313-26070 |
JZS13# ﾏｰｸ 1 |
1 | ||
| 44313-26090 |
JZS13# ﾏｰｸ 3 |
1 | ||
| 44313-26100 |
JZS13# ﾏｰｸ 4 |
1 | ||
| 44320 - PUMP ASSY, VANE | ||||
| 44320-30400 |
JZS13# |
1 | ||
| 44320-30401 |
JZS13# |
1 | ||
| 44324A - HOUSING, PUMP, REAR | ||||
| 44324-22040 |
JZS13# |
1 | ||
| 44324C - RING, O(FOR PUMP HOUSING REAR) | ||||
| 90301-18007 |
JZS13# |
1 | ||
| 44326 - RING, CAM(FOR VANE PUMP) | ||||
| 44325-30150 |
GS130,131,MS135..SPC,TWC ﾏｰｸ無し |
1 | ||
| 44325-30160 |
GS130,131,MS135..SPC,TWC ﾏｰｸ 1 |
1 | ||
| 44325-30170 |
GS130,131,MS135..SPC,TWC ﾏｰｸ 2 |
1 | ||
| 44325-30190 |
GS130,131,MS135..SPC,TWC ﾏｰｸ 4 |
1 | ||
| 44325-30180 |
GS130,131,MS135..SPC,TWC ﾏｰｸ 3 |
1 | ||
| 44325-32060 |
JZS13# ﾏｰｸ無し |
1 | ||
| 44325-32080 |
JZS13# ﾏｰｸ 2 |
1 | ||
| 44325-32090 |
JZS13# ﾏｰｸ 3 |
1 | ||
| 44325-32100 |
JZS13# ﾏｰｸ 4 |
1 | ||
| 44325-32070 |
JZS13# ﾏｰｸ 1 |
1 | ||
| 44326A - PIN, STRAIGHT(FOR VANE PUMP CAM RING) | ||||
| 90250-05017 |
GS130,131,MS135,137..SPC,TWC,TWLPG 長さ=43.5,外径=5.0 |
1 | ||
| 90250-05008 |
GS130,131,MS135,137..SPC,TWC,TWLPG 長さ=25,外径=5.0 |
1 | ||
| 90250-04071 |
JZS13# 長さ=23.3,外径=4.0 |
2 | ||
| 44327C - GASKET, VANE PUMP HOUSING | ||||
| 44327-26010 |
JZS13# |
1 | ||
| 44330 - VALVE ASSY, FLOW CONTROL | ||||
| 44330-30100 |
GS136,LS13#,YS130;GS130,131,MS130,135..DLX,ROY,SAL,SALEX,SDX,SPE,SSL ﾏｰｸ A |
1 | ||
| 44330-30140 |
GS136,LS13#,YS130;GS130,131,MS130,135..DLX,ROY,SAL,SALEX,SDX,SPE,SSL ﾏｰｸ E |
1 | ||
| 44330-30120 |
GS136,LS13#,YS130;GS130,131,MS130,135..DLX,ROY,SAL,SALEX,SDX,SPE,SSL ﾏｰｸ C |
1 | ||
| 44330-30110 |
GS136,LS13#,YS130;GS130,131,MS130,135..DLX,ROY,SAL,SALEX,SDX,SPE,SSL ﾏｰｸ B |
1 | ||
| 44330-30130 |
GS136,LS13#,YS130;GS130,131,MS130,135..DLX,ROY,SAL,SALEX,SDX,SPE,SSL ﾏｰｸ D |
1 | ||
| 44330-30150 |
GS136,LS13#,YS130;GS130,131,MS130,135..DLX,ROY,SAL,SALEX,SDX,SPE,SSL ﾏｰｸ F |
1 | ||
| 44330-26010 |
JZS13# ﾏｰｸ A |
1 | ||
| 44330-26020 |
JZS13# ﾏｰｸ B |
1 | ||
| 44330-26050 |
JZS13# ﾏｰｸ E |
1 | ||
| 44330-26040 |
JZS13# ﾏｰｸ D |
1 | ||
| 44330-26060 |
JZS13# ﾏｰｸ F |
1 | ||
| 44330-26030 |
JZS13# ﾏｰｸ C |
1 | ||
| 44330-26041 |
JZS13# ﾏｰｸ D |
1 | ||
| 44330-26011 |
JZS13# ﾏｰｸ A |
1 | ||
| 44330-26021 |
JZS13# ﾏｰｸ B |
1 | ||
| 44330-26051 |
JZS13# ﾏｰｸ E |
1 | ||
| 44330-26031 |
JZS13# ﾏｰｸ C |
1 | ||
| 44330-26061 |
JZS13# ﾏｰｸ F |
1 | ||
| 44330A - SPRING, COMPRESSION(FOR FLOW CONTROL VALVE) | ||||
| 90501-11047 |
JZS13# |
1 | ||
| 90501-12103 |
GS136,LS130,136,YS130;GS130,131,LS131,MS13#,UZS131..DLX,ROY,ROYG,SAL,SALEX,SDX,SPE,SSL |
1 | ||
| 90501-13034 |
JZS13# |
1 | ||
| 44338A - RING, O(FOR PRESSURE PORT UNION) | ||||
| 90301-19003 |
GS131,136,UZS131..EFI,HTWC;GS130,JZS13#..(DLX,ROY,SAL,SALEX,SDX,SPE,SSL)..(EFI,HTWC,TWC) 内径=19.5,外径=22.5 |
1 | ||
| 90301-22001 |
GS130,131,LS13#,MS13#,YS130..DSL,LPG,SPC,TD,TDE,TWC 外径=25.5,内径=22.5 |
1 | ||
| 96711-19014 |
GS130,131,LS13#,MS13#,YS130..DSL,LPG,SPC,TD,TDE,TWC 外径=17.0,内径=13.0 |
1 | ||
| 44342 - PLATE, VANE PUMP SIDE, REAR | ||||
| 44342-22010 |
GS130,131,MS135..ROY |
1 | ||
| 44342-32050 |
JZS13# |
1 | ||
| 44342A - RING, O(FOR VANE PUMP SIDE PLATE REAR) | ||||
| 90301-13004 |
GS130,131,MS135,137..SPC,TWC,TWLPG 内側 |
1 | ||
| 90301-30004 |
GS130,131,MS135,137..SPC,TWC,TWLPG 外側 |
1 | ||
| 90301-47001 |
JZS13# |
1 | ||
| 44345B - PLATE, VANE PUMP | ||||
| 44345-12010 |
GS136,LS130,136,YS130;GS130,131,LS131,MS13#,UZS131..DLX,ROY,ROYG,SAL,SALEX,SDX,SPE,SSL 長さ=14.997 |
10 | ||
| 44345-26030 |
JZS13# 長さ=14.996 |
10 | ||
| 44345-26020 |
JZS13# 長さ=14.998 |
10 | ||
| 44345-12020 |
GS136,LS130,136,YS130;GS130,131,LS131,MS13#,UZS131..DLX,ROY,ROYG,SAL,SALEX,SDX,SPE,SSL 長さ=14.995 |
10 | ||
| 44345-12050 |
GS136,LS130,136,YS130;GS130,131,LS131,MS13#,UZS131..DLX,ROY,ROYG,SAL,SALEX,SDX,SPE,SSL 長さ=14.989 |
10 | ||
| 44345-12040 |
GS136,LS130,136,YS130;GS130,131,LS131,MS13#,UZS131..DLX,ROY,ROYG,SAL,SALEX,SDX,SPE,SSL 長さ=14.991 |
10 | ||
| 44345-12030 |
GS136,LS130,136,YS130;GS130,131,LS131,MS13#,UZS131..DLX,ROY,ROYG,SAL,SALEX,SDX,SPE,SSL 長さ=14.993 |
10 | ||
| 44345-26010 |
JZS13# 長さ=15.000 |
10 | ||
| 44345-26040 |
JZS13# 長さ=14.994 |
10 | ||
| 44345-26050 |
JZS13# 長さ=14.992 |
10 | ||
| 44360 - RESERVOIR ASSY, VANE PUMP OIL | ||||
| 44306-30280 |
JZS13# |
1 | ||
| 44362A - RING, O(FOR VANE PUMP OIL RESERVOIR) | ||||
| 90301-11010 |
JZS13# |
1 | ||
| 44441B - BRACKET, PUMP, FRONT | ||||
| 44441-30080 |
JZS13# |
1 | ||
| 44443B - BRACKET, VANE PUMP | ||||
| 44443-22130 |
JZS13# |
1 | ||
| Common parts | ||||
| 90105-08194 | ||||
| 90105-10038 | ||||
| 90119-08469 | ||||
| 90206-31001 | ||||
