GS131-ATPEK (1989)
Toyota Crown
(8908- )GS13#..HTWC,SPC,TWC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 78024 - BRACKET SUB-ASSY, ACCELERATOR CONTROL CABLE | ||||
| 78024-88300 |
GS131..TWC |
1 | ||
| 78024-88300 |
GS131..TWC |
1 | ||
| 78024 - BRACKET SUB-ASSY, ACCELERATOR CONTROL CABLE | ||||
| 78024-88300 |
GS131..TWC |
1 | ||
| 78024-88300 |
GS131..TWC |
1 | ||
| 78111 - PEDAL, ACCELERATOR | ||||
| 78111-30090 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78111-30080 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| 78111 - PEDAL, ACCELERATOR | ||||
| 78111-30090 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78111-30080 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| 78111A - SPRING (FOR ACCELERATOR PEDAL) | ||||
| 90508-18071 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78111C - PIN (FOR ACCELERATOR PEDAL) | ||||
| 90249-05043 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78114A - BRACKET, ACCELERATOR PEDAL SUPPORT | ||||
| 78114-30050 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| 78120A - SPRING, COMPRESSION (FOR ACCELERATOR LINK ROD) | ||||
| 90508-18066 |
LS13#;GS130,131,MS13#..ATM |
1 | ||
| 90508-23101 |
LS13#;GS130,131,MS13#..ATM ｶﾝﾚｲﾁ ｼﾖｳ |
2 | ||
| 90508-23026 |
GS130,131,MS13#,UZS131..ATM;GS130,LS13#..MTM..(DSL,TD,TWLPG) ｶﾝﾚｲﾁ ｼﾖｳ |
2 | ||
| 90508-23026 |
GS130,LS13#..MTM..(DSL,TD,TWLPG);GS130,131,JZS13#,MS13#,UZS131..ATM ｶﾝﾚｲﾁ ｼﾖｳ |
2 | ||
| 78120A - SPRING, COMPRESSION (FOR ACCELERATOR LINK ROD) | ||||
| 90508-18066 |
LS13#;GS130,131,MS13#..ATM |
1 | ||
| 90508-23101 |
LS13#;GS130,131,MS13#..ATM ｶﾝﾚｲﾁ ｼﾖｳ |
2 | ||
| 90508-23026 |
GS130,131,MS13#,UZS131..ATM;GS130,LS13#..MTM..(DSL,TD,TWLPG) ｶﾝﾚｲﾁ ｼﾖｳ |
2 | ||
| 90508-23026 |
GS130,LS13#..MTM..(DSL,TD,TWLPG);GS130,131,JZS13#,MS13#,UZS131..ATM ｶﾝﾚｲﾁ ｼﾖｳ |
2 | ||
| 78120G - ROD ASSY, ACCELERATOR PEDAL | ||||
| 78120-30540 |
GS130,131..ATM..(EFI,TWC);GS131,LS13#..(DLX,SALEX,SDX,SPE,SSL,STD)..(DSL,SPC,TD,TDE) ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78120-30550 |
GS130,131..ATM..(EFI,TWC);GS131,LS13#..(DLX,SALEX,SDX,SPE,SSL,STD)..(DSL,SPC,TD,TDE) |
1 | ||
| 78120-30541 |
LS13#..MTM;GS131..SSL..SPC;GS131..ATM..(HTWC,TWC);GS130,MS135,UZS131..ATM..(DLX,ROYG,SALEX,SDX)..(HTWC,TWC) ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78120-30541 |
LS136..MTM;GS131..SSL..SPC;GS131..ATM..(HTWC,TWC);JZS13#,LS130,131,UZS131..DSL,HTWC,TD,TWC;GS130,MS135..ATM..(DLX,SALEX,SDX)..(HTWC,TWC) ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78120G - ROD ASSY, ACCELERATOR PEDAL | ||||
| 78120-30540 |
GS130,131..ATM..(EFI,TWC);GS131,LS13#..(DLX,SALEX,SDX,SPE,SSL,STD)..(DSL,SPC,TD,TDE) ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78120-30550 |
GS130,131..ATM..(EFI,TWC);GS131,LS13#..(DLX,SALEX,SDX,SPE,SSL,STD)..(DSL,SPC,TD,TDE) |
1 | ||
| 78120-30541 |
LS13#..MTM;GS131..SSL..SPC;GS131..ATM..(HTWC,TWC);GS130,MS135,UZS131..ATM..(DLX,ROYG,SALEX,SDX)..(HTWC,TWC) ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78120-30541 |
LS136..MTM;GS131..SSL..SPC;GS131..ATM..(HTWC,TWC);JZS13#,LS130,131,UZS131..DSL,HTWC,TD,TWC;GS130,MS135..ATM..(DLX,SALEX,SDX)..(HTWC,TWC) ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 78139A - SEAL, ACCELERATOR PEDAL ROD BRACKET, NO.2 | ||||
| 78139-30060 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| 78139A - SEAL, ACCELERATOR PEDAL ROD BRACKET, NO.2 | ||||
| 78139-30060 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| 78180P - CABLE ASSY, ACCELERATOR CONTROL | ||||
| 78180-3A110 |
GS131..TWC |
1 | ||
| 78180-30731 |
GS13#..HTWC |
1 | ||
| 78180-3A111 |
GS131..TWC |
1 | ||
| 78183B - CLAMP, ACCELERATOR CONTROL CABLE | ||||
| 78183-30090 |
GS130,131,LS13#,MS13#,YS130..DSL,LPG,SPC,TD,TDE,TWC |
1 | ||
| 78183-30070 |
GS13#,JZS13#,LS13#,MS135,YS130 |
1 | ||
| Common parts | ||||
| 90202-08028 | ||||
| 90386-08077 | ||||
| 90541-06002 | ||||
| 91111-40620 | ||||
| 91611-F0812 | ||||
| 91611-F0814 | ||||
| 91615-60614 | ||||
| 91666-40635 | ||||
| 94110-40600 | ||||
| 94611-10800 | ||||
| 95381-02015 | ||||
| 96160-00400 | ||||
