GS130G-AWSJE (1987)
Toyota Crown
(8709- )V,WG
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69051 - CYLINDER & KEY SET, DOOR LOCK, RH | ||||
| 69051-30160 |
GS13#,LS13#,MS13#,YS130 |
1 | ||
| 69052 - CYLINDER & KEY SET, DOOR LOCK, LH | ||||
| 69052-30140 |
GS13#,LS13#,MS13#,YS130 |
1 | ||
| 69054 - CYLINDER & KEY SET, BACK DOOR LOCK | ||||
| 69055-91704 |
GS130,136,LS13#..(V,WG)..(DSL,EFI,HTWC,TDE) |
1 | ||
| 69057A - CYLINDER & KEY SET, IGNITION SWITCH LOCK | ||||
| 69057-30070 |
GS13#,LS13#,MS13#,YS130 |
1 | ||
| 69062 - CYLINDER & KEY SET, GLOVE COMPARTMENT LOCK | ||||
| 69056-3010002 |
GS131,MS135,137..4HC;GS130..(SAL,SALEX,SDX)..HTWC;GS130,131,MS135,137..SED..(4FC,4H)..(DLX,ROY,ROYG)..(HTWC,SPC,TWC);GS130,136,LS13#,MS130,YS130..(SED,V,WG)..(DLX,ROY,SAL,SALEX,SDX)..(DSL,EFI,LPG,SPC,TD,TDE) MAROON,TRIM3# |
1 | ||
| 69056-3010004 |
GS131,MS135,137..4HC;GS131,MS135,137..SED..4FC;GS130,136,LS13#,MS130,YS130..SED,V,WG BLUE,TRIM8# |
1 | ||
| 69056-3010006 |
GS131,MS135,137..4HC;GS131,MS135,137..SED..4FC;GS130,LS130..(SED,WG)..(ROY,SAL,SALEX) SABLE,TRIM4# |
1 | ||
| 69503 - CYLINDER SET, LOCK | ||||
| 69005-91715 |
GS130,LS130..WG..(SALEX,SDX) |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00139 |
GS13#,LS13#,MS13#,YS130 ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00130 |
GS13#,LS13#,MS13#,YS130 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00137 |
GS130,131,LS130,MS13#,YS130 ｻﾌﾞｷｰ |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00139 |
GS13#,LS13#,MS13#,YS130 ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00130 |
GS13#,LS13#,MS13#,YS130 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00137 |
GS130,131,LS130,MS13#,YS130 ｻﾌﾞｷｰ |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00139 |
GS13#,LS13#,MS13#,YS130 ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00130 |
GS13#,LS13#,MS13#,YS130 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00137 |
GS130,131,LS130,MS13#,YS130 ｻﾌﾞｷｰ |
1 | ||
| 69555 - COVER, KEY | ||||
| 69555-20010 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| 69759C - SNAP, BACK DOOR LOCK CYLINDER | ||||
| 69759-24080 |
GS130,136,JZS130,LS130,136..V,WG ｲｴﾛｰ |
1 | ||
| 69759-24090 |
GS130,136,JZS130,LS130,136..V,WG ﾌﾞﾗｳﾝ |
1 | ||
| 69759C - SNAP, BACK DOOR LOCK CYLINDER | ||||
| 69759-24080 |
GS130,136,JZS130,LS130,136..V,WG ｲｴﾛｰ |
1 | ||
| 69759-24090 |
GS130,136,JZS130,LS130,136..V,WG ﾌﾞﾗｳﾝ |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-30040 |
GS13#,LS13#,MS13#,YS130 右側 |
1 | ||
| 69759-30050 |
GS13#,LS13#,MS13#,YS130 左側 |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-30040 |
GS13#,LS13#,MS13#,YS130 右側 |
1 | ||
| 69759-30050 |
GS13#,LS13#,MS13#,YS130 左側 |
1 | ||
| Common parts | ||||
| 90151-40009 | ||||
| 91611-40612 | ||||
| 91612-40612 | ||||
| 93319-15008 | ||||
| Linked diagrams | ||||
| 5501 | ||||
