GS130G-AWPJK (1988)
Toyota Crown
(8709-8908)ROY,ROYG ; (8908- )GS130,131,MS135..HTWC,TWC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04443 - BOOSTER KIT, BRAKE | ||||
| 04443-30580 |
GS130..WG..SALEX..HTWC;GS130..(DLX,SDX,SPE,STD)..HTWC |
1 | ||
| 04443-30500 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) JKC |
1 | ||
| 04443-30580 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) AISIN |
1 | ||
| 04443-30620 |
GS130..HTWC AISIN |
1 | ||
| 44606E - ROD SUB-ASSY, BRAKE BOOSTER PISTON | ||||
| 44606-20800 |
GS130,131,JZS13#,MS135,137,UZS131..HTWC,SPC,TWC |
1 | ||
| 44610 - BOOSTER ASSY, BRAKE | ||||
| 44610-30670 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) JKC |
1 | ||
| 44610-30660 |
GS130..WG..SALEX..HTWC;GS130..(DLX,SDX,SPE,STD)..HTWC |
1 | ||
| 44610-30660 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) AISIN |
1 | ||
| 44610-30661 |
GS130,131..HTWC,TWC AISIN |
1 | ||
| 44621V - SEAL, BOOSTER BODY | ||||
| 44621-14030 |
GS130,131,JZS13#,MS135,137,UZS131..HTWC,SPC,TWC |
1 | ||
| 44626 - RETAINER, BOOSTER ROD CUP | ||||
| 44626-60010 |
GS130,131,JZS13#,MS135,137,UZS131..HTWC,SPC,TWC |
1 | ||
| 44629 - RING, CIRCULAR INTERNAL | ||||
| 44628-60010 |
GS130,131,JZS13#,MS135,137,UZS131..HTWC,SPC,TWC |
1 | ||
| 44635B - KEY, VALVE STOPPER | ||||
| 44635-20800 |
GS130,131,MS135,137..SPC,TWC |
1 | ||
| 44635-20800 |
GS130,131,JZS13#,MS13#,UZS131..HTWC,SPC,TWC |
1 | ||
| 44635-20800 |
GS131..HTWC,SPC,TWC;GS130,MS135,137..HTWC,TWC |
1 | ||
| 44642 - PISTON, BRAKE BOOSTER | ||||
| 44642-20800 |
GS130,131,MS135,137..HTWC,SPC,TWC |
1 | ||
| 44642-20800 |
GS130,131,JZS13#,MS13#,UZS131..HTWC,SPC,TWC |
1 | ||
| 44643 - RETAINER, DIAPHRAGM | ||||
| 44643-20800 |
GS130,131,JZS13#,MS135,137,UZS131..HTWC,SPC,TWC |
1 | ||
| 44657D - CASE, REACTION DISC | ||||
| 44657-30560 |
GS130,131,MS135,137..SPC,TWC |
1 | ||
| 44657-30560 |
GS130,131..HTWC,TWC |
1 | ||
| 44696 - GROMMET, CHECK VALVE | ||||
| 90480-24439 |
YS130..4HC;GS136,MS130;YS130..4H..DLX;GS130..WG..SALEX;GS130..DLX,ROY,SDX,SPE |
1 | ||
| 90480-24439 |
GS130,131,MS135,137..(HT,SED)..(ROY,ROYG,SAL,SALEX,SSL) AISIN BOOSTER |
1 | ||
| 90480-24517 |
GS130,131,MS135,137..(HT,SED)..(ROY,ROYG,SAL,SALEX,SSL) JKC BOOSTER |
1 | ||
| 90480-24439 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(EFI,HTWC,TWC) AISIN BOOSTER |
1 | ||
| 90480-24517 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(EFI,HTWC,TWC) JKC BOOSTER |
1 | ||
| 90480-24439 |
YS130..4HC;YS130..4H..DLX;GS136,MS135,137;GS130..WG..SALEX;GS130..STD..HTWC;GS131,MS130..LPG,SPC;GS130..DLX,ROY,SDX,SPE |
1 | ||
| 90480-24439 |
YS130..4HC;YS130..4H..DLX;GS130,136,JZS130 |
1 | ||
| 44730 - VALVE ASSY, VACUUM CHECK(FOR BRAKE) | ||||
| 44730-14050 |
YS130..4HC;GS136,MS130;YS130..4H..DLX;GS130..WG..SALEX;GS130..DLX,ROY,SDX,SPE |
1 | ||
| 44730-14050 |
GS130,131,MS135,137..(HT,SED)..(ROY,ROYG,SAL,SALEX,SSL) AISIN BOOSTER |
1 | ||
| 44730-14060 |
GS130,131,MS135,137..(HT,SED)..(ROY,ROYG,SAL,SALEX,SSL) JKC BOOSTER |
1 | ||
| 44730-14060 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(EFI,HTWC,TWC) JKC BOOSTER |
1 | ||
| 44730-14050 |
YS130..4HC;YS130..4H..DLX;GS130,136,JZS130 |
1 | ||
| 44730-14050 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(EFI,HTWC,TWC) AISIN BOOSTER |
1 | ||
| 44730-14050 |
YS130..4HC;YS130..4H..DLX;GS136,MS135,137;GS130..WG..SALEX;GS130..STD..HTWC;GS131,MS130..LPG,SPC;GS130..DLX,ROY,SDX,SPE |
1 | ||
| 44758 - BRACKET, VACUUM CHECK VALVE | ||||
| 44758-30100 |
GS130,131,JZS13#,MS135,137,UZS131..HTWC,SPC,TWC |
1 | ||
| 44785 - GASKET, BRAKE BOOSTER | ||||
| 44785-30020 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| Common parts | ||||
| 90179-08041 | ||||
(8908- )MS135..ROY ; (8908- )GS131..ROY..SPC ; (8908- )GS131,JZS13#,MS137,
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04443 - BOOSTER KIT, BRAKE | ||||
| 04443-30580 |
GS130..WG..SALEX..HTWC;GS130..(DLX,SDX,SPE,STD)..HTWC |
1 | ||
| 04443-30500 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) JKC |
1 | ||
| 04443-30580 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) AISIN |
1 | ||
| 04443-30620 |
GS130..HTWC AISIN |
1 | ||
| 44605 - PLATE & SEAL SUB-ASSY, BOOSTER | ||||
| 44605-30350 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) |
1 | ||
| 44608 - PUSH ROD SUB-ASSY, BOOSTER | ||||
| 44608-17090 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) |
1 | ||
| 44609D - PLATE & RETAINER SUB-ASSY, BOOSTER | ||||
| 44609-26380 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) |
1 | ||
| 44610 - BOOSTER ASSY, BRAKE | ||||
| 44610-30670 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) JKC |
1 | ||
| 44610-30660 |
GS130..WG..SALEX..HTWC;GS130..(DLX,SDX,SPE,STD)..HTWC |
1 | ||
| 44610-30660 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) AISIN |
1 | ||
| 44610-30661 |
GS130,131..HTWC,TWC AISIN |
1 | ||
| 44624J - PLATE, BOOSTER CENTER | ||||
| 44624-28300 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) |
1 | ||
| 44633 - KEY, BOOSTER VALVE PLUNGER | ||||
| 44633-20811 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) |
1 | ||
| 44637A - PLATE, BOOSTER DIAPHRAGM | ||||
| 44637-28300 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) |
1 | ||
| 44645 - RETAINER, BOOSTER PUSH ROD SEAL | ||||
| 44645-10080 |
YS130..MTM..STD;GS130,131,MS135,137..(HT,SED)..(ROY,ROYG,SAL,SALEX,SSL,STD) |
1 | ||
| 44673A - BODY, BOOSTER VALVE | ||||
| 44673-20810 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(HTWC,TWC) |
1 | ||
| 44696 - GROMMET, CHECK VALVE | ||||
| 90480-24439 |
YS130..4HC;GS136,MS130;YS130..4H..DLX;GS130..WG..SALEX;GS130..DLX,ROY,SDX,SPE |
1 | ||
| 90480-24439 |
GS130,131,MS135,137..(HT,SED)..(ROY,ROYG,SAL,SALEX,SSL) AISIN BOOSTER |
1 | ||
| 90480-24517 |
GS130,131,MS135,137..(HT,SED)..(ROY,ROYG,SAL,SALEX,SSL) JKC BOOSTER |
1 | ||
| 90480-24439 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(EFI,HTWC,TWC) AISIN BOOSTER |
1 | ||
| 90480-24517 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(EFI,HTWC,TWC) JKC BOOSTER |
1 | ||
| 90480-24439 |
YS130..4HC;YS130..4H..DLX;GS136,MS135,137;GS130..WG..SALEX;GS130..STD..HTWC;GS131,MS130..LPG,SPC;GS130..DLX,ROY,SDX,SPE |
1 | ||
| 90480-24439 |
YS130..4HC;YS130..4H..DLX;GS130,136,JZS130 |
1 | ||
| 44730 - VALVE ASSY, VACUUM CHECK(FOR BRAKE) | ||||
| 44730-14050 |
YS130..4HC;GS136,MS130;YS130..4H..DLX;GS130..WG..SALEX;GS130..DLX,ROY,SDX,SPE |
1 | ||
| 44730-14050 |
GS130,131,MS135,137..(HT,SED)..(ROY,ROYG,SAL,SALEX,SSL) AISIN BOOSTER |
1 | ||
| 44730-14060 |
GS130,131,MS135,137..(HT,SED)..(ROY,ROYG,SAL,SALEX,SSL) JKC BOOSTER |
1 | ||
| 44730-14060 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(EFI,HTWC,TWC) JKC BOOSTER |
1 | ||
| 44730-14050 |
YS130..4HC;YS130..4H..DLX;GS130,136,JZS130 |
1 | ||
| 44730-14050 |
GS130,131..(HT,SED)..(ROY,SAL,SALEX,SSL)..(EFI,HTWC,TWC) AISIN BOOSTER |
1 | ||
| 44730-14050 |
YS130..4HC;YS130..4H..DLX;GS136,MS135,137;GS130..WG..SALEX;GS130..STD..HTWC;GS131,MS130..LPG,SPC;GS130..DLX,ROY,SDX,SPE |
1 | ||
| 44758 - BRACKET, VACUUM CHECK VALVE | ||||
| 44758-30100 |
GS130,131,JZS13#,MS135,137,UZS131..HTWC,SPC,TWC |
1 | ||
| 44785 - GASKET, BRAKE BOOSTER | ||||
| 44785-30020 |
GS13#,JZS13#,LS13#,MS13#,UZS131,YS130 |
1 | ||
| Common parts | ||||
| 90179-08121 | ||||
