GS130-ATPEE (1987)
Toyota Crown
(8709-8908)ATM..DSL,EFI,HTWC,LPG,TWC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 35601B - RING, O (FOR FRONT CLUTCH DRUM) | ||||
| 90301-57188 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
1 | ||
| 35602 - PISTON SUB-ASSY, FRONT CLUTCH | ||||
| 35602-30042 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,LPG,TDE,TWC) |
1 | ||
| 35602F - PISTON SUB-ASSY, REAR CLUTCH, NO.2 | ||||
| 35602-30041 |
GS130,131,LS136,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TWC,TWLPG) |
1 | ||
| 35605 - DRUM SUB-ASSY, REAR CLUTCH W/2ND SUN GEAR | ||||
| 35605-30021 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWLPG) |
1 | ||
| 35606 - PISTON SUB-ASSY, REAR CLUTCH | ||||
| 35606-22010 |
GS130,131,LS136,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TWC,TWLPG) |
1 | ||
| 35606B - RING (FOR REAR CLUTCH PISTON INNER) | ||||
| 90301-57188 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
1 | ||
| 35610B - SPRING, COMPRESSION (FOR FRONT CLUTCH PISTON RETURN) | ||||
| 90501-11023 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) |
20 | ||
| 35610C - RING, SHAFT SNAP (FOR FRONT CLUTCH PISTON RETURN SPRING | ||||
| 90520-39261 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
1 | ||
| 35610D - RING, HOLE SNAP (FOR FRONT MULTIPLE DISC CLUTCH) | ||||
| 90521-99139 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
1 | ||
| 35613 - RING, CLUTCH PISTON OIL SEAL, OUTER | ||||
| 90301-99016 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) |
1 | ||
| 90301-99016 |
GS130,131,LS130,MS130,YS130..ATM..(EFI,HTWC,LPG,TDE,TWC) |
1 | ||
| 35615 - SEAT, CLUTCH PISTON RETURN SPRING | ||||
| 35615-30020 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) |
1 | ||
| 35631 - HUB, CLUTCH(FOR MULTIPLE DISC CLUTCH) | ||||
| 35631-30050 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
1 | ||
| 35631B - BEARING, THRUST(FOR FRONT CLUTCH HUB) | ||||
| 90374-28014 |
GS130,131..ATM..(EFI,HTWC,TWC) |
1 | ||
| 35631C - RACE, THRUST BEARING(FOR FRONT CLUTCH HUB FRONT) | ||||
| 35789-22050 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
1 | ||
| 35631D - RACE, THRUST BEARING(FOR FRONT CLUTCH HUB REAR) | ||||
| 35789-22020 |
GS130,131..ATM..(EFI,HTWC,TWC) |
1 | ||
| 35633 - DISC, CLUTCH (FOR FRONT CLUTCH) | ||||
| 35677-30030 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWLPG) |
4 | ||
| 35633 - DISC, CLUTCH (FOR FRONT CLUTCH) | ||||
| 35677-30030 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWLPG) |
4 | ||
| 35633 - DISC, CLUTCH (FOR FRONT CLUTCH) | ||||
| 35677-30030 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWLPG) |
4 | ||
| 35634 - PLATE, FRONT CLUTCH | ||||
| 35634-22040 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,LPG,TDE) 厚さ=1.8 |
3 | ||
| 35634-22040 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) 厚さ=1.8 |
3 | ||
| 35634-30070 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) 厚さ=2.0 |
1 | ||
| 35634-30070 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,LPG,TDE) 厚さ=2.0 |
1 | ||
| 35634 - PLATE, FRONT CLUTCH | ||||
| 35634-22040 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,LPG,TDE) 厚さ=1.8 |
3 | ||
| 35634-22040 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) 厚さ=1.8 |
3 | ||
| 35634-30070 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) 厚さ=2.0 |
1 | ||
| 35634-30070 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,LPG,TDE) 厚さ=2.0 |
1 | ||
| 35634 - PLATE, FRONT CLUTCH | ||||
| 35634-22040 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,LPG,TDE) 厚さ=1.8 |
3 | ||
| 35634-22040 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) 厚さ=1.8 |
3 | ||
| 35634-30070 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) 厚さ=2.0 |
1 | ||
| 35634-30070 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,LPG,TDE) 厚さ=2.0 |
1 | ||
| 35634 - PLATE, FRONT CLUTCH | ||||
| 35634-22040 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,LPG,TDE) 厚さ=1.8 |
3 | ||
| 35634-22040 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) 厚さ=1.8 |
3 | ||
| 35634-30070 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) 厚さ=2.0 |
1 | ||
| 35634-30070 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,LPG,TDE) 厚さ=2.0 |
1 | ||
| 35634D - PLATE, REAR CLUTCH | ||||
| 35634-22040 |
GS130,131,LS136..ATM..(DSL,EFI,HTWC) 厚さ=1.8 |
3 | ||
| 35634D - PLATE, REAR CLUTCH | ||||
| 35634-22040 |
GS130,131,LS136..ATM..(DSL,EFI,HTWC) 厚さ=1.8 |
3 | ||
| 35634D - PLATE, REAR CLUTCH | ||||
| 35634-22040 |
GS130,131,LS136..ATM..(DSL,EFI,HTWC) 厚さ=1.8 |
3 | ||
| 35650B - SPRING, COMPRESSION (FOR REAR CLUTCH PISTON RETURN) | ||||
| 90501-10671 |
GS130,131,LS136,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG) |
18 | ||
| 35650E - RING, O (FOR REAR CLUTCH PISTON OUTER) | ||||
| 90301-99016 |
GS130,131,LS130,MS130,YS130..ATM..(EFI,HTWC,LPG,TDE,TWC) 外側 |
1 | ||
| 90301-57188 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) 内側 |
1 | ||
| 90301-99016 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) 外側 |
1 | ||
| 35650E - RING, O (FOR REAR CLUTCH PISTON OUTER) | ||||
| 90301-99016 |
GS130,131,LS130,MS130,YS130..ATM..(EFI,HTWC,LPG,TDE,TWC) 外側 |
1 | ||
| 90301-57188 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) 内側 |
1 | ||
| 90301-99016 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) 外側 |
1 | ||
| 35650F - RING, SHAFT SNAP | ||||
| 90520-39261 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
1 | ||
| 35650G - RING, SHAFT SNAP (FOR REAR CLUTCH PISTON RETURN SPRING) | ||||
| 90521-99139 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
1 | ||
| 35653 - RING, REAR CLUTCH OIL SEAL, OUTER | ||||
| 90301-84184 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
1 | ||
| 35654 - HUB, REAR CLUTCH | ||||
| 35654-30010 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
1 | ||
| 35654A - RING, HOLE SNAP (FOR REAR CLUTCH HUB) | ||||
| 90521-99146 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,LPG,TDE,TWC) |
1 | ||
| 35655 - SEAT, REAR CLUTCH PISTON RETURN SPRING | ||||
| 35615-30020 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPG,TDE,TWC) |
1 | ||
| 35675 - FLANGE, REAR CLUTCH | ||||
| 35675-22010 |
GS130,131,LS136..ATM..(DSL,EFI,HTWC,TWC) 厚さ=4.0 |
1 | ||
| 35677C - DISC, REAR CLUTCH | ||||
| 35677-30030 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
3 | ||
| 35677C - DISC, REAR CLUTCH | ||||
| 35677-30030 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
3 | ||
| 35677C - DISC, REAR CLUTCH | ||||
| 35677-30030 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
3 | ||
| 35701 - SHAFT SUB-ASSY, INPUT | ||||
| 35701-30042 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,LPG,TDE,TWC) |
1 | ||
| 35701C - RACE, THRUST BEARING (FOR INPUT SHAFT REAR) | ||||
| 35789-22010 |
GS130,131,LS13#,MS130,YS130..ATM..(DSL,EFI,HTWC,LPEFI,LPG,TDE,TWC,TWLPG) |
1 | ||
