GS130-AESGE (1987)
Toyota Crown
(8709- )4H
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33046 - GEAR SUB-ASSY, COUNTERSHAFT, 4TH | ||||
| 33046-28020 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33046A - BEARING(FOR COUNTERSHAFT 4TH GEAR) | ||||
| 90364-26002 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33311 - SHAFT, INPUT | ||||
| 33301-30061 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33311A - BEARING (FOR INPUT SHAFT FRONT) | ||||
| 90363-32026 |
GS136..4H..EFI;GS130,LS130,136,MS130,YS130..4H..(DSL,EFI,HTWC,LPG) |
1 | ||
| 33311B - RING, SHAFT SNAP (FOR FRONT BEARING) | ||||
| 90520-30216 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.15,ﾏｰｸ 2 |
1 | ||
| 90520-30215 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.10,ﾏｰｸ 1 |
1 | ||
| 90520-30217 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.20,ﾏｰｸ 3 |
1 | ||
| 90520-30218 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.25,ﾏｰｸ 4 |
1 | ||
| 90520-30219 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.30,ﾏｰｸ 5 |
1 | ||
| 90520-30214 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.05,ﾏｰｸ 0 |
1 | ||
| 33311D - BEARING, INPUT SHAFT | ||||
| 90361-06002 |
GS130,136,LS130,136,MS130,YS130..4H |
13 | ||
| 33311G - RING, SHAFT SNAP (FOR FRONT BEARING) | ||||
| 90520-76002 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33318 - PIECE, GEAR SPLINE, NO.5 | ||||
| 33318-28010 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33321 - SHAFT, OUTPUT | ||||
| 33321-30112 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33321A - BEARING (FOR OUTPUT SHAFT REAR) | ||||
| 90363-30032 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33321B - RING, SHAFT SNAP (FOR OUTPUT SHAFT BEARING) | ||||
| 90520-25005 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.67−2.72,ﾏｰｸ A |
1 | ||
| 90520-25006 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.73−2.78,ﾏｰｸ B |
1 | ||
| 90520-25009 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.79−2.84,ﾏｰｸ C |
1 | ||
| 90520-25010 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.85−2.90,ﾏｰｸ D |
1 | ||
| 90520-25012 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.97−3.02,ﾏｰｸ F |
1 | ||
| 90520-25013 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=3.03−3.08,ﾏｰｸ G |
1 | ||
| 90520-25014 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=3.09−3.14,ﾏｰｸ H |
1 | ||
| 90520-25011 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.91−2.96,ﾏｰｸ E |
1 | ||
| 90520-25016 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=3.21−3.26,ﾏｰｸ K |
1 | ||
| 90520-25015 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=3.15−3.20,ﾏｰｸ J |
1 | ||
| 90520-25017 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=3.27−3.32,ﾏｰｸ L |
1 | ||
| 33321C - RING, SHAFT SNAP (FOR OUTPUT SHAFT BEARING) | ||||
| 90520-71221 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=1.65,内径=71.1 |
1 | ||
| 33331 - GEAR, REVERSE | ||||
| 33031-30020 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33331A - BEARING (FOR REVERSE GEAR) | ||||
| 90364-38034 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33332 - GEAR, 2ND | ||||
| 33033-30021 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33332B - BEARING, NEEDLE ROLLER (FOR 2ND GEAR) | ||||
| 90364-35005 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33334 - GEAR, 4TH | ||||
| 33336-28020 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33335 - GEAR, 1ST | ||||
| 33032-30020 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33335C - BEARING, NEEDLE ROLLER(FOR 1ST GEAR) | ||||
| 90364-38002 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33344 - BUSH, REVERSE GEAR | ||||
| 33344-30010 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33344A - KEY OR BALL, REVERSE GEAR BEARING | ||||
| 90360-06004 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33349A - WASHER, 4TH GEAR | ||||
| 33349-30020 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33349B - BALL (FOR 4TH GEAR WASHER) | ||||
| 90360-06004 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33361 - HUB, TRANSMISSION CLUTCH, NO.1 | ||||
| 33361-35020 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33362 - HUB, TRANSMISSION CLUTCH, NO.2 | ||||
| 33362-30040 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33362A - RING, SHAFT SNAP (FOR CLUTCH HUB NO.2 SETTING) | ||||
| 90520-28012 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=1.75,ﾏｰｸ C−1 |
1 | ||
| 90520-28245 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=1.80−1.85,ﾏｰｸ D |
1 | ||
| 90520-28010 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=1.85,ﾏｰｸ D−1 |
1 | ||
| 90520-28248 |
GS136..4H..EFI;GS130,LS130,136,MS130,YS130..4H..(DSL,EFI,HTWC,LPG) 厚さ=2.00−2.05,ﾏｰｸ F |
1 | ||
| 90520-28011 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=1.95,ﾏｰｸ E−1 |
1 | ||
| 90520-28013 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.05,ﾏｰｸ F−1 |
1 | ||
| 90520-28246 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=1.90−1.95,ﾏｰｸ E |
1 | ||
| 33363 - SLEEVE, TRANSMISSION HUB, NO.1 | ||||
| 33364-30021 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33364 - SLEEVE, TRANSMISSION HUB, NO.2 | ||||
| 33364-30021 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33365 - KEY, SYNCHROMESH SHIFTING, NO.1 | ||||
| 33365-30050 |
GS130,136,LS130,136,MS130,YS130..4H |
3 | ||
| 33366 - KEY, SYNCHROMESH SHIFTING, NO.2 | ||||
| 33366-30031 |
GS130,136,LS130,136,MS130,YS130..4H |
3 | ||
| 33367 - RING, SYNCHRONIZER, NO.1 | ||||
| 33369-30020 |
GS130,136,LS13#,MS130,YS130..4H REVERSE |
1 | ||
| 33367-30040 |
GS130,136,LS13#,MS130,YS130..4H 1ST |
1 | ||
| 33367 - RING, SYNCHRONIZER, NO.1 | ||||
| 33369-30020 |
GS130,136,LS13#,MS130,YS130..4H REVERSE |
1 | ||
| 33367-30040 |
GS130,136,LS13#,MS130,YS130..4H 1ST |
1 | ||
| 33368 - RING, SYNCHRONIZER, NO.2 | ||||
| 33368-20012 |
GS130,136,LS130,136,MS130,YS130..4H |
2 | ||
| 33368 - RING, SYNCHRONIZER, NO.2 | ||||
| 33368-20012 |
GS130,136,LS130,136,MS130,YS130..4H |
2 | ||
| 33371 - SPRING, SYNCHROMESH SHIFTING KEY, NO.1 | ||||
| 33391-22020 |
GS130,136,LS130,136,MS130,YS130..4H |
2 | ||
| 33371 - SPRING, SYNCHROMESH SHIFTING KEY, NO.1 | ||||
| 33391-22020 |
GS130,136,LS130,136,MS130,YS130..4H |
2 | ||
| 33391 - SPRING, SYNCHROMESH SHIFTING KEY, NO.2 | ||||
| 33391-22020 |
GS130,136,LS130,136,MS130,YS130..4H |
2 | ||
| 33391 - SPRING, SYNCHROMESH SHIFTING KEY, NO.2 | ||||
| 33391-22020 |
GS130,136,LS130,136,MS130,YS130..4H |
2 | ||
| 33394 - KEY, SYNCHROMESH SHIFTING, NO.3 | ||||
| 33394-30010 |
GS130,136,LS13#,MS130,YS130..4H |
3 | ||
| 33395 - SLEEVE, TRANSMISSION HUB, NO.3 | ||||
| 33395-14013 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33402A - BUSH OR BEARING (FOR REVERSE IDLER GEAR) | ||||
| 90364-28006 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33411A - BEARING OR ROLLER(FOR COUNTER GEAR FRONT) | ||||
| 90365-25025 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33411E - NUT(FOR COUNTER GEAR SHAFT) | ||||
| 90179-20009 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33411P - BEARING, COUNTER SHAFT CENTER | ||||
| 90365-31002 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33421 - GEAR, COUNTER | ||||
| 33421-30130 |
GS130,136,LS13#,MS130,YS130..4H |
1 | ||
| 33421R - RING, SHAFT SNAP(FOR COUNTER GEAR REAR) | ||||
| 90520-19009 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.90 |
1 | ||
| 90520-19008 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.85 |
1 | ||
| 90520-19012 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=3.05 |
1 | ||
| 90520-19011 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=3.00 |
1 | ||
| 90520-19010 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=2.95 |
1 | ||
| 90520-19013 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=3.10 |
1 | ||
| 90520-19014 |
GS130,136,LS13#,MS130,YS130..4H 厚さ=3.15 |
1 | ||
| 33451 - SHAFT, REVERSE IDLER GEAR | ||||
| 33451-30040 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33452 - STOPPER, REVERSE IDLER GEAR SHAFT | ||||
| 33452-30010 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33461 - GEAR, REVERSE IDLER | ||||
| 33461-30030 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33462 - WASHER, REVERSE IDLER THRUST | ||||
| 33462-30020 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33481 - GEAR, SPEEDOMETER DRIVE (MTM) | ||||
| 33481-30040 |
GS130,MS130..SED..4H 歯数=6,ﾏｰｸ 6X21−23 |
1 | ||
| 33481A - KEY OR BALL, SPEEDOMETER DRIVE GEAR (MTM) | ||||
| 90360-06004 |
GS130,136,LS130,136,MS130,YS130..4H |
1 | ||
| 33481B - RING OR SPACER (FOR MTM SPEEDOMETER DRIVE GEAR) | ||||
| 90520-26179 |
GS130,136,LS130,136,MS130,YS130..4H 厚さ=1.50,外径=31.3 |
2 | ||
| 33481B - RING OR SPACER (FOR MTM SPEEDOMETER DRIVE GEAR) | ||||
| 90520-26179 |
GS130,136,LS130,136,MS130,YS130..4H 厚さ=1.50,外径=31.3 |
2 | ||
| Common parts | ||||
| 91611-60820 | ||||
(9110-9512)4H
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 91611-60820 | ||||
