GS130-AEPFK (1991)
Toyota Crown
(9110- )GS130,LS130..SED..DLX,SALEX,SDX ; (9112- )YS130..DLX,DLXA
YS130..DLX,DLXA(ｶｺﾞｼﾏ ｼﾖｳ)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52023 - REINFORCEMENT SUB-ASSY, REAR BUMPER | ||||
| 52023-30140 |
GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52067 - SUPPORT SUB-ASSY, REAR BUMPER SIDE, RH | ||||
| 52067-30050 |
GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52068 - SUPPORT SUB-ASSY, REAR BUMPER SIDE, LH | ||||
| 52068-30050 |
GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52152B - EXTENSION, REAR BUMPER, RH | ||||
| 52152-30130A0 |
GS130,LS130..SED..(SALEX,SDX) SUPER WHITE 4,050 |
1 | ||
| 52152-30130C0 |
GS130,LS130..SED..(SALEX,SDX) BLACK,202 |
1 | ||
| 52152-30130B0 |
GS130,LS130..SED..(SALEX,SDX) SUPER SILVER 3 M,176 |
1 | ||
| 52152-30130B1 |
GS130,LS130..SED..(SALEX,SDX) DK.BL.GRAY ME,183 |
1 | ||
| 52152-30130A1 |
GS130,LS130..SED..(SALEX,SDX) SUPER WHITE 2,040 |
1 | ||
| 52152-30130H0 |
GS130,LS130..SED..(SALEX,SDX) DK.TURQUOISE.MC,742 |
1 | ||
| 52152-30130B2 |
GS130,LS130..SED..(SALEX,SDX) SILVER ME,199 |
1 | ||
| 52152-30130J0 |
GS130,LS130..SED..(SALEX,SDX) DK.BLUE MCFP,8J5 |
1 | ||
| 52153B - EXTENSION, REAR BUMPER, LH | ||||
| 52153-30070B0 |
GS130,LS130..SED..(SALEX,SDX) SUPER SILVER 3 M,176 |
1 | ||
| 52153-30070A0 |
GS130,LS130..SED..(SALEX,SDX) SUPER WHITE 4,050 |
1 | ||
| 52153-30070B1 |
GS130,LS130..SED..(SALEX,SDX) DK.BL.GRAY ME,183 |
1 | ||
| 52153-30070A1 |
GS130,LS130..SED..(SALEX,SDX) SUPER WHITE 2,040 |
1 | ||
| 52153-30070C0 |
GS130,LS130..SED..(SALEX,SDX) BLACK,202 |
1 | ||
| 52153-30070J0 |
GS130,LS130..SED..(SALEX,SDX) DK.BLUE MCFP,8J5 |
1 | ||
| 52153-30070B2 |
GS130,LS130..SED..(SALEX,SDX) SILVER ME,199 |
1 | ||
| 52153-30070H0 |
GS130,LS130..SED..(SALEX,SDX) DK.TURQUOISE.MC,742 |
1 | ||
| 52155C - SUPPORT, REAR BUMPER SIDE, NO.1 RH | ||||
| 52155-30040 |
GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52156C - SUPPORT, REAR BUMPER SIDE, NO.1 LH | ||||
| 52155-30040 |
GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52159 - COVER, REAR BUMPER | ||||
| 52159-30140A1 |
LS130..SDX;GS130..SALEX,SDX SUPER WHITE 4,050 |
1 | ||
| 52159-30140B3 |
GS130,LS130..SED..(SALEX,SDX) DK.BL.GRAY ME,183 |
1 | ||
| 52159-30140B2 |
LS130..SDX;GS130..SALEX,SDX SUPER SILVER 3 M,176 |
1 | ||
| 52159-30140J1 |
LS130..SDX;GS130..SALEX,SDX DK.BLUE MCFP,8J5 |
1 | ||
| 52159-30140C1 |
GS130,LS130..SED..(SALEX,SDX) BLACK,202 |
1 | ||
| 52159-30140H0 |
GS130,LS130..SED..(SALEX,SDX) DK.TURQUOISE.MC,742 |
1 | ||
| 52159-30140B3 |
LS130..SDX;GS130..SALEX,SDX DK.BL.GRAY ME,183 |
1 | ||
| 52159-30140A2 |
GS130..WG..SDX;GS130,LS130..SED..(SALEX,SDX) SUPER WHITE 2,040 |
1 | ||
| 52159-30140B4 |
GS130..WG..SDX;GS130,LS130..SED..(SALEX,SDX) SILVER ME,199 |
1 | ||
| 52552 - FILLER, REAR BUMPER, RH | ||||
| 52506-30040 |
GS130,LS130,YS130..SED..(DLX,DLXA,SALEX,SDX,STD) |
1 | ||
| 52506-30040 |
GS130,LS130..SED |
1 | ||
| 52553 - FILLER, REAR BUMPER, LH | ||||
| 52507-30040 |
GS130,LS130,YS130..SED..(DLX,DLXA,SALEX,SDX,STD) |
1 | ||
| 52507-30040 |
GS130,LS130..SED |
1 | ||
| 52561 - RETAINER, REAR BUMPER, UPPER CENTER | ||||
| 52561-30030 |
GS130..WG..SDX;GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52565A - RETAINER, REAR BUMPER, LOWER | ||||
| 52565-30020 |
JZS130;GS130,LS130..SALEX,SDX |
1 | ||
| 52567C - RETAINER, REAR BUMPER LOWER SIDE, RH | ||||
| 52567-30050 |
GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52568C - RETAINER, REAR BUMPER LOWER SIDE, LH | ||||
| 52568-30040 |
GS130..WG..SDX;GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52575 - RETAINER, REAR BUMPER SIDE, RH | ||||
| 52575-30040 |
GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52576 - RETAINER, REAR BUMPER SIDE, LH | ||||
| 52576-30040 |
GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52579 - RETAINER, REAR BUMPER SIDE, NO.3 | ||||
| 52579-30020 |
GS130,LS130..SED..(SALEX,SDX) |
2 | ||
| 52581 - PROTECTOR, REAR BUMPER, RH | ||||
| 52581-22021 |
GS130,LS130..SED |
1 | ||
| 52581-22021 |
GS130,LS130,YS130..SED..(DLX,DLXA,SALEX,SDX,STD) |
1 | ||
| 52582 - PROTECTOR, REAR BUMPER, LH | ||||
| 52581-22021 |
GS130,LS130,YS130..SED..(DLX,DLXA,SALEX,SDX,STD) |
1 | ||
| 52581-22021 |
GS130,LS130..SED |
1 | ||
| 52589 - RETAINER, REAR BUMPER END, NO.2 | ||||
| 52589-30030 |
GS130,LS130..SED..(SALEX,SDX) |
2 | ||
| 52615 - ABSORBER, REAR BUMPER ENERGY | ||||
| 52615-30120 |
GS130..WG..SDX;GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52751 - MOULDING, REAR BUMPER | ||||
| 52751-30030 |
GS130..WG..SDX;GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52751-30050 |
GS130,LS130..SED..(SALEX,SDX) ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 52752 - MOULDING, REAR BUMPER SIDE, RH | ||||
| 52752-30090 |
GS130,LS130..SED..(SALEX,SDX) ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 52752-30080 |
GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52753 - MOULDING, REAR BUMPER SIDE, LH | ||||
| 52753-30080 |
GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| 52753-30090 |
GS130,LS130..SED..(SALEX,SDX) ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 52754 - MOULDING, REAR BUMPER, NO.2 | ||||
| 52754-30090 |
GS130,LS130..SED..(SALEX,SDX) |
1 | ||
| Common parts | ||||
| 90109-06081 | ||||
| 90109-06083 | ||||
| 90119-12162 | ||||
| 90159-40235 | ||||
| 90159-60336 | ||||
| 90179-05004 | ||||
| 90179-06007 | ||||
| 90183-03007 | ||||
| 90189-06191 | ||||
| 90430-05008 | ||||
| 90467-09029 | ||||
| 90468-04150 | ||||
| 90541-07029 | ||||
| 91661-60616 | ||||
| Linked diagrams | ||||
| 6101 | ||||
