GS120-STPZE (1983)
Toyota Crown
(8308- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81850 - LAMP ASSY, INDICATOR | ||||
| 81850-30260 |
GS120..HT..4FC ATM SHIFT |
1 | ||
| 81850-30260 |
GS120,LS120..HT..4FC ATM SHIFT |
1 | ||
| 81850-30310 |
GS12#,LS12#,MS120,YS120..(4FC,5F)..(DLX,SAL,SDX,SPE,SSL,STD) CONSOLE |
1 | ||
| 81850-30260 |
GS120,LS120..HT..4FC ATM SHIFT |
1 | ||
| 81850 - LAMP ASSY, INDICATOR | ||||
| 81850-30260 |
GS120..HT..4FC ATM SHIFT |
1 | ||
| 81850-30260 |
GS120,LS120..HT..4FC ATM SHIFT |
1 | ||
| 81850-30310 |
GS12#,LS12#,MS120,YS120..(4FC,5F)..(DLX,SAL,SDX,SPE,SSL,STD) CONSOLE |
1 | ||
| 81850-30260 |
GS120,LS120..HT..4FC ATM SHIFT |
1 | ||
| 81850 - LAMP ASSY, INDICATOR | ||||
| 81850-30260 |
GS120..HT..4FC ATM SHIFT |
1 | ||
| 81850-30260 |
GS120,LS120..HT..4FC ATM SHIFT |
1 | ||
| 81850-30310 |
GS12#,LS12#,MS120,YS120..(4FC,5F)..(DLX,SAL,SDX,SPE,SSL,STD) CONSOLE |
1 | ||
| 81850-30260 |
GS120,LS120..HT..4FC ATM SHIFT |
1 | ||
| 81850B - BULB, INDICATOR LAMP | ||||
| 84999-20020 |
GS120,LS120..HT..4FC ATM SHIFT,12V 1.4W |
7 | ||
| 84999-20030 |
GS120,LS120..HT..4FC ATM SHIFT,12V 1.4W W/GREEN CAP |
1 | ||
| 84999-20020 |
GS120..HT..4FC ATM SHIFT,12V 1.4W |
7 | ||
| 84999-20030 |
GS120..HT..4FC ATM SHIFT,12V 1.4W W/GREEN CAP |
1 | ||
| 90981-11018 |
GS12#,LS12#,MS12#,YS120..4FC,4HC,5F 12V 1.2W ｿｹｯﾄ無し,WARNING & CONSOLE,12V 1.4W |
8 | ||
| 81850B - BULB, INDICATOR LAMP | ||||
| 84999-20020 |
GS120,LS120..HT..4FC ATM SHIFT,12V 1.4W |
7 | ||
| 84999-20030 |
GS120,LS120..HT..4FC ATM SHIFT,12V 1.4W W/GREEN CAP |
1 | ||
| 84999-20020 |
GS120..HT..4FC ATM SHIFT,12V 1.4W |
7 | ||
| 84999-20030 |
GS120..HT..4FC ATM SHIFT,12V 1.4W W/GREEN CAP |
1 | ||
| 90981-11018 |
GS12#,LS12#,MS12#,YS120..4FC,4HC,5F 12V 1.2W ｿｹｯﾄ無し,WARNING & CONSOLE,12V 1.4W |
8 | ||
| 81850B - BULB, INDICATOR LAMP | ||||
| 84999-20020 |
GS120,LS120..HT..4FC ATM SHIFT,12V 1.4W |
7 | ||
| 84999-20030 |
GS120,LS120..HT..4FC ATM SHIFT,12V 1.4W W/GREEN CAP |
1 | ||
| 84999-20020 |
GS120..HT..4FC ATM SHIFT,12V 1.4W |
7 | ||
| 84999-20030 |
GS120..HT..4FC ATM SHIFT,12V 1.4W W/GREEN CAP |
1 | ||
| 90981-11018 |
GS12#,LS12#,MS12#,YS120..4FC,4HC,5F 12V 1.2W ｿｹｯﾄ無し,WARNING & CONSOLE,12V 1.4W |
8 | ||
| 81850B - BULB, INDICATOR LAMP | ||||
| 84999-20020 |
GS120,LS120..HT..4FC ATM SHIFT,12V 1.4W |
7 | ||
| 84999-20030 |
GS120,LS120..HT..4FC ATM SHIFT,12V 1.4W W/GREEN CAP |
1 | ||
| 84999-20020 |
GS120..HT..4FC ATM SHIFT,12V 1.4W |
7 | ||
| 84999-20030 |
GS120..HT..4FC ATM SHIFT,12V 1.4W W/GREEN CAP |
1 | ||
| 90981-11018 |
GS12#,LS12#,MS12#,YS120..4FC,4HC,5F 12V 1.2W ｿｹｯﾄ無し,WARNING & CONSOLE,12V 1.4W |
8 | ||
| 81930 - LAMP ASSY, HEATER CONTROL INDICATOR, NO.1 | ||||
| 81930-30200 |
GS120,121,LS120,MS12#..(HT,SED)..(ROY,SAL,SDX,SPE)..(EFI,TBO,TD,TDE,TWC) W/*AAC |
1 | ||
| 81930-30180 |
GS12#,LS12#,MS120..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE)..(DSL,EFI,TBO,TD,TDE,TWC) |
1 | ||
| 81930-30190 |
GS12#,LS12#,MS120..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE)..(DSL,EFI,TBO,TD,TDE,TWC) W/*AIC |
1 | ||
| 81930-30181 |
GS12#,LS12#,MS120..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE)..(DSL,EFI,TBO,TD,TDE,TWC) |
1 | ||
| 81930-30200 |
GS120,LS120,MS12#..(HT,SED)..(ROY,SAL,SDX,SPE)..(EFI,TBO,TD,TDE,TWC) W/*AAC |
1 | ||
| 81930-30210 |
GS120,126,LS12#..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE,SSL) |
1 | ||
| 81930-30191 |
GS120,LS120,MS12#..(HT,SED)..(ROY,SAL,SDX,SPE)..(EFI,TBO,TD,TDE,TWC) W/*AAC |
1 | ||
| 81930-30231 |
GS12#,LS12#,MS120..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE)..(DSL,EFI,TBO,TD,TDE,TWC) W/*AIC |
1 | ||
| 81930-30220 |
GS120,126,LS12#..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE,SSL) W/COOLER |
1 | ||
| 81930 - LAMP ASSY, HEATER CONTROL INDICATOR, NO.1 | ||||
| 81930-30200 |
GS120,121,LS120,MS12#..(HT,SED)..(ROY,SAL,SDX,SPE)..(EFI,TBO,TD,TDE,TWC) W/*AAC |
1 | ||
| 81930-30180 |
GS12#,LS12#,MS120..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE)..(DSL,EFI,TBO,TD,TDE,TWC) |
1 | ||
| 81930-30190 |
GS12#,LS12#,MS120..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE)..(DSL,EFI,TBO,TD,TDE,TWC) W/*AIC |
1 | ||
| 81930-30181 |
GS12#,LS12#,MS120..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE)..(DSL,EFI,TBO,TD,TDE,TWC) |
1 | ||
| 81930-30200 |
GS120,LS120,MS12#..(HT,SED)..(ROY,SAL,SDX,SPE)..(EFI,TBO,TD,TDE,TWC) W/*AAC |
1 | ||
| 81930-30210 |
GS120,126,LS12#..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE,SSL) |
1 | ||
| 81930-30191 |
GS120,LS120,MS12#..(HT,SED)..(ROY,SAL,SDX,SPE)..(EFI,TBO,TD,TDE,TWC) W/*AAC |
1 | ||
| 81930-30231 |
GS12#,LS12#,MS120..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE)..(DSL,EFI,TBO,TD,TDE,TWC) W/*AIC |
1 | ||
| 81930-30220 |
GS120,126,LS12#..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE,SSL) W/COOLER |
1 | ||
| 81931A - COVER, COOLER SWITCH HOLE | ||||
| 55538-30070 |
GS12#,LS12#,MS120..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE)..(DSL,EFI,TBO,TD,TDE,TWC) |
1 | ||
| 55538-30071 |
GS12#,LS12#..(4FC,4HC,5F)..(DLX,SAL,SDX,SPE,SSL) |
1 | ||
| Common parts | ||||
| 88569-30870 | ||||
| 90167-45002 | ||||
| 93510-13008 | ||||
| 93560-55016 | ||||
| Linked diagrams | ||||
| 3312 | ||||
