GRS210-AETQH (2012)
Toyota Crown/Hybrid
(1212- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 42304 - CARRIER SUB-ASSY, REAR AXLE, RH | ||||
| 42304-30140 |
AWS210,211,GRS210,211..ROY,ROYAL,ROYG |
1 | ||
| 42305 - CARRIER SUB-ASSY, REAR AXLE, LH | ||||
| 42305-30140 |
AWS210,211,GRS210,211..ROY,ROYAL,ROYG |
1 | ||
| 48231A - SPRING, COIL, REAR RH | ||||
| 48231-30D80 |
GRS210..ROY,ROYAL,ROYG |
1 | ||
| 48231-30D81 |
GRS210..ROY,ROYAL,ROYG |
1 | ||
| 48231B - SPRING, COIL, REAR LH | ||||
| 48231-30D80 |
GRS210..ROY,ROYAL,ROYG |
1 | ||
| 48231-30D81 |
GRS210..ROY,ROYAL,ROYG |
1 | ||
| 48257A - INSULATOR, REAR COIL SPRING, LOWER | ||||
| 48158-30020 |
AWS21#,GRS21#,GWS214 |
2 | ||
| 48257C - INSULATOR, REAR COIL SPRING, UPPER RH | ||||
| 48257-30070 |
AWS210,GRS21#,GWS214 |
1 | ||
| 48257-30100 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48259A - INSULATOR, REAR COIL SPRING, UPPER LH | ||||
| 48257-30070 |
AWS210,GRS21#,GWS214 |
1 | ||
| 48257-30100 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48341A - BUMPER, REAR SPRING, NO.1 RH | ||||
| 48341-30130 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48341B - BUMPER, REAR SPRING, NO.1 LH | ||||
| 48341-30130 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48409 - CAM SUB-ASSY, REAR SUSPENSION TOE ADJUST | ||||
| 48409-30020 |
AWS21#,GRS21#,GWS214 |
2 | ||
| 48452R - PLATE, REAR SUSPENSION TOE ADJUST, NO.2 | ||||
| 48452-30040 |
AWS21#,GRS21#,GWS214 |
2 | ||
| 48530 - ABSORBER ASSY, SHOCK, REAR RH | ||||
| 48530-80656 |
GRS210..ROY,ROYAL,ROYG ﾏｰｸ 48530−30B30 |
1 | ||
| 48530B - WASHER, REAR SHOCK ABSORBER CUSHION, NO.1 | ||||
| 90948-03021 |
AWS21#,GRS21#,GWS214 |
2 | ||
| 48530G - CUSHION, REAR SHOCK ABSORBER, NO.1 | ||||
| 90948-01092 |
AWS21#,GRS21#,GWS214 |
2 | ||
| 48530K - CUSHION, REAR SHOCK ABSORBER, NO.2 | ||||
| 90948-01093 |
AWS21#,GRS21#,GWS214 |
2 | ||
| 48540 - ABSORBER ASSY, SHOCK, REAR LH | ||||
| 48530-80656 |
GRS210..ROY,ROYAL,ROYG ﾏｰｸ 48530−30B30 |
1 | ||
| 48705 - LINK SUB-ASSY, TOE CONTROL, RH | ||||
| 48705-30140 |
AWS210,211,GRS210,211..ROY,ROYAL,ROYG |
1 | ||
| 48706B - LINK SUB-ASSY, TOE CONTROL, LH | ||||
| 48706-30080 |
AWS210,211,GRS210,211..ROY,ROYAL,ROYG |
1 | ||
| 48710A - ARM ASSY, REAR SUSPENSION, NO.1 RH | ||||
| 48710-30230 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48720A - ARM ASSY, REAR SUSPENSION, NO.1 LH | ||||
| 48710-30230 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48730F - ARM ASSY, REAR SUSPENSION, NO.2 RH | ||||
| 48730-30130 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48740F - ARM ASSY, REAR SUSPENSION, NO.2 LH | ||||
| 48740-30130 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48750H - SUPPORT ASSY, REAR SUSPENSION, RH | ||||
| 48750-30150 |
AWS210,GRS21#,GWS214 |
1 | ||
| 48750-30151 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48750J - NUT(FOR REAR SUPPORT TO REAR SHOCK ABSORBER RH) | ||||
| 90179-12127 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48750K - COLLAR(FOR REAR SUPPORT TO REAR SHOCK ABSORBER RH) | ||||
| 90387-12050 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48760B - SUPPORT ASSY REAR SUSPENSION, LH | ||||
| 48750-30151 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48750-30150 |
AWS210,GRS21#,GWS214 |
1 | ||
| 48760C - NUT(FOR REAR SUPPORT TO REAR SHOCK ABSORBER LH) | ||||
| 90179-12127 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48760D - COLLAR(FOR REAR SUPPORT TO REAR SHOCK ABSORBER LH) | ||||
| 90387-12050 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48770J - ARM ASSY, UPPER CONTROL, REAR NO.1 | ||||
| 48770-30130 |
AWS210,211,GRS210,211..ROY,ROYAL,ROYG |
2 | ||
| 48780G - ARM ASSY, UPPER CONTROL, REAR NO.2 LH | ||||
| 48780-30070 |
AWS210,211,GRS210,211..ROY,ROYAL,ROYG |
1 | ||
| 48790D - ARM ASSY, UPPER CONTROL, REAR NO.2 | ||||
| 48790-30150 |
AWS210,211,GRS210,211..ROY,ROYAL,ROYG |
1 | ||
| 48812 - BAR, STABILIZER, REAR | ||||
| 48812-30520 |
AWS211,GRS211;AWS210,215,GRS210..MJ,ROY,ROYAL,ROYG |
1 | ||
| 48818 - BUSH, STABILIZER, REAR | ||||
| 48818-30160 |
AWS211,GRS211;AWS210,215,GRS210..MJ,ROY,ROYAL,ROYG |
2 | ||
| 48824R - BRACKET, STABILIZER(FOR REAR) | ||||
| 48832-30060 |
AWS21#,GRS21#,GWS214 |
2 | ||
| 48830A - NUT(FOR REAR STABILIZER LINK) | ||||
| 90179-12151 |
AWS21#,GRS21#,GWS214 |
2 | ||
| 48830D - LINK ASSY, REAR STABILIZER, RH | ||||
| 48830-30090 |
AWS21#,GRS21#,GWS214 |
1 | ||
| 48840A - LINK ASSY, REAR STABILIZER, LH | ||||
| 48830-30090 |
AWS21#,GRS21#,GWS214 |
1 | ||
| Common parts | ||||
| 90105-14200 | ||||
| 90105-14202 | ||||
| 90110-12009 | ||||
| 90119-14188 | ||||
| 90170-12030 | ||||
| 90177-12001 | ||||
| 90178-10014 | ||||
| 90179-14044 | ||||
| 90179-14068 | ||||
| 91551-G0875 | ||||
| 91672-G1265 | ||||
| 91674-80814 | ||||
| 91674-80820 | ||||
| 94151-20801 | ||||
| 94151-21200 | ||||
| 94151-21441 | ||||
| 94622-51400 | ||||
| Linked diagrams | ||||
| 8414 | ||||
| 8419 | ||||
