UZS145-ATPZK (1992)
Toyota Crown/Crown Majesta
(9110-9308)1UZFE
12V 110A
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27060-50100 |
1UZFE..UZS143,145 12V 100A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-50090 |
1UZFE..UZS143,145 |
1 | ||
| 27039-50090 |
1UZFE..UZS14# |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-50090 |
1UZFE..UZS143,145 |
1 | ||
| 27039-50090 |
1UZFE..UZS14# |
1 | ||
| 27064 - SEAL, ALTERNATOR PLATE | ||||
| 27064-42010 |
1JZGE,2JZGE,2LT#,1UZFE..JZS14#,LS141,UZS14# |
1 | ||
| 27113 - PLATE, BEARING RETAINER, ALTERNATOR | ||||
| 27312-42010 |
1JZGE,2JZGE,1UZFE..JZS14#,UZS14# |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-50060 |
1UZFE..UZS143,145 |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10192 |
1JZGE,2JZGE,1UZFE..JZS14#,UZS14# |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-50070 |
1UZFE..UZS143,145 |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10194 |
1JZGE,2JZGE,1UZFE..JZS14#,UZS14# |
1 | ||
| 27357 - HOLDER, ALTERNATOR, W/RECTIFIER | ||||
| 27357-74170 |
1UZFE..UZS143,145 |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-50030 |
1UZFE..UZS14# |
1 | ||
| 27370A - HOLDER ASSY, ALTERNATOR BRUSH | ||||
| 27370-75060 |
1JZGE,2JZGE,2LT#,1UZFE..JZS14#,LS141,UZS14# |
1 | ||
| 27384 - WASHER | ||||
| 27384-50030 |
1JZGE,2JZGE,2LT#,1UZFE..JZS14#,LS141,UZS14# |
1 | ||
| 27388 - COVER, ALTERNATOR BRUSH | ||||
| 27388-42010 |
1JZGE,2JZGE,2LT#,1UZFE..JZS14#,LS141,UZS14# |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-43200 |
1UZFE..UZS143,145 |
1 | ||
| 27443 - COVER, ALTERNATOR BEARING | ||||
| 27443-63020 |
1GFE,1JZGE,2JZGE,2LT#,1UZFE..GS141,JZS14#,LS141,UZS14# |
1 | ||
| 27700A - REGULATOR ASSY, GENERATOR | ||||
| 27700-46050 |
1UZFE..UZS143,145 |
1 | ||
| 27700-74030 |
1UZFE..UZS143,145 |
1 | ||
| 27700-46050 |
1UZFE..UZS14# |
1 | ||
| Common parts | ||||
| 27381-50030 | ||||
| 27387-42040 | ||||
| 27389-42010 | ||||
| 27412-50030 | ||||
| 90093-00510 | ||||
| 90099-00195 | ||||
| 90099-00197 | ||||
| 90099-04436 | ||||
| 90099-04966 | ||||
| 90099-05171 | ||||
| 90099-05172 | ||||
| 90099-05231 | ||||
| 90119-10554 | ||||
| 90179-08146 | ||||
| 90179-10144 | ||||
| 93319-14025 | ||||
(9210-9508)1UZFE ; (9308-9508)1UZFE
12V 100A & 12V 110A
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27060-50100 |
1UZFE..UZS143,145 12V 100A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-50090 |
1UZFE..UZS143,145 |
1 | ||
| 27039-50090 |
1UZFE..UZS14# |
1 | ||
| 27064 - SEAL, ALTERNATOR PLATE | ||||
| 27064-42010 |
1JZGE,2JZGE,2LT#,1UZFE..JZS14#,LS141,UZS14# |
1 | ||
| 27113 - PLATE, BEARING RETAINER, ALTERNATOR | ||||
| 27312-42010 |
1JZGE,2JZGE,1UZFE..JZS14#,UZS14# |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-50060 |
1UZFE..UZS143,145 |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10192 |
1JZGE,2JZGE,1UZFE..JZS14#,UZS14# |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-50070 |
1UZFE..UZS143,145 |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10194 |
1JZGE,2JZGE,1UZFE..JZS14#,UZS14# |
1 | ||
| 27357 - HOLDER, ALTERNATOR, W/RECTIFIER | ||||
| 27357-74170 |
1UZFE..UZS143,145 |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-50030 |
1UZFE..UZS14# |
1 | ||
| 27365 - PLATE, TERMINAL | ||||
| 27365-55080 |
1JZGE,2JZGE,2LTE,1UZFE..JZS14#,LS141,UZS14# |
1 | ||
| 27365-55080 |
2JZGE,1UZFE..JZS147,149,UZS14# |
1 | ||
| 27370A - HOLDER ASSY, ALTERNATOR BRUSH | ||||
| 27370-75060 |
1JZGE,2JZGE,2LT#,1UZFE..JZS14#,LS141,UZS14# |
1 | ||
| 27384 - WASHER | ||||
| 27384-50030 |
1JZGE,2JZGE,2LT#,1UZFE..JZS14#,LS141,UZS14# |
1 | ||
| 27388 - COVER, ALTERNATOR BRUSH | ||||
| 27388-42010 |
1JZGE,2JZGE,2LT#,1UZFE..JZS14#,LS141,UZS14# |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-43200 |
1UZFE..UZS143,145 |
1 | ||
| 27443 - COVER, ALTERNATOR BEARING | ||||
| 27443-63020 |
1GFE,1JZGE,2JZGE,2LT#,1UZFE..GS141,JZS14#,LS141,UZS14# |
1 | ||
| 27446 - CLIP, ALTERNATOR CORD | ||||
| 27446-62012 |
1UZFE..UZS143,145 |
1 | ||
| 27446-46130 |
1JZGE,2JZGE,1UZFE..JZS141,143,145,UZS143,145 |
1 | ||
| 27700A - REGULATOR ASSY, GENERATOR | ||||
| 27700-46050 |
1UZFE..UZS143,145 |
1 | ||
| 27700-74030 |
1UZFE..UZS143,145 |
1 | ||
| 27700-46050 |
1UZFE..UZS14# |
1 | ||
| Common parts | ||||
| 27387-42040 | ||||
| 27389-42010 | ||||
| 90099-00195 | ||||
| 90099-00197 | ||||
| 90099-00243 | ||||
| 90099-00246 | ||||
| 90099-04966 | ||||
| 90099-05171 | ||||
| 90099-05172 | ||||
| 90099-05231 | ||||
| 90119-10554 | ||||
| 90179-08146 | ||||
| 90179-10144 | ||||
| 93319-14025 | ||||
