LS151H-ATPQT (1995)
Toyota Crown/Crown Majesta
(9508- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81205C - BULB, ASH RECEPTACLE LAMP, REAR RH | ||||
| 90981-11041 |
GS151,JZS15#,LS151,UZS15# |
1 | ||
| 81205D - BULB, ASH RECEPTACLE LAMP, REAR LH | ||||
| 90981-11041 |
GS151,JZS15#,LS151,UZS15# |
1 | ||
| 81230 - LAMP ASSY, COURTESY | ||||
| 81230-30150 |
GS151,JZS15#,LS151,UZS15# |
4 | ||
| 81230A - LAMP ASSY, COURTESY, NO.2 | ||||
| 81230-34010 |
GS151,JZS15#,LS151..ROY,ROYEX,ROYG,ROYT,SALEX,SPDLX |
1 | ||
| 81230B - BULB(FOR COURTESY LAMP) | ||||
| 90981-11020 |
GS151,JZS15#,LS151,UZS15# 12V 3.8W |
4 | ||
| 81230C - BULB(FOR COURTESY LAMP NO.2) | ||||
| 99132-12050 |
GS151,JZS15#,LS151..ROY,ROYEX,ROYG,ROYT,SALEX,SPDLX 12V 5W |
1 | ||
| 81231 - LENS, COURTESY LAMP | ||||
| 81231-30150 |
GS151,JZS15#,LS151,UZS15# |
4 | ||
| 81250B - BULB, ROOM LAMP, NO.2 | ||||
| 99132-12050 |
JZS153;LS151..NOB;GS151,JZS157,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) 12V 5W |
2 | ||
| 81250B - BULB, ROOM LAMP, NO.2 | ||||
| 99132-12050 |
JZS153;LS151..NOB;GS151,JZS157,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) 12V 5W |
2 | ||
| 81250D - LAMP ASSY, REAR ROOM, RH | ||||
| 81250-30120B0 |
LS151..NOB;GS151,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX) ｱﾘ(ﾘﾔ ｵ-ﾄ ｴｱｺﾝ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81250-30130B0 |
JZS151,LS151..SALEX,SPDLX;GS151,JZS153,UZS157..HTWC,TWC;JZS151,155,LS151..HT..(E,ROY,ROYEX) ｱﾘ(ﾘﾔ ﾏﾆﾕｱﾙ ｴｱｺﾝ) OR ﾅｼ(ﾘﾔ ｴｱｺﾝ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81250-30120E0 |
LS151..NOB;GS151,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) ｱﾘ(ﾘﾔ ｵ-ﾄ ｴｱｺﾝ),QUARTZ,TRIM4# |
1 | ||
| 81250-30130E0 |
JZS151,LS151..SALEX,SPDLX;GS151,JZS153,UZS157..HTWC,TWC;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) ｱﾘ(ﾘﾔ ﾏﾆﾕｱﾙ ｴｱｺﾝ) OR ﾅｼ(ﾘﾔ ｴｱｺﾝ),QUARTZ,TRIM4# |
1 | ||
| 81250D - LAMP ASSY, REAR ROOM, RH | ||||
| 81250-30120B0 |
LS151..NOB;GS151,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX) ｱﾘ(ﾘﾔ ｵ-ﾄ ｴｱｺﾝ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81250-30130B0 |
JZS151,LS151..SALEX,SPDLX;GS151,JZS153,UZS157..HTWC,TWC;JZS151,155,LS151..HT..(E,ROY,ROYEX) ｱﾘ(ﾘﾔ ﾏﾆﾕｱﾙ ｴｱｺﾝ) OR ﾅｼ(ﾘﾔ ｴｱｺﾝ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81250-30120E0 |
LS151..NOB;GS151,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) ｱﾘ(ﾘﾔ ｵ-ﾄ ｴｱｺﾝ),QUARTZ,TRIM4# |
1 | ||
| 81250-30130E0 |
JZS151,LS151..SALEX,SPDLX;GS151,JZS153,UZS157..HTWC,TWC;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) ｱﾘ(ﾘﾔ ﾏﾆﾕｱﾙ ｴｱｺﾝ) OR ﾅｼ(ﾘﾔ ｴｱｺﾝ),QUARTZ,TRIM4# |
1 | ||
| 81251B - LENS, REAR ROOM LAMP, RH | ||||
| 81251-30120 |
JZS153;LS151..NOB;GS151,JZS157,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) |
2 | ||
| 81260 - LAMP ASSY, GLOVE BOX | ||||
| 81260-50010 |
GS151,JZS15#,LS151,UZS15# |
1 | ||
| 81260B - BULB(FOR GLOVE BOX) | ||||
| 90981-11018 |
GS151,JZS15#,LS151,UZS15# 12V 1.2W ｿｹｯﾄ無し |
1 | ||
| 90981-11018 |
GS151,JZS15#,LS151,UZS15# 12V 1.2W ｿｹｯﾄ無し |
1 | ||
| 81261B - LENS,GLOVE BOX LAMP | ||||
| 81261-50010 |
GS151,JZS15#,LS151,UZS15# |
1 | ||
| 81290D - LAMP ASSY, REAR ROOM, LH | ||||
| 81290-30130E0 |
LS151..NOB;GS151,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) ｱﾘ(ﾘﾔ ｵ-ﾄ ｴｱｺﾝ),QUARTZ,TRIM4# |
1 | ||
| 81290-30140E0 |
JZS151,LS151..SALEX,SPDLX;GS151,JZS153,UZS157..HTWC,TWC;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) ｱﾘ(ﾘﾔ ﾏﾆﾕｱﾙ ｴｱｺﾝ) OR ﾅｼ(ﾘﾔ ｴｱｺﾝ),QUARTZ,TRIM4# |
1 | ||
| 81290-30130B0 |
LS151..NOB;GS151,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX) ｱﾘ(ﾘﾔ ｵ-ﾄ ｴｱｺﾝ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81290-30140B0 |
JZS151,LS151..SALEX,SPDLX;GS151,JZS153,UZS157..HTWC,TWC;JZS151,155,LS151..HT..(E,ROY,ROYEX) ﾅｼ(ﾘﾔ ｴｱｺﾝ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81290D - LAMP ASSY, REAR ROOM, LH | ||||
| 81290-30130E0 |
LS151..NOB;GS151,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) ｱﾘ(ﾘﾔ ｵ-ﾄ ｴｱｺﾝ),QUARTZ,TRIM4# |
1 | ||
| 81290-30140E0 |
JZS151,LS151..SALEX,SPDLX;GS151,JZS153,UZS157..HTWC,TWC;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) ｱﾘ(ﾘﾔ ﾏﾆﾕｱﾙ ｴｱｺﾝ) OR ﾅｼ(ﾘﾔ ｴｱｺﾝ),QUARTZ,TRIM4# |
1 | ||
| 81290-30130B0 |
LS151..NOB;GS151,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX) ｱﾘ(ﾘﾔ ｵ-ﾄ ｴｱｺﾝ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81290-30140B0 |
JZS151,LS151..SALEX,SPDLX;GS151,JZS153,UZS157..HTWC,TWC;JZS151,155,LS151..HT..(E,ROY,ROYEX) ﾅｼ(ﾘﾔ ｴｱｺﾝ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81360B - BULB, STEP OR SPOT LAMP | ||||
| 90981-11041 |
GS151,JZS15#,LS151,UZS15# 14V 1.4W |
2 | ||
| Common parts | ||||
| 90164-40042 | ||||
| 90168-40080 | ||||
| 90468-06080 | ||||
| Linked diagrams | ||||
| 8401 | ||||
| 8715 | ||||
(9508- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81250B - BULB, ROOM LAMP, NO.2 | ||||
| 99132-12050 |
JZS153;LS151..NOB;GS151,JZS157,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) 12V 5W |
2 | ||
| 81250D - LAMP ASSY, REAR ROOM, RH | ||||
| 81250-30120B0 |
LS151..NOB;GS151,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX) ｱﾘ(ﾘﾔ ｵ-ﾄ ｴｱｺﾝ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81250-30130B0 |
JZS151,LS151..SALEX,SPDLX;GS151,JZS153,UZS157..HTWC,TWC;JZS151,155,LS151..HT..(E,ROY,ROYEX) ｱﾘ(ﾘﾔ ﾏﾆﾕｱﾙ ｴｱｺﾝ) OR ﾅｼ(ﾘﾔ ｴｱｺﾝ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81250-30120E0 |
LS151..NOB;GS151,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) ｱﾘ(ﾘﾔ ｵ-ﾄ ｴｱｺﾝ),QUARTZ,TRIM4# |
1 | ||
| 81250-30130E0 |
JZS151,LS151..SALEX,SPDLX;GS151,JZS153,UZS157..HTWC,TWC;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) ｱﾘ(ﾘﾔ ﾏﾆﾕｱﾙ ｴｱｺﾝ) OR ﾅｼ(ﾘﾔ ｴｱｺﾝ),QUARTZ,TRIM4# |
1 | ||
| 81251B - LENS, REAR ROOM LAMP, RH | ||||
| 81251-30120 |
JZS153;LS151..NOB;GS151,JZS157,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) |
2 | ||
| 81260A - LAMP ASSY, MAP | ||||
| 81260-30210B0 |
JZS15#,LS151,UZS15#..HT..(A,C,F,ROY,ROYG) ｱﾘ(ﾑ-ﾝﾙ-ﾌ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81260-30210E0 |
JZS15#,LS151,UZS15#..HT..(A,C,F,ROY,ROYG,ROYT) ｱﾘ(ﾑ-ﾝﾙ-ﾌ),QUARTZ,TRIM4# |
1 | ||
| 81260-30200B0 |
GS151,JZS15#,LS151,UZS15#..(A,C,E,F,ROY,ROYEX,ROYG,SALEX,SPDLX)..(HTWC,TDE,TWC) LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81260-30200E0 |
GS151,JZS15#,LS151,UZS15#..HTWC,TDE,TWC QUARTZ,TRIM4# |
1 | ||
| 81260A - LAMP ASSY, MAP | ||||
| 81260-30210B0 |
JZS15#,LS151,UZS15#..HT..(A,C,F,ROY,ROYG) ｱﾘ(ﾑ-ﾝﾙ-ﾌ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81260-30210E0 |
JZS15#,LS151,UZS15#..HT..(A,C,F,ROY,ROYG,ROYT) ｱﾘ(ﾑ-ﾝﾙ-ﾌ),QUARTZ,TRIM4# |
1 | ||
| 81260-30200B0 |
GS151,JZS15#,LS151,UZS15#..(A,C,E,F,ROY,ROYEX,ROYG,SALEX,SPDLX)..(HTWC,TDE,TWC) LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81260-30200E0 |
GS151,JZS15#,LS151,UZS15#..HTWC,TDE,TWC QUARTZ,TRIM4# |
1 | ||
| 81260C - BULB(FOR MAP LAMP) | ||||
| 90981-12005 |
GS151,JZS15#,LS151,UZS15# 12V 8W,NO.1 |
2 | ||
| 90981-14004 |
GS151,JZS15#,LS151,UZS15# 12V 8W,NO.2 |
1 | ||
| 81260C - BULB(FOR MAP LAMP) | ||||
| 90981-12005 |
GS151,JZS15#,LS151,UZS15# 12V 8W,NO.1 |
2 | ||
| 90981-14004 |
GS151,JZS15#,LS151,UZS15# 12V 8W,NO.2 |
1 | ||
| 81260C - BULB(FOR MAP LAMP) | ||||
| 90981-12005 |
GS151,JZS15#,LS151,UZS15# 12V 8W,NO.1 |
2 | ||
| 90981-14004 |
GS151,JZS15#,LS151,UZS15# 12V 8W,NO.2 |
1 | ||
| 81260C - BULB(FOR MAP LAMP) | ||||
| 90981-12005 |
GS151,JZS15#,LS151,UZS15# 12V 8W,NO.1 |
2 | ||
| 90981-14004 |
GS151,JZS15#,LS151,UZS15# 12V 8W,NO.2 |
1 | ||
| 81260C - BULB(FOR MAP LAMP) | ||||
| 90981-12005 |
GS151,JZS15#,LS151,UZS15# 12V 8W,NO.1 |
2 | ||
| 90981-14004 |
GS151,JZS15#,LS151,UZS15# 12V 8W,NO.2 |
1 | ||
| 81260C - BULB(FOR MAP LAMP) | ||||
| 90981-12005 |
GS151,JZS15#,LS151,UZS15# 12V 8W,NO.1 |
2 | ||
| 90981-14004 |
GS151,JZS15#,LS151,UZS15# 12V 8W,NO.2 |
1 | ||
| 81261 - LENS AND COVER, MAP LAMP | ||||
| 81261-50070 |
JZS15#,LS151,UZS15#..HT..(A,C,F,ROY,ROYG,ROYT) ｱﾘ(ﾑ-ﾝﾙ-ﾌ) |
1 | ||
| 81261-50060 |
GS151,JZS15#,LS151,UZS15# |
1 | ||
| 81261 - LENS AND COVER, MAP LAMP | ||||
| 81261-50070 |
JZS15#,LS151,UZS15#..HT..(A,C,F,ROY,ROYG,ROYT) ｱﾘ(ﾑ-ﾝﾙ-ﾌ) |
1 | ||
| 81261-50060 |
GS151,JZS15#,LS151,UZS15# |
1 | ||
| 81290D - LAMP ASSY, REAR ROOM, LH | ||||
| 81290-30130E0 |
LS151..NOB;GS151,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) ｱﾘ(ﾘﾔ ｵ-ﾄ ｴｱｺﾝ),QUARTZ,TRIM4# |
1 | ||
| 81290-30140E0 |
JZS151,LS151..SALEX,SPDLX;GS151,JZS153,UZS157..HTWC,TWC;JZS151,155,LS151..HT..(E,ROY,ROYEX,ROYT) ｱﾘ(ﾘﾔ ﾏﾆﾕｱﾙ ｴｱｺﾝ) OR ﾅｼ(ﾘﾔ ｴｱｺﾝ),QUARTZ,TRIM4# |
1 | ||
| 81290-30130B0 |
LS151..NOB;GS151,UZS157..F,ROY,ROYEX,SPDLX;JZS151,155,LS151..HT..(E,ROY,ROYEX) ｱﾘ(ﾘﾔ ｵ-ﾄ ｴｱｺﾝ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81290-30140B0 |
JZS151,LS151..SALEX,SPDLX;GS151,JZS153,UZS157..HTWC,TWC;JZS151,155,LS151..HT..(E,ROY,ROYEX) ﾅｼ(ﾘﾔ ｴｱｺﾝ),LT.BLUISH GRAY,TRIM1# |
1 | ||
| 81340 - LAMP ASSY, VANITY | ||||
| 81350-50070E0 |
GS151,JZS15#,LS151,UZS15#..(A,C,E,F,ROY,ROYEX,ROYG,ROYT,SALEX)..(HTWC,TDE,TWC) QUARTZ,TRIM4#,右側 |
1 | ||
| 81350-50070B1 |
GS151,JZS15#,LS151,UZS15#..(A,C,E,F,ROY,ROYEX,ROYG,SALEX)..(HTWC,TDE,TWC) LT.BLUISH GRAY,TRIM1#,右側 |
1 | ||
| 81340-50070B1 |
GS151,JZS15#,LS151,UZS15#..(A,C,E,F,ROY,ROYEX,ROYG,SALEX)..(HTWC,TDE,TWC) LT.BLUISH GRAY,TRIM1#,左側 |
1 | ||
| 81340-50070E0 |
GS151,JZS15#,LS151,UZS15#..(A,C,E,F,ROY,ROYEX,ROYG,ROYT,SALEX)..(HTWC,TDE,TWC) QUARTZ,TRIM4#,左側 |
1 | ||
| 81340B - BULB (FOR VANITY LAMP) | ||||
| 90981-14007 |
GS151,JZS15#,LS151,UZS15#..(A,C,E,F,ROY,ROYEX,ROYG,ROYT,SALEX)..(HTWC,TDE,TWC) 12V 3W |
2 | ||
| 81341 - LENS, VANITY LAMP | ||||
| 81341-50060 |
GS151,JZS15#,LS151,UZS15#..(A,C,E,F,ROY,ROYEX,ROYG,ROYT,SALEX)..(HTWC,TDE,TWC) |
2 | ||
| 81870D - LAMP ASSY, KEY CYLINDER | ||||
| 81870-30100 |
GS151,JZS15#,LS151,UZS15# |
1 | ||
| 81870-22050 |
GS151,JZS15#,LS151,UZS15# |
1 | ||
| 81870E - BULB, KEY CYLINDER LAMP | ||||
| 90981-11014 |
GS151,JZS15#,LS151,UZS15# 14V 1.4W |
1 | ||
| 81870F - CAP, KEY CYLINDER LAMP BULB | ||||
| 84998-10080 |
GS151,JZS15#,LS151,UZS15# |
1 | ||
| Common parts | ||||
| 90157-40018 | ||||
| 90159-50151 | ||||
| 90160-40021 | ||||
