JZS151-ATPSF (1995)
Toyota Crown/Crown Majesta
(9508- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69503 - CYLINDER SET, LOCK | ||||
| 69005-30650 |
GS151,JZS151,153,LS151..ROYEX |
1 | ||
| 69503B - KEY, CUT | ||||
| 69515-30160 |
JZS15#,LS151,UZS15#..A,C,E,F,ROY,ROYG,ROYT ﾏｽﾀｰｷｰ,W(*68) |
1 | ||
| 69516-30090 |
GS151,JZS15#,LS151,UZS15#..A,C,E,F,ROY,ROYEX,ROYG,ROYT,SALEX ｻﾌﾞｷｰ,W(*68) |
1 | ||
| 69515-30160 |
GS151..ROY,ROYEX,SALEX;JZS151,153,LS151..ROYEX,SALEX ﾏｽﾀｰｷｰ,W(*68) |
2 | ||
| 69503B - KEY, CUT | ||||
| 69515-30160 |
JZS15#,LS151,UZS15#..A,C,E,F,ROY,ROYG,ROYT ﾏｽﾀｰｷｰ,W(*68) |
1 | ||
| 69516-30090 |
GS151,JZS15#,LS151,UZS15#..A,C,E,F,ROY,ROYEX,ROYG,ROYT,SALEX ｻﾌﾞｷｰ,W(*68) |
1 | ||
| 69515-30160 |
GS151..ROY,ROYEX,SALEX;JZS151,153,LS151..ROYEX,SALEX ﾏｽﾀｰｷｰ,W(*68) |
2 | ||
| 69510 - CYLINDER ASSY, FRONT DOOR LOCK, RH | ||||
| 69510-30220 |
GS151,JZS15#,LS151,UZS15#..HT |
1 | ||
| 69520 - CYLINDER ASSY, FRONT DOOR LOCK, LH | ||||
| 69520-30190 |
GS151,JZS15#,LS151,UZS15#..HT |
1 | ||
| 69550A - CYLINDER ASSY, GLOVE COMPARTMENT DOOR LOCK | ||||
| 69550-30120 |
GS151,JZS15#,LS151,UZS15#..A,C,E,F,ROY,ROYEX,ROYG,ROYT,SALEX |
1 | ||
| 69555 - COVER, KEY | ||||
| 69555-30020 |
GS151,JZS153..ROYEX;JZS151,155,157..HT..(ROY,ROYEX) ｱﾆﾊﾞ-ｻﾘ- ﾊﾟﾂｹ-ｼﾞ *(A) |
1 | ||
| 69555-17020 |
GS151,JZS15#,LS151,UZS15# |
1 | ||
| 69560A - CYLINDER ASSY, LUGGAGE COMPARTMENT DOOR LOCK | ||||
| 69560-30180 |
GS151,JZS15#,LS151..ROY,ROYEX,ROYG,ROYT,SALEX |
1 | ||
| 69570 - CYLINDER ASSY, IGNITION SWITCH LOCK | ||||
| 69570-30180 |
GS151,JZS15#,LS151,UZS15#..A,C,E,F,ROY,ROYEX,ROYG,ROYT,SALEX |
1 | ||
| 69759G - SNAP, LUGGAGE DOOR LOCK CYLINDER | ||||
| 69759-24090 |
GS151,JZS15#,LS151..ROY,ROYEX,ROYG,ROYT,SALEX,SPDLX |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-24100 |
GS151,JZS15#,LS151,UZS15#..HT 右側 |
1 | ||
| 69759-24110 |
GS151,JZS15#,LS151,UZS15#..HT 左側 |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-24100 |
GS151,JZS15#,LS151,UZS15#..HT 右側 |
1 | ||
| 69759-24110 |
GS151,JZS15#,LS151,UZS15#..HT 左側 |
1 | ||
| Common parts | ||||
| 90119-06137 | ||||
| 90151-40011 | ||||
| 91651-40612 | ||||
(9508- )
ｱﾘ(ﾜｲﾔﾚｽ ﾄﾞｱﾛﾂｸ)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69503B - KEY, CUT | ||||
| 69515-30160 |
JZS15#,LS151,UZS15#..A,C,E,F,ROY,ROYG,ROYT ﾏｽﾀｰｷｰ,W(*68) |
1 | ||
| 69516-30090 |
GS151,JZS15#,LS151,UZS15#..A,C,E,F,ROY,ROYEX,ROYG,ROYT,SALEX ｻﾌﾞｷｰ,W(*68) |
1 | ||
| 69515-30160 |
GS151..ROY,ROYEX,SALEX;JZS151,153,LS151..ROYEX,SALEX ﾏｽﾀｰｷｰ,W(*68) |
2 | ||
| 69503B - KEY, CUT | ||||
| 69515-30160 |
JZS15#,LS151,UZS15#..A,C,E,F,ROY,ROYG,ROYT ﾏｽﾀｰｷｰ,W(*68) |
1 | ||
| 69516-30090 |
GS151,JZS15#,LS151,UZS15#..A,C,E,F,ROY,ROYEX,ROYG,ROYT,SALEX ｻﾌﾞｷｰ,W(*68) |
1 | ||
| 69515-30160 |
GS151..ROY,ROYEX,SALEX;JZS151,153,LS151..ROYEX,SALEX ﾏｽﾀｰｷｰ,W(*68) |
2 | ||
| 69510 - CYLINDER ASSY, FRONT DOOR LOCK, RH | ||||
| 69510-30220 |
GS151,JZS15#,LS151,UZS15#..HT |
1 | ||
| 69520 - CYLINDER ASSY, FRONT DOOR LOCK, LH | ||||
| 69520-30190 |
GS151,JZS15#,LS151,UZS15#..HT |
1 | ||
| 69550A - CYLINDER ASSY, GLOVE COMPARTMENT DOOR LOCK | ||||
| 69550-30120 |
GS151,JZS15#,LS151,UZS15#..A,C,E,F,ROY,ROYEX,ROYG,ROYT,SALEX |
1 | ||
| 69555 - COVER, KEY | ||||
| 69555-30020 |
GS151,JZS153..ROYEX;JZS151,155,157..HT..(ROY,ROYEX) ｱﾆﾊﾞ-ｻﾘ- ﾊﾟﾂｹ-ｼﾞ *(A) |
1 | ||
| 69555-17020 |
GS151,JZS15#,LS151,UZS15# |
1 | ||
| 69560A - CYLINDER ASSY, LUGGAGE COMPARTMENT DOOR LOCK | ||||
| 69560-30180 |
GS151,JZS15#,LS151..ROY,ROYEX,ROYG,ROYT,SALEX |
1 | ||
| 69570 - CYLINDER ASSY, IGNITION SWITCH LOCK | ||||
| 69570-30180 |
GS151,JZS15#,LS151,UZS15#..A,C,E,F,ROY,ROYEX,ROYG,ROYT,SALEX |
1 | ||
| 69759G - SNAP, LUGGAGE DOOR LOCK CYLINDER | ||||
| 69759-24090 |
GS151,JZS15#,LS151..ROY,ROYEX,ROYG,ROYT,SALEX,SPDLX |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-24100 |
GS151,JZS15#,LS151,UZS15#..HT 右側 |
1 | ||
| 69759-24110 |
GS151,JZS15#,LS151,UZS15#..HT 左側 |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-24100 |
GS151,JZS15#,LS151,UZS15#..HT 右側 |
1 | ||
| 69759-24110 |
GS151,JZS15#,LS151,UZS15#..HT 左側 |
1 | ||
| Common parts | ||||
| 90119-06137 | ||||
| 90151-40011 | ||||
| 91651-40612 | ||||
| Linked diagrams | ||||
| 8420 | ||||
