GX50-YTMFE (1980)
Toyota Cresta
(8003-8208) ; (8208- )5F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 58266 - BRACKET, CONSOLE BOX SUPPORT, FRONT | ||||
| 58996-22010 |
GX5#,61,LX60,MX51,61,SX60,TX50 |
1 | ||
| 58268 - BRACKET, CONSOLE BOX SUPPORT, REAR | ||||
| 58853-22020 |
GX5#,61,LX60,MX51,61,SX60,TX50 |
1 | ||
| 58808 - COVER SUB-ASSY, SHIFTING HOLE | ||||
| 58808-2206001 |
GX5#,TX50..MTM BLACK,BLACK,TRIM2# |
1 | ||
| 58808-2205004 |
GX5#,TX50..MTM BLUE,BLUE,TRIM8# |
1 | ||
| 58808-2205001 |
GX5#,TX50..MTM BLACK,BLACK,TRIM2# |
1 | ||
| 58808-2206004 |
GX5#,TX50..MTM BLUE,BLUE,TRIM8# |
1 | ||
| 58808-2205006 |
GX5#,TX50..MTM D-BROWN,BROWN,TRIM4# |
1 | ||
| 58810 - CONSOLE ASSY | ||||
| 58811-2212004 |
GX5#,MX51,TX50 BLUE,BLUE,TRIM8# |
1 | ||
| 58811-2212001 |
GX5#,MX51,TX50 BLACK,BLACK,TRIM2# |
1 | ||
| 58811-2212005 |
GX5#,MX51,TX50 GREIGE,BEIGE,TRIM4# |
1 | ||
| 58827B - SPACER, CONSOLE COMPARTMENT DOOR STOPPER | ||||
| 58967-22010 |
GX5#,MX51,TX50 |
1 | ||
| 58836 - PANEL, CONSOLE, UPPER FRONT | ||||
| 58821-22010 |
GX5#,MX51,TX50..3FC,4FC,5F |
1 | ||
| 58836 - PANEL, CONSOLE, UPPER FRONT | ||||
| 58821-22010 |
GX5#,MX51,TX50..3FC,4FC,5F |
1 | ||
| 58836 - PANEL, CONSOLE, UPPER FRONT | ||||
| 58821-22010 |
GX5#,MX51,TX50..3FC,4FC,5F |
1 | ||
| 58904A - STOPPER SUB-ASSY, CONSOLE COMPARTMENT DOOR | ||||
| 58904-22020 |
GX5#,MX51,TX50 |
1 | ||
| 58905 - DOOR SUB-ASSY, CONSOLE COMPARTMENT | ||||
| 58905-2202004 |
GX5#,MX51,TX50 BLUE,BLUE,TRIM8# |
1 | ||
| 58905-2202005 |
GX5#,MX51,TX50 GREIGE,BEIGE,TRIM4# |
1 | ||
| 58905-2202001 |
GX5#,MX51,TX50 BLACK,BLACK,TRIM2# |
1 | ||
| 58908A - LOCK SUB-ASSY, CONSOLE COMPARTMENT DOOR | ||||
| 58908-22010 |
GX5#,MX51,TX50 |
1 | ||
| 58940 - CONSOLE ASSY, REAR | ||||
| 58901-2202005 |
GX5#,MX51,TX50 GREIGE,BEIGE,TRIM4# |
1 | ||
| 58901-2202004 |
GX5#,MX51,TX50 BLUE,BLUE,TRIM8# |
1 | ||
| 58901-2202001 |
GX5#,MX51,TX50 BLACK,BLACK,TRIM2# |
1 | ||
| 58940 - CONSOLE ASSY, REAR | ||||
| 58901-2202005 |
GX5#,MX51,TX50 GREIGE,BEIGE,TRIM4# |
1 | ||
| 58901-2202004 |
GX5#,MX51,TX50 BLUE,BLUE,TRIM8# |
1 | ||
| 58901-2202001 |
GX5#,MX51,TX50 BLACK,BLACK,TRIM2# |
1 | ||
| 58969A - RETAINER, CONSOLE COMPARTMENT DOOR STOPPER | ||||
| 58969-20010 |
GX5#,MX51,TX50 |
1 | ||
| Common parts | ||||
| 90176-04015 | ||||
| 90183-04006 | ||||
| 90541-04079 | ||||
| 93540-15014 | ||||
| 93540-54012 | ||||
| 93560-55016 | ||||
| 93566-14512 | ||||
| 93566-54512 | ||||
| Linked diagrams | ||||
| 7501 | ||||
