GX50-YTMFE (1980)
Toyota Cresta
(8003-8010)5F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 31111 - HOUSING, CLUTCH | ||||
| 31111-22100 |
GX5#..5F |
1 | ||
| 31111-22080 |
GX5#..5F |
1 | ||
| 33104 - PLUG SUB-ASSY, DRAIN(MTM) | ||||
| 90341-18057 |
GX5#,61,LX60,SX60,TX50..MTM |
1 | ||
| 33104A - GASKET, DRAIN PLUG(MTM) | ||||
| 12157-10010 |
GX5#,TX50..MTM |
1 | ||
| 33111 - CASE, MANUAL TRANSMISSION | ||||
| 33101-22010 |
GX5#,TX50..MTM |
1 | ||
| 33101-20011 |
GX5#,TX50..MTM |
1 | ||
| 33111A - PLUG, MANUAL TRANSMISSION CASE | ||||
| 90341-18002 |
GX5#,61,LX60,SX60,TX50..MTM |
1 | ||
| 33111C - PLUG(FOR TRANSMISSION CASE) | ||||
| 90331-20044 |
GX5#,TX50..MTM |
3 | ||
| 33111J - PIN, STRAIGHT(FOR MANUAL TRANSMISSION CASE) | ||||
| 90250-12195 |
GX5#,TX50..MTM OD=12,L=39 |
2 | ||
| 90334-06017 |
GX5#,TX50..MTM OD=6,L=11 |
1 | ||
| 90250-12146 |
GX5#,TX50..MTM 長さ=17,外径=12,OD=12,L=17 |
2 | ||
| 90250-12002 |
GX5#,TX50..MTM 長さ=16,外径=12,OD=12,L=16 |
4 | ||
| 33111J - PIN, STRAIGHT(FOR MANUAL TRANSMISSION CASE) | ||||
| 90250-12195 |
GX5#,TX50..MTM OD=12,L=39 |
2 | ||
| 90334-06017 |
GX5#,TX50..MTM OD=6,L=11 |
1 | ||
| 90250-12146 |
GX5#,TX50..MTM 長さ=17,外径=12,OD=12,L=17 |
2 | ||
| 90250-12002 |
GX5#,TX50..MTM 長さ=16,外径=12,OD=12,L=16 |
4 | ||
| 33111U - PIN, RING(FOR MANUAL TRANSMISSION CASE) | ||||
| 90253-13017 |
GX5#,TX50..MTM 長さ=12,外径=13 |
2 | ||
| 33111X - GASKET, TRANSMISSION CASE PLUG | ||||
| 12157-10010 |
GX5#,TX50..MTM |
1 | ||
| 33118 - PLATE, STIFFENER, RH(MTM) | ||||
| 33118-22050 |
GX5#,61..5F |
1 | ||
| 33119 - PLATE, STIFFENER, LH(MTM) | ||||
| 33119-22040 |
GX5#..5F |
1 | ||
| 33131 - RETAINER, BEARING, FRONT(MTM) | ||||
| 33131-31010 |
GX5#,TX50..MTM |
1 | ||
| 33131A - SEAL, OIL(FOR TRANSMISSION FRONT BEARING RETAINER) | ||||
| 90311-30115 |
GX5#,61,LX60,SX60,TX50..MTM |
1 | ||
| 33132 - GASKET, FRONT BEARING RETAINER(MTM) | ||||
| 33132-20040 |
GX5#,TX50..MTM |
1 | ||
| 33138 - GASKET, INTERMEDIATE PLATE | ||||
| 33142-20020 |
GX5#..5F |
1 | ||
| 33151 - RETAINER, OUTPUT SHAFT REAR BEARING(MTM) | ||||
| 33151-20010 |
GX5#..5F |
1 | ||
| Common parts | ||||
| 90119-06043 | ||||
| 90119-10025 | ||||
| 91611-61028 | ||||
| 91611-61035 | ||||
| 91619-61250 | ||||
| 91651-61040 | ||||
| 93220-18020 | ||||
(8010- )GX5#,61..5F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 31111 - HOUSING, CLUTCH | ||||
| 31111-22100 |
GX5#..5F |
1 | ||
| 31111-22080 |
GX5#..5F |
1 | ||
| 33104 - PLUG SUB-ASSY, DRAIN(MTM) | ||||
| 90341-18057 |
GX5#,61,LX60,SX60,TX50..MTM |
1 | ||
| 33104A - GASKET, DRAIN PLUG(MTM) | ||||
| 12157-10010 |
GX5#,TX50..MTM |
1 | ||
| 33111 - CASE, MANUAL TRANSMISSION | ||||
| 33101-22010 |
GX5#,TX50..MTM |
1 | ||
| 33101-20011 |
GX5#,TX50..MTM |
1 | ||
| 33111A - PLUG, MANUAL TRANSMISSION CASE | ||||
| 90341-18002 |
GX5#,61,LX60,SX60,TX50..MTM |
1 | ||
| 33111C - PLUG(FOR TRANSMISSION CASE) | ||||
| 90331-20044 |
GX5#,TX50..MTM |
3 | ||
| 33111J - PIN, STRAIGHT(FOR MANUAL TRANSMISSION CASE) | ||||
| 90250-12195 |
GX5#,TX50..MTM OD=12,L=39 |
2 | ||
| 90334-06017 |
GX5#,TX50..MTM OD=6,L=11 |
1 | ||
| 90250-12146 |
GX5#,TX50..MTM 長さ=17,外径=12,OD=12,L=17 |
2 | ||
| 90250-12002 |
GX5#,TX50..MTM 長さ=16,外径=12,OD=12,L=16 |
4 | ||
| 33111J - PIN, STRAIGHT(FOR MANUAL TRANSMISSION CASE) | ||||
| 90250-12195 |
GX5#,TX50..MTM OD=12,L=39 |
2 | ||
| 90334-06017 |
GX5#,TX50..MTM OD=6,L=11 |
1 | ||
| 90250-12146 |
GX5#,TX50..MTM 長さ=17,外径=12,OD=12,L=17 |
2 | ||
| 90250-12002 |
GX5#,TX50..MTM 長さ=16,外径=12,OD=12,L=16 |
4 | ||
| 33111J - PIN, STRAIGHT(FOR MANUAL TRANSMISSION CASE) | ||||
| 90250-12195 |
GX5#,TX50..MTM OD=12,L=39 |
2 | ||
| 90334-06017 |
GX5#,TX50..MTM OD=6,L=11 |
1 | ||
| 90250-12146 |
GX5#,TX50..MTM 長さ=17,外径=12,OD=12,L=17 |
2 | ||
| 90250-12002 |
GX5#,TX50..MTM 長さ=16,外径=12,OD=12,L=16 |
4 | ||
| 33111X - GASKET, TRANSMISSION CASE PLUG | ||||
| 12157-10010 |
GX5#,TX50..MTM |
1 | ||
| 33118 - PLATE, STIFFENER, RH(MTM) | ||||
| 33118-22050 |
GX5#,61..5F |
1 | ||
| 33119 - PLATE, STIFFENER, LH(MTM) | ||||
| 33119-22040 |
GX5#..5F |
1 | ||
| 33131 - RETAINER, BEARING, FRONT(MTM) | ||||
| 33131-31010 |
GX5#,TX50..MTM |
1 | ||
| 33131A - SEAL, OIL(FOR TRANSMISSION FRONT BEARING RETAINER) | ||||
| 90311-30115 |
GX5#,61,LX60,SX60,TX50..MTM |
1 | ||
| 33132 - GASKET, FRONT BEARING RETAINER(MTM) | ||||
| 33132-20040 |
GX5#,TX50..MTM |
1 | ||
| 33138 - GASKET, INTERMEDIATE PLATE | ||||
| 33142-20020 |
GX5#..5F |
1 | ||
| 33151 - RETAINER, OUTPUT SHAFT REAR BEARING(MTM) | ||||
| 33151-20010 |
GX5#..5F |
1 | ||
| Common parts | ||||
| 90119-08213 | ||||
| 90149-80002 | ||||
| 91611-61028 | ||||
| 91611-61035 | ||||
| 91611-61040 | ||||
| 91611-61645 | ||||
| 91619-61250 | ||||
