Toyota Corsa/tercel EL51 STEERING WHEEL

EL51-BEHDK (1994)

Toyota Corsa/Tercel

Production Sep 1994 - Jul 1999

Engine 4EFE

Transmission 3FC ATM

Displacement 2500cc

Power 168 HP (125 kW)

(9409- )

Click highlighted areas on diagram

4-SP0KE,ｱﾘ(ﾃﾞﾝｷｼｷ *80)

Part #	Description	Period	Qty
45100 - WHEEL ASSY, STEERING
45100-16470B1	EL5#,NL50 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	08/1995 - 04/1996	1
45100-10431B0	EL5#,NL50 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	04/1996 - 08/1996	1
45100-16370B1	EL51..AX,JOI,MOA 2本ｽﾎﾟｰｸ,ﾎﾟﾘﾌﾟﾛﾋﾟﾚﾝ,SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45100-16370B0	EL5#,NL50..AX,JOI,MOA 2本ｽﾎﾟｰｸ,ﾎﾟﾘﾌﾟﾛﾋﾟﾚﾝ,BLUISH GRAY,TRIM1#	09/1994 - 08/1996	1
45100-16500B0	EL51..AX,JOI,MOA 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45100-16510B0	EL5#,NL50 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,ｱﾘ(ﾃﾞﾝｷｼｷ *80),SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45100-16600B0	EL5#,NL50 4本ｽﾎﾟｰｸ,SHADOW GRAY,TRIM1#	12/1997 - 12/2999	1
45100-16600E0	EL5#,NL50 4本ｽﾎﾟｰｸ,OAK,TRIM4#	12/1997 - 12/2999	1
45100-16400B0	EL5#,NL50 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	09/1994 - 08/1995	1
45130 - BUTTON ASSY, HORN
45130-16290B0	EL5#,NL50..AX,JOI,MOA BLUISH GRAY,TRIM1#	09/1994 - 08/1996	1
45130-16370B0	EL5#,NL50 ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	08/1995 - 08/1996	1
45130-16290B1	EL51..AX,JOI,MOA SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45130-16390B0	EL51..AX,JOI,MOA ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	08/1996 - 12/1997	1
45130-16400B0	EL5#,NL50 ｱﾘ(ﾃﾞﾝｷｼｷ *80),SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45130-16450B1	EL5#,NL50 SHADOW GRAY,TRIM1#	12/1997 - 12/2999	1
45130-16300B0	EL5#,NL50 ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	09/1994 - 08/1995	1
45130-16450E0	EL5#,NL50 OAK,TRIM4#	12/1997 - 12/2999	1
45201P - NUT, STEERING WHEEL SET
90179-12071	EL5#,NL50	09/1994 - 12/2999	1
Common parts
90148-60031

(9409-9712)AX,JOI,MOA

Click highlighted areas on diagram

2-SPOKE

Part #	Description	Period	Qty
45100 - WHEEL ASSY, STEERING
45100-16470B1	EL5#,NL50 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	08/1995 - 04/1996	1
45100-10431B0	EL5#,NL50 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	04/1996 - 08/1996	1
45100-16370B1	EL51..AX,JOI,MOA 2本ｽﾎﾟｰｸ,ﾎﾟﾘﾌﾟﾛﾋﾟﾚﾝ,SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45100-16370B0	EL5#,NL50..AX,JOI,MOA 2本ｽﾎﾟｰｸ,ﾎﾟﾘﾌﾟﾛﾋﾟﾚﾝ,BLUISH GRAY,TRIM1#	09/1994 - 08/1996	1
45100-16500B0	EL51..AX,JOI,MOA 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45100-16510B0	EL5#,NL50 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,ｱﾘ(ﾃﾞﾝｷｼｷ *80),SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45100-16600B0	EL5#,NL50 4本ｽﾎﾟｰｸ,SHADOW GRAY,TRIM1#	12/1997 - 12/2999	1
45100-16600E0	EL5#,NL50 4本ｽﾎﾟｰｸ,OAK,TRIM4#	12/1997 - 12/2999	1
45100-16400B0	EL5#,NL50 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	09/1994 - 08/1995	1
45105 - PLATE SUB-ASSY, HORN BUTTON CONTACT, NO.1
45105-10070	EL51..AX,JOI,MOA	08/1996 - 12/1997	1
45105-10070	EL5#,NL50..AX,JOI,MOA	09/1994 - 08/1996	1
45105B - SPACER(FOR HORN BUTTON CONTACT PLATE)
90561-04014	EL51..AX,JOI,MOA	08/1996 - 12/1997	1
90561-04014	EL5#,NL50..AX,JOI,MOA	09/1994 - 08/1996	1
45130 - BUTTON ASSY, HORN
45130-16290B0	EL5#,NL50..AX,JOI,MOA BLUISH GRAY,TRIM1#	09/1994 - 08/1996	1
45130-16370B0	EL5#,NL50 ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	08/1995 - 08/1996	1
45130-16290B1	EL51..AX,JOI,MOA SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45130-16390B0	EL51..AX,JOI,MOA ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	08/1996 - 12/1997	1
45130-16400B0	EL5#,NL50 ｱﾘ(ﾃﾞﾝｷｼｷ *80),SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45130-16450B1	EL5#,NL50 SHADOW GRAY,TRIM1#	12/1997 - 12/2999	1
45130-16300B0	EL5#,NL50 ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	09/1994 - 08/1995	1
45130-16450E0	EL5#,NL50 OAK,TRIM4#	12/1997 - 12/2999	1
45142 - SEAT, HORN BUTTON CONTACT, NO.1
45142-12100	EL5#,NL50..AX,JOI,MOA	09/1994 - 08/1996	1
45142-12100	EL51..AX,JOI,MOA	08/1996 - 12/1997	1
45180 - COVER SUB-ASSY, STEERING WHEEL
45180-16140B1	EL51..AX,JOI,MOA SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45180-16140B0	EL5#,NL50..AX,JOI,MOA BLUISH GRAY,TRIM1#	09/1994 - 08/1996	1
45201P - NUT, STEERING WHEEL SET
90179-12071	EL5#,NL50	09/1994 - 12/2999	1
Common parts
90159-50238
90167-40049
90168-30006
90168-40103

(9409- )

Click highlighted areas on diagram

4-SPOKE,ｱﾘ(ｷｶｲｼｷ *80)

Part #	Description	Period	Qty
45100 - WHEEL ASSY, STEERING
45100-16470B1	EL5#,NL50 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	08/1995 - 04/1996	1
45100-10431B0	EL5#,NL50 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	04/1996 - 08/1996	1
45100-16370B1	EL51..AX,JOI,MOA 2本ｽﾎﾟｰｸ,ﾎﾟﾘﾌﾟﾛﾋﾟﾚﾝ,SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45100-16370B0	EL5#,NL50..AX,JOI,MOA 2本ｽﾎﾟｰｸ,ﾎﾟﾘﾌﾟﾛﾋﾟﾚﾝ,BLUISH GRAY,TRIM1#	09/1994 - 08/1996	1
45100-16500B0	EL51..AX,JOI,MOA 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45100-16510B0	EL5#,NL50 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,ｱﾘ(ﾃﾞﾝｷｼｷ *80),SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45100-16600B0	EL5#,NL50 4本ｽﾎﾟｰｸ,SHADOW GRAY,TRIM1#	12/1997 - 12/2999	1
45100-16600E0	EL5#,NL50 4本ｽﾎﾟｰｸ,OAK,TRIM4#	12/1997 - 12/2999	1
45100-16400B0	EL5#,NL50 4本ｽﾎﾟｰｸ,ｳﾚﾀﾝ,ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	09/1994 - 08/1995	1
45130 - BUTTON ASSY, HORN
45130-16290B0	EL5#,NL50..AX,JOI,MOA BLUISH GRAY,TRIM1#	09/1994 - 08/1996	1
45130-16370B0	EL5#,NL50 ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	08/1995 - 08/1996	1
45130-16290B1	EL51..AX,JOI,MOA SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45130-16390B0	EL51..AX,JOI,MOA ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	08/1996 - 12/1997	1
45130-16400B0	EL5#,NL50 ｱﾘ(ﾃﾞﾝｷｼｷ *80),SHADOW GRAY,TRIM1#	08/1996 - 12/1997	1
45130-16450B1	EL5#,NL50 SHADOW GRAY,TRIM1#	12/1997 - 12/2999	1
45130-16300B0	EL5#,NL50 ｱﾘ(ｷｶｲｼｷ *80),BLUISH GRAY,TRIM1#	09/1994 - 08/1995	1
45130-16450E0	EL5#,NL50 OAK,TRIM4#	12/1997 - 12/2999	1
45187 - COVER, STEERING WHEEL, LOWER NO.3
45187-16020B1	EL51..AX,JOI,MOA SHADOW GRAY,TRIM1#	08/1996 - 10/1996	1
45187-16020B1	EL5#,NL50 SHADOW GRAY,TRIM1#	10/1996 - 12/1997	1
45187-16020B0	EL5#,NL50 BLUISH GRAY,TRIM1#	09/1994 - 08/1996	1
45201P - NUT, STEERING WHEEL SET
90179-12071	EL5#,NL50	09/1994 - 12/2999	1
Common parts
90148-60031

EL51-BEHDK (1994)

(9409- )

(9409-9712)AX,JOI,MOA

(9409- )
