EL31-LGPES (1986)
Toyota Corsa/Tercel
(8605- )2E,3E#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27060-10061 |
3E#..EL31..ATM 12V 60A,12V 55A |
1 | ||
| 27060-10060 |
3E..EL31..ATM 12V 55A,12V 55A |
1 | ||
| 27060-10061 |
3E..EL31..ATM 12V 60A,12V 55A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-72110 |
3E..EL31 12V 55A |
1 | ||
| 27039-72150 |
3E..EL31..(3FC,4F,5F)..(EX,GX,VL,VX) 12V 45A |
1 | ||
| 27039-72110 |
3E#..EL31 12V 55A |
1 | ||
| 27113 - PLATE, BEARING RETAINER, ALTERNATOR | ||||
| 27312-72100 |
3E#,1NT..EL31,NL30 12V 55A,60A |
1 | ||
| 27312-72120 |
3E..EL31..(3FC,4F,5F)..(EX,GX,VL,VX) 12V 45A |
1 | ||
| 27312-72100 |
3E,1NT..EL31,NL30 12V 55A,60A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-10021 |
3E..EL31 12V 55A |
1 | ||
| 27310-10021 |
3E#..EL31 12V 55A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10159 |
3E#,1NT..EL31,NL30 12V 55A,60A |
1 | ||
| 90099-10170 |
3E..EL31..(3FC,4F,5F)..(EX,GX,VL,VX) 12V 45A |
1 | ||
| 90099-10159 |
3E,1NT..EL31,NL30 12V 55A,60A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-10021 |
3E#..EL31 12V 55A |
1 | ||
| 27330-72150 |
3E..EL31..(3FC,4F,5F)..(EX,GX,VL,VX) 12V 45A |
1 | ||
| 27330-10021 |
3E..EL31 12V 55A |
1 | ||
| 27330-10020 |
3E#..EL31 12V 55A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10154 |
3E..EL31..(3FC,4F,5F)..(EX,GX,VL,VX) 12V 45A |
1 | ||
| 90099-10140 |
3E#,1NT..EL31,NL30 12V 55A,60A |
1 | ||
| 27357 - HOLDER, ALTERNATOR, W/RECTIFIER | ||||
| 27357-63040 |
3E..EL31 12V 55A |
1 | ||
| 27357-63040 |
3E#..EL31 12V 55A |
1 | ||
| 27357-72150 |
3E..EL31..(3FC,4F,5F)..(EX,GX,VL,VX) 12V 45A |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-16081 |
3E..EL31 12V 55A |
1 | ||
| 27359-16081 |
3E#..EL31 12V 55A |
1 | ||
| 27370 - HOLDER ASSY, ALTERNATOR BRUSH | ||||
| 27370-16011 |
2E,3E#,1NT..EL3#,NL30 12V 45A,55A,60A,70A |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-63020 |
2E,3E#,1NT..EL3#,NL30 12V 45A,55A,60A,70A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 27372-72100 |
2E,3E#,1NT..EL3#,NL30 12V 45A,55A,60A,70A |
2 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-10070 |
3E#..EL31..ATM 12V 55A |
1 | ||
| 27411-10070 |
3E..EL31..ATM 12V 55A |
1 | ||
| 27443 - COVER, ALTERNATOR BEARING | ||||
| 27443-63020 |
2E,3E#,1NT..EL3#,NL30 12V 45A,55A,60A |
1 | ||
| 27700A - REGULATOR ASSY, GENERATOR | ||||
| 27700-63021 |
3E#,1NT..EL31,NL30 12V 55A,60A |
1 | ||
| 27700-10050 |
3E..EL31..(3FC,4F,5F)..(EX,GX,VL,VX) 12V 45A |
1 | ||
| 27700-63021 |
3E,1NT..EL31,NL30 12V 55A,60A |
1 | ||
| Common parts | ||||
| 27387-10050 | ||||
| 27387-10080 | ||||
| 27387-63020 | ||||
| 27387-70170 | ||||
| 90099-00159 | ||||
| 90099-00161 | ||||
| 90099-00197 | ||||
| 90099-04329 | ||||
| 90099-04330 | ||||
| 90099-04333 | ||||
| 90099-05119 | ||||
| 90099-05171 | ||||
| 90099-05172 | ||||
| 90105-10102 | ||||
| 90179-06158 | ||||
| 90179-10016 | ||||
| 91655-60820 | ||||
| 93319-14025 | ||||
| Linked diagrams | ||||
| 1605 | ||||
