EL30-LGKDS (1986)
Toyota Corsa/Tercel
(8605- )TX,VC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71015 - FRAME SUB-ASSY, REAR SEAT CUSHION | ||||
| 71015-16070 |
EL3#,NL30..CUT,GX,SOP,TX,VC,VL |
1 | ||
| 71017A - FRAME SUB-ASSY, REAR SEAT BACK | ||||
| 71017-16110 |
EL30,NL30..TX,VC |
1 | ||
| 71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE) | ||||
| 71065-1615005 |
EL30,NL30..TX,VC FB,BEIGE,BEIGE,TRIM4# |
1 | ||
| 71065-1640004 |
EL30..TX,VC MOA OR JOINUS,FB,BLUE,BLUE,TRIM8# |
1 | ||
| 71065-1615003 |
EL30,NL30..TX,VC FB,GRAY,GRAY,TRIM2# |
1 | ||
| 71065-1615004 |
EL30,NL30..TX,VC FB,BLUE,BLUE,TRIM8# |
1 | ||
| 71065-1640003 |
EL30..TX,VC MOA OR JOINUS,FB,GRAY,GRAY,TRIM2# |
1 | ||
| 71077B - COVER, REAR SEAT BACK (FOR BENCH TYPE) | ||||
| 71077-1687003 |
EL30,NL30..TX,VC FB,GRAY,GRAY,TRIM2# |
1 | ||
| 71077-1G21003 |
EL30..TX,VC MOA OR JOINUS,FB,GRAY,GRAY,TRIM2# |
1 | ||
| 71077-1G21004 |
EL30..TX,VC MOA OR JOINUS,FB,BLUE,BLUE,TRIM8# |
1 | ||
| 71077-1687005 |
EL30,NL30..TX,VC FB,BEIGE,BEIGE,TRIM4# |
1 | ||
| 71077-1687004 |
EL30,NL30..TX,VC FB,BLUE,BLUE,TRIM8# |
1 | ||
| 71303 - HINGE SUB-ASSY, REAR SEAT BACK | ||||
| 71303-16040 |
EL3#,NL30 |
2 | ||
| 71460B - CUSHION ASSY, REAR SEAT (FOR BENCH TYPE) | ||||
| 71560-1645003 |
EL30..TX,VC MOA OR JOINUS,FB,GLAY,GRAY,TRIM2# |
1 | ||
| 71560-1618003 |
EL30,NL30..TX,VC FB,GRAY,GRAY,TRIM2# |
1 | ||
| 71560-1618004 |
EL30,NL30..TX,VC FB,BLUE,BLUE,TRIM8# |
1 | ||
| 71560-1645004 |
EL30..TX,VC MOA OR JOINUS,FB,BLUE,BLUE,TRIM8# |
1 | ||
| 71560-1618005 |
EL30,NL30..TX,VC FB,BEIGE,BEIGE,TRIM4# |
1 | ||
| 71480B - BACK ASSY, REAR SEAT (FOR BENCH TYPE) | ||||
| 71480-1G03004 |
EL30,NL30..TX,VC FB,BLUE,BLUE,TRIM8# |
1 | ||
| 71480-1G03005 |
EL30,NL30..TX,VC FB,BEIGE,BEIGE,TRIM4# |
1 | ||
| 71480-1G03003 |
EL30,NL30..TX,VC FB,GRAY,GRAY,TRIM2# |
1 | ||
| 71480-1G29004 |
EL30..TX,VC MOA OR JOINUS,FB,BLUE,BLUE,TRIM8# |
1 | ||
| 71480-1G29003 |
EL30..TX,VC MOA OR JOINUS,FB,GLAY,GRAY,TRIM2# |
1 | ||
| 71611 - PAD, REAR SEAT CUSHION | ||||
| 71611-16170 |
EL3#,NL30..CUT,GX,SOP,TX,VC,VL |
1 | ||
| 71651B - PAD, REAR SEAT BACK(FOR BENCH TYPE) | ||||
| 71651-16220 |
EL30,NL30..TX,VC |
1 | ||
| 71812B - CLIP(FOR REAR SEAT CUSHION COVER) | ||||
| 90468-18071 |
EL3#,NL30 |
1 | ||
| 71812B - CLIP(FOR REAR SEAT CUSHION COVER) | ||||
| 90468-18071 |
EL3#,NL30 |
1 | ||
| 72601 - STRIKER SUB-ASSY, REAR SEAT LOCK | ||||
| 72601-16070 |
EL3#,NL30 |
2 | ||
| 72620 - LOCK ASSY, REAR SEAT BACK | ||||
| 72630-16140 |
EL3#,NL30 RH |
1 | ||
| 72640-16100 |
EL3#,NL30 LH |
1 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-1601004 |
EL3#,NL30 BLUE,BLUE,TRIM8# |
2 | ||
| 72646-1601005 |
EL3#,NL30..CUT,EX,GX,SOP,TX,VC,VL,VX BEIGE,DARK BEIGE,TRIM4# |
2 | ||
| 72646-1601001 |
EL3#,NL30 BLACK,BLACK,TRIM2# |
2 | ||
| 72656 - BUTTON, REAR SEAT BACK STOP RELEASE | ||||
| 72658-2301004 |
EL3#,NL30 BLUE,BLUE,TRIM8# |
2 | ||
| 72658-2301015 |
EL3#,NL30..CUT,EX,GX,SOP,TX,VC,VL,VX BEIGE,DARK BEIGE,TRIM4# |
2 | ||
| 72658-2301001 |
EL3#,NL30 BLACK,BLACK,TRIM2# |
2 | ||
| Common parts | ||||
| 90105-08102 | ||||
| 90105-08132 | ||||
| 91651-60614 | ||||
