AL21-ZHMSH (1982)

Toyota Corsa/Tercel

Production May 1982 - Aug 1984
Engine 3AHU
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

ILLUST NO. 1 OF 2(8205- )

Click highlighted areas on diagram

diagram 67003 67004 67113 67114 67405 67406 67603 67603A 67604 67803 67804 67836 67871 67871A 67872 68103 68104 68123 68124 68142 68163 68188 68189 68190 68190A 68630 68630 68630A 7404 9017906070 9033330002 9165140612 9165540616 9322915008
Part # Description Qty Price
67003 - PANEL SUB-ASSY, REAR DOOR, RH
67003-16120

AL21..5DS..(SX,VS)

 1
67004 - PANEL SUB-ASSY, REAR DOOR, LH
67004-16120

AL21..5DS..(SX,VS)

 1
67113 - PANEL, REAR DOOR, OUTER RH
67113-16040

AL21..(4DS,5DS)..(SX,VS)

 1
67114 - PANEL, REAR DOOR, OUTER LH
67114-16040

AL21..(4DS,5DS)..(SX,VS)

 1
67405 - BAR SUB-ASSY, REAR DOOR WINDOW DIVISION, RH
67407-16020

AL20,21..5DS

 1
67406 - BAR SUB-ASSY, REAR DOOR WINDOW DIVISION, LH
67408-16020

AL20,21..5DS

 1
67603 - BOARD SUB-ASSY, REAR DOOR TRIM, RH
67630-1611006

AL21..(4DS,5DS)..(EX,SX,VE,VS)

BROWN,BROWN,TRIM4#

 1
67630-1611003

AL21..(4DS,5DS)..(EX,SX,VE,VS)

GRAY,GRAY,TRIM1#

 1
67630-1611002

AL21..(4DS,5DS)..(EX,SX,VE,VS)

DARK WINE,RED/MAROON,TRIM3#

 1
67603A - RETAINER(FOR REAR DOOR TRIM BOARD)
67771-16020

AL2#..4DS,5DS

 18
67604 - BOARD SUB-ASSY, REAR DOOR TRIM, LH
67640-1612002

AL21..(4DS,5DS)..(EX,SX,VE,VS)

DARK WINE,RED/MAROON,TRIM3#

 1
67640-1612003

AL21..(4DS,5DS)..(EX,SX,VE,VS)

GRAY,GRAY,TRIM1#

 1
67640-1612006

AL21..(4DS,5DS)..(EX,SX,VE,VS)

BROWN,BROWN,TRIM4#

 1
67803 - COVER SUB-ASSY, REAR DOOR SERVICE HOLE, RH
67841-16060

AL2#..4DS,5DS

 1
67841-16070

AL2#..4DS,5DS

COLD SPEC

 1
67804 - COVER SUB-ASSY, REAR DOOR SERVICE HOLE, LH
67842-16020

AL2#..4DS,5DS

 1
67842-16040

AL2#..4DS,5DS

COLD SPEC

 1
67871 - WEATHERSTRIP, REAR DOOR, RH
67871-16050

AL2#..5DS

 1
67871-16060

AL2#..5DS

COLD SPEC

 1
67871A - RETAINER(FOR REAR DOOR WEATHERSTRIP)
67868-30040

AL2#..4DS,5DS

 38
67872 - WEATHERSTRIP, REAR DOOR, LH
67872-16060

AL2#..5DS

COLD SPEC

 1
67872-16050

AL2#..5DS

 1
68103 - GLASS SUB-ASSY, REAR DOOR, RH
68113-16040

AL20,21..5DS

*TT,T=3.5

 1
68104 - GLASS SUB-ASSY, REAR DOOR, LH
68114-16040

AL20,21..5DS

*TT,T=3.5

 1
68123 - GLASS, REAR DOOR WINDOW, RH
68123-16040

AL20,21..5DS

*TT,T=3.5

 1
68124 - GLASS, REAR DOOR WINDOW, LH
68124-16040

AL20,21..5DS

*TT,T=3.5

 1
68142 - RUN, REAR DOOR GLASS
68142-16020

AL2#..5DS

 2
68188 - WEATHERSTRIP, REAR DOOR QUARTER WINDOW, RH
68188-16020

AL20,21..5DS

 1
68189 - WEATHERSTRIP, REAR DOOR QUARTER WINDOW, LH
68189-16020

AL20,21..5DS

 1
68190 - WEATHERSTRIP ASSY, REAR DOOR GLASS, INNER
68190-16030

AL2#..4DS,5DS

RH

 1
68240-16030

AL2#..4DS,5DS

LH

 1
68190A - CLIP(FOR REAR DOOR GLASS INNER WEATHERSTRIP SET)
68211-10030

AL2#..4DS,5DS

 8
68630 - CHECK ASSY, REAR DOOR
68630-16020

AL2#..4DS,5DS

 2
68630 - CHECK ASSY, REAR DOOR
68630-16020

AL2#..4DS,5DS

 2
68630A - PIN(FOR REAR DOOR CHECK)
68617-22010

AL2#..4DS,5DS

 2
Common parts
90179-06070
90333-30002
91651-40612
91655-40616
93229-15008
Linked diagrams
7404
