AL21-LHHSS (1984)
Toyota Corsa/Tercel
(8408- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 88031 - ACTUATOR SET, IDLE-UP | ||||
| 88031-16040 |
AL21..SX,VS |
1 | ||
| 88031-16051 |
AL21..3FC..(SX,VS) |
1 | ||
| 88031-16050 |
AL21..3FC..(SX,VS) |
1 | ||
| 88645B - JOINT, NO.1 (FOR IDLE UP DIVICE) | ||||
| 88894-16020 |
AL2# |
2 | ||
| 88648B - WIRING, COOLER, NO.1 | ||||
| 88648-16090 |
AL2# NO.1 |
1 | ||
| 88648-16080 |
AL21,25..EX,SX,VE,VS W/*AAC,NO.2 |
1 | ||
| 88648B - WIRING, COOLER, NO.1 | ||||
| 88648-16090 |
AL2# NO.1 |
1 | ||
| 88648-16080 |
AL21,25..EX,SX,VE,VS W/*AAC,NO.2 |
1 | ||
| 88691 - VALVE, MAGNET (FOR IDLE UP DEVICE) | ||||
| 88691-87101 |
AL2# NO.1 |
1 | ||
| 88690-12161 |
AL21..EX,SX,VE,VS W/*AAC,NO.2 |
1 | ||
| 88690-16100 |
AL21..3FC..(SX,VS) |
1 | ||
| 88691 - VALVE, MAGNET (FOR IDLE UP DEVICE) | ||||
| 88691-87101 |
AL2# NO.1 |
1 | ||
| 88690-12161 |
AL21..EX,SX,VE,VS W/*AAC,NO.2 |
1 | ||
| 88690-16100 |
AL21..3FC..(SX,VS) |
1 | ||
| Common parts | ||||
| 90464-00074 | ||||
| 90464-00082 | ||||
| 90464-00087 | ||||
| 90464-00184 | ||||
| 90464-00248 | ||||
| 93385-16016 | ||||
(8408- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 87690B - WAY, 3 | ||||
| 90413-04005 |
AL21,25..EX,SX,VE,VS W/*AAC |
3 | ||
| 90413-04005 |
AL2# |
1 | ||
| 87690B - WAY, 3 | ||||
| 90413-04005 |
AL21,25..EX,SX,VE,VS W/*AAC |
3 | ||
| 90413-04005 |
AL2# |
1 | ||
| 87690B - WAY, 3 | ||||
| 90413-04005 |
AL21,25..EX,SX,VE,VS W/*AAC |
3 | ||
| 90413-04005 |
AL2# |
1 | ||
| 88031 - ACTUATOR SET, IDLE-UP | ||||
| 88031-16040 |
AL21..SX,VS |
1 | ||
| 88031-16051 |
AL21..3FC..(SX,VS) |
1 | ||
| 88031-16050 |
AL21..3FC..(SX,VS) |
1 | ||
| 88605D - WIRE, AIR CONDITIONER | ||||
| 88605-16080 |
AL21..EX,SX,VE,VS W/*AAC |
1 | ||
| 88605D - WIRE, AIR CONDITIONER | ||||
| 88605-16080 |
AL21..EX,SX,VE,VS W/*AAC |
1 | ||
| 88648B - WIRING, COOLER, NO.1 | ||||
| 88648-16090 |
AL2# NO.1 |
1 | ||
| 88648-16080 |
AL21,25..EX,SX,VE,VS W/*AAC,NO.2 |
1 | ||
| 88648B - WIRING, COOLER, NO.1 | ||||
| 88648-16090 |
AL2# NO.1 |
1 | ||
| 88648-16080 |
AL21,25..EX,SX,VE,VS W/*AAC,NO.2 |
1 | ||
| 88648B - WIRING, COOLER, NO.1 | ||||
| 88648-16090 |
AL2# NO.1 |
1 | ||
| 88648-16080 |
AL21,25..EX,SX,VE,VS W/*AAC,NO.2 |
1 | ||
| 88648B - WIRING, COOLER, NO.1 | ||||
| 88648-16090 |
AL2# NO.1 |
1 | ||
| 88648-16080 |
AL21,25..EX,SX,VE,VS W/*AAC,NO.2 |
1 | ||
| 88683B - TANK, VACUUM | ||||
| 88683-16010 |
AL21,25..EX,SX,VE,VS W/*AAC |
1 | ||
| 88683B - TANK, VACUUM | ||||
| 88683-16010 |
AL21,25..EX,SX,VE,VS W/*AAC |
1 | ||
| 88685 - BRACKET, AIR CONDITIONER CONTROL VACUUM TANK | ||||
| 88688-16030 |
AL21,25..EX,SX,VE,VS W/*AAC |
1 | ||
| 88685 - BRACKET, AIR CONDITIONER CONTROL VACUUM TANK | ||||
| 88688-16030 |
AL21,25..EX,SX,VE,VS W/*AAC |
1 | ||
| 88690A - VALVE ASSY, COMBINATION | ||||
| 88690-16050 |
AL21,25..EX,SX,VE,VS W/*AAC |
1 | ||
| 88690A - VALVE ASSY, COMBINATION | ||||
| 88690-16050 |
AL21,25..EX,SX,VE,VS W/*AAC |
1 | ||
| 88690C - HOSE, VACUUM, NO.1 (FOR HEATER OR AIR CONDITIONER) | ||||
| 95411-10030 |
AL21..EX,SX,VE,VS *H,L=120,ﾏｰｸ=#0,W/*AAC |
1 | ||
| 95411-19930 |
AL21..EX,SX,VE,VS *H,L=120,ﾏｰｸ=#*,W/*AAC |
1 | ||
| 88690C - HOSE, VACUUM, NO.1 (FOR HEATER OR AIR CONDITIONER) | ||||
| 95411-10030 |
AL21..EX,SX,VE,VS *H,L=120,ﾏｰｸ=#0,W/*AAC |
1 | ||
| 95411-19930 |
AL21..EX,SX,VE,VS *H,L=120,ﾏｰｸ=#*,W/*AAC |
1 | ||
| 88690D - HOSE, VACUUM, NO.2 (FOR HEATER OR AIR CONDITIONER) | ||||
| 95411-19995 |
AL21..SX,VS *H,L=750,ﾏｰｸ=#*,W/*AAC |
1 | ||
| 88690D - HOSE, VACUUM, NO.2 (FOR HEATER OR AIR CONDITIONER) | ||||
| 95411-19995 |
AL21..SX,VS *H,L=750,ﾏｰｸ=#*,W/*AAC |
1 | ||
| 88690E - HOSE, VACUUM, NO.3 (FOR HEATER OR AIR CONDITIONER) | ||||
| 95411-10095 |
AL21..SX,VS *H,L=800,ﾏｰｸ=#0,W/*AAC |
1 | ||
| 88690E - HOSE, VACUUM, NO.3 (FOR HEATER OR AIR CONDITIONER) | ||||
| 95411-10095 |
AL21..SX,VS *H,L=800,ﾏｰｸ=#0,W/*AAC |
1 | ||
| 88690F - HOSE, VACUUM, NO.4 (FOR HEATER OR AIR CONDITIONER) | ||||
| 95411-10430 |
AL21..EX,SX,VE,VS *H,L=120,ﾏｰｸ=#4,W/*AAC |
1 | ||
| 88690F - HOSE, VACUUM, NO.4 (FOR HEATER OR AIR CONDITIONER) | ||||
| 95411-10430 |
AL21..EX,SX,VE,VS *H,L=120,ﾏｰｸ=#4,W/*AAC |
1 | ||
| 88690G - HOSE, VACUUM, NO.5 (FOR HEATER OR AIR CONDITIONER) | ||||
| 95411-10130 |
AL21..SX,VS *H,L=300,ﾏｰｸ=#1,W/*AAC |
1 | ||
| 88690G - HOSE, VACUUM, NO.5 (FOR HEATER OR AIR CONDITIONER) | ||||
| 95411-10130 |
AL21..SX,VS *H,L=300,ﾏｰｸ=#1,W/*AAC |
1 | ||
| 88690H - HOSE, VACUUM, NO.6 (FOR HEATER OR AIR CONDITIONER) | ||||
| 95411-10230 |
AL21..EX,SX,VE,VS *H,L=180,ﾏｰｸ=#2,W/*AAC |
1 | ||
| 88690H - HOSE, VACUUM, NO.6 (FOR HEATER OR AIR CONDITIONER) | ||||
| 95411-10230 |
AL21..EX,SX,VE,VS *H,L=180,ﾏｰｸ=#2,W/*AAC |
1 | ||
| 88691 - VALVE, MAGNET (FOR IDLE UP DEVICE) | ||||
| 88691-87101 |
AL2# NO.1 |
1 | ||
| 88690-12161 |
AL21..EX,SX,VE,VS W/*AAC,NO.2 |
1 | ||
| 88690-16100 |
AL21..3FC..(SX,VS) |
1 | ||
| 88691 - VALVE, MAGNET (FOR IDLE UP DEVICE) | ||||
| 88691-87101 |
AL2# NO.1 |
1 | ||
| 88690-12161 |
AL21..EX,SX,VE,VS W/*AAC,NO.2 |
1 | ||
| 88690-16100 |
AL21..3FC..(SX,VS) |
1 | ||
| 88691B - VALVE, MAGNET (FOR WATER VALVE) | ||||
| 88691-16010 |
AL21,25..EX,SX,VE,VS W/*AAC |
1 | ||
| 88691B - VALVE, MAGNET (FOR WATER VALVE) | ||||
| 88691-16010 |
AL21,25..EX,SX,VE,VS W/*AAC |
1 | ||
| Common parts | ||||
| 82711-12200 | ||||
| 88891-16020 | ||||
| 90414-04002 | ||||
| 90464-00074 | ||||
| 90464-00081 | ||||
| 90464-00082 | ||||
| 90464-00087 | ||||
| 90464-00111 | ||||
| 90464-00184 | ||||
| 90464-00248 | ||||
| 93385-15012 | ||||
| 93385-16016 | ||||
