TT147V-TUKDS (1982)
Toyota Corona
(8201-8712)KT147,TT147
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04371 - SPIDER KIT, UNIVERSAL JOINT(FOR PROPELLER SHAFT) | ||||
| 04371-22010 |
AT140,CT14#,KT147,ST140,TT147,YT140 |
3 | ||
| 37101A - PIECE, BALANCE, NO.1 (FOR PROPELLER SHAFT) | ||||
| 90937-01136 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 20G,長さ=41.4,20G |
2 | ||
| 90937-01153 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 16G,長さ=33.2,16G |
2 | ||
| 90937-01157 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 26G,長さ=53.9,26G |
2 | ||
| 90937-01140 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 30G,長さ=62.2,30G |
2 | ||
| 90937-01156 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 24G,長さ=49.7,24G |
2 | ||
| 90937-01149 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 6G,長さ=12.4,6G |
2 | ||
| 90937-01154 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 18G,長さ=37.3,18G |
2 | ||
| 90937-01147 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 2G,厚さ=2.0,2G |
2 | ||
| 90937-01152 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 14G,長さ=29.0,14G |
2 | ||
| 90937-01158 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 28G,長さ=58.1,28G |
2 | ||
| 90937-01132 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 10G,長さ=20.7,10G |
2 | ||
| 90937-01150 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 8G,長さ=16.6,8G |
2 | ||
| 90937-01148 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 4G,厚さ=2.0,4G |
2 | ||
| 90937-01155 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 22G,長さ=45.6,22G |
2 | ||
| 90937-01151 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 12G,長さ=24.9,12G |
2 | ||
| 37101A - PIECE, BALANCE, NO.1 (FOR PROPELLER SHAFT) | ||||
| 90937-01136 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 20G,長さ=41.4,20G |
2 | ||
| 90937-01153 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 16G,長さ=33.2,16G |
2 | ||
| 90937-01157 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 26G,長さ=53.9,26G |
2 | ||
| 90937-01140 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 30G,長さ=62.2,30G |
2 | ||
| 90937-01156 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 24G,長さ=49.7,24G |
2 | ||
| 90937-01149 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 6G,長さ=12.4,6G |
2 | ||
| 90937-01154 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 18G,長さ=37.3,18G |
2 | ||
| 90937-01147 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 2G,厚さ=2.0,2G |
2 | ||
| 90937-01152 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 14G,長さ=29.0,14G |
2 | ||
| 90937-01158 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 28G,長さ=58.1,28G |
2 | ||
| 90937-01132 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 10G,長さ=20.7,10G |
2 | ||
| 90937-01150 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 8G,長さ=16.6,8G |
2 | ||
| 90937-01148 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 4G,厚さ=2.0,4G |
2 | ||
| 90937-01155 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 22G,長さ=45.6,22G |
2 | ||
| 90937-01151 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 12G,長さ=24.9,12G |
2 | ||
| 37110 - SHAFT ASSY, PROPELLER | ||||
| 37110-21040 |
TT147..4F SHEEL TYPE |
1 | ||
| 37110-21050 |
TT147..4F SOLID TYPE |
1 | ||
| 37110A - BOLT (FOR PROPELLER SHAFT) | ||||
| 90101-08062 |
AT140,CT14#,RT141,ST140,TT14#,YT140 |
8 | ||
| 37302 - YOKE SUB-ASSY, UNIVERSAL JOINT SLEEVE | ||||
| 37302-14030 |
TT147..4F |
1 | ||
| 37302-20040 |
CT140,147,YT140;AT140,KT147,ST140,TT147..ATM |
1 | ||
| 37315 - YOKE, UNIVERSAL JOINT FLANGE | ||||
| 37315-20020 |
AT140,CT14#,KT147,ST140,TT147,YT140 |
2 | ||
| 37331 - COVER, SLIDING SHAFT DUST | ||||
| 37331-30010 |
CT140,147,RT141,YT140;AT140,KT147,ST140,TT14#..ATM |
1 | ||
| 37331-12010 |
AT14#,KT147,ST140,TT14#..MTM..(DLX,EXS,GT,GX,GXA,STD,SX) |
1 | ||
| 37401A - RING, HOLE SNAP (FOR SPIDER BEARING) | ||||
| 90521-29070 |
AT140,CT14#,KT147,ST140,TT147,YT140 厚さ=2.375−2.425,T=2.375-2.425 |
12 | ||
| 90521-29073 |
AT140,CT14#,KT147,ST140,TT147,YT140 厚さ=2.525−2.575,T=2.525-2.575 |
12 | ||
| 90521-29072 |
AT140,CT14#,KT147,ST140,TT147,YT140 厚さ=2.475−2.525,T=2.475-2.525 |
12 | ||
| 90521-29071 |
AT140,CT14#,KT147,ST140,TT147,YT140 厚さ=2.425−2.475,T=2.425-2.475 |
12 | ||
| 37402 - BEARING SUB-ASSY, UNIVERSAL JOINT SPIDER | ||||
| 37402-22020 |
AT140,CT14#,KT147,ST140,TT147,YT140 |
12 | ||
| Common parts | ||||
| 90170-08007 | ||||
| 90170-08015 | ||||
| 94512-00800 | ||||
(8201-8712)KT147,TT147
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 37101A - PIECE, BALANCE, NO.1 (FOR PROPELLER SHAFT) | ||||
| 90937-01136 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 20G,長さ=41.4,20G |
2 | ||
| 90937-01153 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 16G,長さ=33.2,16G |
2 | ||
| 90937-01157 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 26G,長さ=53.9,26G |
2 | ||
| 90937-01140 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 30G,長さ=62.2,30G |
2 | ||
| 90937-01156 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 24G,長さ=49.7,24G |
2 | ||
| 90937-01149 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 6G,長さ=12.4,6G |
2 | ||
| 90937-01154 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 18G,長さ=37.3,18G |
2 | ||
| 90937-01147 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 2G,厚さ=2.0,2G |
2 | ||
| 90937-01152 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 14G,長さ=29.0,14G |
2 | ||
| 90937-01158 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 28G,長さ=58.1,28G |
2 | ||
| 90937-01132 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 10G,長さ=20.7,10G |
2 | ||
| 90937-01150 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 8G,長さ=16.6,8G |
2 | ||
| 90937-01148 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 4G,厚さ=2.0,4G |
2 | ||
| 90937-01155 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 22G,長さ=45.6,22G |
2 | ||
| 90937-01151 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 12G,長さ=24.9,12G |
2 | ||
| 37110 - SHAFT ASSY, PROPELLER | ||||
| 37110-21040 |
TT147..4F SHEEL TYPE |
1 | ||
| 37110-21050 |
TT147..4F SOLID TYPE |
1 | ||
| 37110A - BOLT (FOR PROPELLER SHAFT) | ||||
| 90101-08062 |
AT140,CT14#,RT141,ST140,TT14#,YT140 |
8 | ||
| 37331 - COVER, SLIDING SHAFT DUST | ||||
| 37331-30010 |
CT140,147,RT141,YT140;AT140,KT147,ST140,TT14#..ATM |
1 | ||
| 37331-12010 |
AT14#,KT147,ST140,TT14#..MTM..(DLX,EXS,GT,GX,GXA,STD,SX) |
1 | ||
| Common parts | ||||
| 90170-08007 | ||||
| 90170-08015 | ||||
| 94512-00800 | ||||
(8201-9111)AT14#,CT14#,RT141,ST140,TT142..DLX,EXA,EXS,GT,GX,GXA,STD,SX ; (8210-8508
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 37101A - PIECE, BALANCE, NO.1 (FOR PROPELLER SHAFT) | ||||
| 90937-01136 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 20G,長さ=41.4,20G |
2 | ||
| 90937-01153 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 16G,長さ=33.2,16G |
2 | ||
| 90937-01157 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 26G,長さ=53.9,26G |
2 | ||
| 90937-01140 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 30G,長さ=62.2,30G |
2 | ||
| 90937-01156 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 24G,長さ=49.7,24G |
2 | ||
| 90937-01149 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 6G,長さ=12.4,6G |
2 | ||
| 90937-01154 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 18G,長さ=37.3,18G |
2 | ||
| 90937-01147 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 2G,厚さ=2.0,2G |
2 | ||
| 90937-01152 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 14G,長さ=29.0,14G |
2 | ||
| 90937-01158 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 28G,長さ=58.1,28G |
2 | ||
| 90937-01132 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 10G,長さ=20.7,10G |
2 | ||
| 90937-01150 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 8G,長さ=16.6,8G |
2 | ||
| 90937-01148 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 4G,厚さ=2.0,4G |
2 | ||
| 90937-01155 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 22G,長さ=45.6,22G |
2 | ||
| 90937-01151 |
AT14#,CT14#,KT147,RT141,ST140,TT14#,YT140 12G,長さ=24.9,12G |
2 | ||
| 37110 - SHAFT ASSY, PROPELLER | ||||
| 37110-21040 |
TT147..4F SHEEL TYPE |
1 | ||
| 37110-21050 |
TT147..4F SOLID TYPE |
1 | ||
| 37110 - SHAFT ASSY, PROPELLER | ||||
| 37110-21040 |
TT147..4F SHEEL TYPE |
1 | ||
| 37110-21050 |
TT147..4F SOLID TYPE |
1 | ||
| 37110A - BOLT (FOR PROPELLER SHAFT) | ||||
| 90101-08062 |
AT140,CT14#,RT141,ST140,TT14#,YT140 |
8 | ||
| 37110A - BOLT (FOR PROPELLER SHAFT) | ||||
| 90101-08062 |
AT140,CT14#,RT141,ST140,TT14#,YT140 |
8 | ||
| 37120A - WASHER, PLATE (FOR PROPELLER INTERMEDIATE SHAFT SET) | ||||
| 90201-18182 |
AT14#,CT14#,RT141,ST140,TT14#,YT140 外径=33.5,厚さ=4.0,T=4,OD=33.5 |
1 | ||
| 37120A - WASHER, PLATE (FOR PROPELLER INTERMEDIATE SHAFT SET) | ||||
| 90201-18182 |
AT14#,CT14#,RT141,ST140,TT14#,YT140 外径=33.5,厚さ=4.0,T=4,OD=33.5 |
1 | ||
| 37331 - COVER, SLIDING SHAFT DUST | ||||
| 37331-30010 |
CT140,147,RT141,YT140;AT140,KT147,ST140,TT14#..ATM |
1 | ||
| 37331-12010 |
AT14#,KT147,ST140,TT14#..MTM..(DLX,EXS,GT,GX,GXA,STD,SX) |
1 | ||
| Common parts | ||||
| 90170-08007 | ||||
| 90170-08015 | ||||
| 94512-00800 | ||||
