CT170-AEMES (1987)
Toyota Corona
(8712- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 53410 - HINGE ASSY, HOOD, RH | ||||
| 53410-20100 |
AT17#,CT17#,ET176,ST17# |
1 | ||
| 53420 - HINGE ASSY, HOOD, LH | ||||
| 53420-20090 |
AT17#,CT17#,ET176,ST17# |
1 | ||
| 53445 - COVER, HOOD HINGE, RH | ||||
| 53445-20010 |
AT17#,CT17#,ET176,ST17# |
1 | ||
| 53446 - COVER, HOOD HINGE, LH | ||||
| 53446-20010 |
AT17#,CT17#,ET176,ST17# |
1 | ||
| 53451 - ROD, HOOD SUPPORT | ||||
| 53451-20080 |
AT17#,CT17#,ET176,ST17# |
1 | ||
| 53451A - GROMMET(FOR HOOD SUPPORT ROD) | ||||
| 90480-15012 |
AT17#,CT17#,ET176,ST17# |
1 | ||
| 53455 - CLAMP, HOOD SUPPORT ROD | ||||
| 53455-14020 |
AT17#,CT17#,ET176,ST17# |
1 | ||
| 53497 - PAD, HOOD HINGE, NO.1 | ||||
| 53497-20020 |
AT17#,CT17#,ET176,ST17# |
1 | ||
| 53497 - PAD, HOOD HINGE, NO.1 | ||||
| 53497-20020 |
AT17#,CT17#,ET176,ST17# |
1 | ||
| 53498 - PAD, HOOD HINGE, NO.2 | ||||
| 53498-20010 |
AT17#,CT17#,ET176,ST17# |
1 | ||
| 53498 - PAD, HOOD HINGE, NO.2 | ||||
| 53498-20010 |
AT17#,CT17#,ET176,ST17# |
1 | ||
| 53510 - LOCK ASSY, HOOD | ||||
| 53510-20130 |
AT17#,CT17#,ET176,ST17# |
1 | ||
| 53510-20310 |
AT17#,CT170,ST17# |
1 | ||
| 53510A - SPRING, TENSION(FOR HOOD LOCK) | ||||
| 90506-09029 |
AT17#,CT17#,ET176,ST17# 線径=0.9,WD=0.9,CW=26.5 |
1 | ||
| 90506-09044 |
AT17#,CT170,ST17# WD=0.9,CW=9.5 |
1 | ||
| 90506-20008 |
AT17#,CT17#,ET176,ST17# 線径=2.0,ｺｲﾙ巻数=17,WD=2.0,CW=17 |
1 | ||
| 53510A - SPRING, TENSION(FOR HOOD LOCK) | ||||
| 90506-09029 |
AT17#,CT17#,ET176,ST17# 線径=0.9,WD=0.9,CW=26.5 |
1 | ||
| 90506-09044 |
AT17#,CT170,ST17# WD=0.9,CW=9.5 |
1 | ||
| 90506-20008 |
AT17#,CT17#,ET176,ST17# 線径=2.0,ｺｲﾙ巻数=17,WD=2.0,CW=17 |
1 | ||
| 53601 - LEVER SUB-ASSY, HOOD LOCK CONTROL | ||||
| 53601-10020J0 |
AT17#,CT170,ST17#..DX,EXG,EXS,G,GX,MX,X,Z DARK BLUE,TRIM8# |
1 | ||
| 53601-1002023 |
AT17#,CT17#,ET176,ST17# GRAY,TRIM1# |
1 | ||
| 53601-1002024 |
AT17#,CT170,ST17#..DX,EXG,EXS,G,GX,MX,X,Z DARK BLUE,TRIM8# |
1 | ||
| 53601-1002023 |
AT17#,CT17#,ET176,ST17# GRAY,TRIM1# |
1 | ||
| 53601-1002034 |
AT17#,CT170,ST17#..DX,EXG,EXS,G,GX,SELS,X,Z DARK BLUE,TRIM8# |
1 | ||
| 53601-1002016 |
AT17#,CT17#,ET176,ST17#..DX,EXG,EXS,G,GX,MX,SELS,X,Z SABLE,TRIM4# |
1 | ||
| 53601-1002023 |
CT176..5F;CT170,ET176..(3FC,4FC,5F)..(EXS,GX);AT175,ET176,ST171..(4F,4FC,5F)..(DX,EXG,G,GT,GTR,GX,STD,SXR) GRAY,TRIM1# |
1 | ||
| 53630 - CABLE ASSY, HOOD LOCK CONTROL | ||||
| 53630-20220 |
AT17#,CT17#,ET176,ST17# |
1 | ||
| Common parts | ||||
| 90105-08087 | ||||
| 90119-06423 | ||||
| 90467-09043 | ||||
| 93567-55016 | ||||
