AT190-AEMMK (1992)

Toyota Corona

Production Feb 1992 - Jan 1996
Engine 4AFE
Transmission MTM
Displacement 2500cc
Power 168 HP (125 kW)

(9202-9402) ; (9402- )LB

Click highlighted areas on diagram

diagram 84987A 89704 89705 89706 89707 89708 89743 9015120002 9017906100
Part # Description Qty Price
89704 - CONTROL SET, WIRELESS DOOR LOCK
89704-20130

CT195..EXS;AT190,CT190,ST19#..EXG,EXS,SELS

 1
89704-20130

AT190,CT190,ST190,195..SELS

ｾﾚｸﾄｻﾙ-ﾝG

 1
89705 - TRANSMITTER, DOOR CONTROL
89742-12060

AT190,CT190,ST190,195..SELS

ｾﾚｸﾄｻﾙ-ﾝG

 1
89706 - BATTERY SET, TRANSMITTER
89706-50010

CT195..EXS;AT190,CT190,ST19#..EXG,EXS,SELS,TYPE1,TYPE2

 1
89706-50010

AT190,CT190,ST190,195..SELS

ｾﾚｸﾄｻﾙ-ﾝG

 1
89708 - CYLINDER SET, WIRELESS DOOR LOCK
89708-20030

CT195..EXS;AT190,CT190,ST19#..EXG,EXS,SELS

 1
Common parts
90151-20002
90179-06100

(9402- )SED

Click highlighted areas on diagram

diagram 84987A 89704 89706 89707 89708 89741 89742 9015120002 9017906100
Part # Description Qty Price
89704 - CONTROL SET, WIRELESS DOOR LOCK
89704-20130

CT195..EXS;AT190,CT190,ST19#..EXG,EXS,SELS

 1
89704-20130

AT190,CT190,ST190,195..SELS

ｾﾚｸﾄｻﾙ-ﾝG

 1
89706 - BATTERY SET, TRANSMITTER
89706-50010

CT195..EXS;AT190,CT190,ST19#..EXG,EXS,SELS,TYPE1,TYPE2

 1
89706-50010

AT190,CT190,ST190,195..SELS

ｾﾚｸﾄｻﾙ-ﾝG

 1
89708 - CYLINDER SET, WIRELESS DOOR LOCK
89708-20030

CT195..EXS;AT190,CT190,ST19#..EXG,EXS,SELS

 1
89741 - RECEIVER, DOOR CONTROL
89741-20100

CT195..EXS;AT190,CT190,ST19#..EXG,EXS,SELS

 1
89741-20100

AT190,CT190,ST190,195..SELS

ｾﾚｸﾄｻﾙ-ﾝG

 1
89742 - TRANSMITTER, DOOR CONTROL
89742-12060

CT195..EXS;AT190,CT190,ST19#..EXG,EXS,SELS

 1
89742-12060

AT190,CT190,ST190,195..SELS

ｾﾚｸﾄｻﾙ-ﾝG

 1
Common parts
90151-20002
90179-06100
