AE91-ACMGU (1987)
Toyota Corolla Levin
ILLUST NO. 1 OF 2(8705- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 85312 - PACKING, WINDSHIELD WASHER TANK | ||||
| 85312-12650 |
AE9# |
1 | ||
| 85330 - JAR ASSY, WINDSHIELD WASHER | ||||
| 85331-12660 |
AE9#..G,GT,L,ZI ｱﾘ(ﾘﾔ ﾜｲﾊﾟ) |
1 | ||
| 85331-12650 |
AE9#..G,GT,GTV,GTZ,L,ZI,ZS |
1 | ||
| 85331-12660 |
AE9#..G,GT,L,ZI ｱﾘ(ﾘﾔ ﾜｲﾊﾟ) |
1 | ||
| 85330 - JAR ASSY, WINDSHIELD WASHER | ||||
| 85331-12660 |
AE9#..G,GT,L,ZI ｱﾘ(ﾘﾔ ﾜｲﾊﾟ) |
1 | ||
| 85331-12650 |
AE9#..G,GT,GTV,GTZ,L,ZI,ZS |
1 | ||
| 85331-12660 |
AE9#..G,GT,L,ZI ｱﾘ(ﾘﾔ ﾜｲﾊﾟ) |
1 | ||
| 85330A - BUSH, WINDSHIELD WASHER JAR | ||||
| 90099-32089 |
AE9# |
1 | ||
| 85330A - BUSH, WINDSHIELD WASHER JAR | ||||
| 90099-32089 |
AE9# |
1 | ||
| 85332 - CAP, WINDSHIELD WASHER JAR | ||||
| 85332-12660 |
AE9#..G,GT,L,ZI ｶﾝﾚｲﾁ ｼﾖｳ OR ﾕｷｸﾞﾆ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 85332-12320 |
AE9# |
1 | ||
| 85332 - CAP, WINDSHIELD WASHER JAR | ||||
| 85332-12660 |
AE9#..G,GT,L,ZI ｶﾝﾚｲﾁ ｼﾖｳ OR ﾕｷｸﾞﾆ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 85332-12320 |
AE9# |
1 | ||
| Common parts | ||||
| 90099-04435 | ||||
| 90099-05247 | ||||
| 90119-06144 | ||||
| 90119-06374 | ||||
| 90119-06404 | ||||
| 90179-06156 | ||||
| 91655-40616 | ||||
ILLUST NO. 2 OF 2(8705- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85035-12350 |
AE9# |
2 | ||
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85035-12350 |
AE9# |
2 | ||
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85035-12350 |
AE9# |
2 | ||
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85035-12350 |
AE9# |
2 | ||
| 85310 - MOTOR AND PUMP ASSY, WINDSHIELD WASHER | ||||
| 85310-22080 |
AE9# |
1 | ||
| 85310 - MOTOR AND PUMP ASSY, WINDSHIELD WASHER | ||||
| 85310-22080 |
AE9# |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85349-89122 |
AE9# 2-WAY |
2 | ||
| 85348-12250 |
AE9# 3-WAY |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85349-89122 |
AE9# 2-WAY |
2 | ||
| 85348-12250 |
AE9# 3-WAY |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85349-89122 |
AE9# 2-WAY |
2 | ||
| 85348-12250 |
AE9# 3-WAY |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85349-89122 |
AE9# 2-WAY |
2 | ||
| 85348-12250 |
AE9# 3-WAY |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85349-89122 |
AE9# 2-WAY |
2 | ||
| 85348-12250 |
AE9# 3-WAY |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85349-89122 |
AE9# 2-WAY |
2 | ||
| 85348-12250 |
AE9# 3-WAY |
1 | ||
| 85348D - JOINT, WINDSHIELD WASHER ELBOW, NO.1 | ||||
| 85355-14481 |
AE9# |
1 | ||
| 85348D - JOINT, WINDSHIELD WASHER ELBOW, NO.1 | ||||
| 85355-14481 |
AE9# |
1 | ||
| 85371 - HOSE, WINDSHIELD WASHER (FROM MOTOR TO JOINT) | ||||
| 90099-33410 |
AE9#..G,GT,GTV,GTZ,L,ZI,ZS *H,L=1100 |
1 | ||
| 85371 - HOSE, WINDSHIELD WASHER (FROM MOTOR TO JOINT) | ||||
| 90099-33410 |
AE9#..G,GT,GTV,GTZ,L,ZI,ZS *H,L=1100 |
1 | ||
| 85372 - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.1 | ||||
| 90099-33080 |
AE9# L=1450 |
1 | ||
| 85372 - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.1 | ||||
| 90099-33080 |
AE9# L=1450 |
1 | ||
| 85372G - TUBE, RUBBER | ||||
| 90099-33080 |
AE9# L=1450 |
1 | ||
| 85372G - TUBE, RUBBER | ||||
| 90099-33080 |
AE9# L=1450 |
1 | ||
| 85373 - HOSE, WINDSHIELD WASHER (FROM JOINT TO NOZZLE) | ||||
| 90099-33080 |
AE9#..G,GT,GTV,GTZ,L,ZI,ZS L=1450 |
1 | ||
| 85373 - HOSE, WINDSHIELD WASHER (FROM JOINT TO NOZZLE) | ||||
| 90099-33080 |
AE9#..G,GT,GTV,GTZ,L,ZI,ZS L=1450 |
1 | ||
| Common parts | ||||
| 16581-63010 | ||||
| 90099-35402 | ||||
| 90989-01031 | ||||
| 91655-40616 | ||||
