NL30-KGMDX (1988)
Toyota Corolla 2
(8805- )AR,CD,GL,GP,SRI,TX
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45025D - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.1 | ||||
| 45025-16070 |
EL3#,NL30..AR,CD,GL,GP,SRI,TX |
1 | ||
| 45025-16091 |
NL30..GL,TX;EL3#..AR,GL,SRI ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45025-16091 |
EL3#,NL30..AR,GL,SRI,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45026 - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.2 | ||||
| 45026-16032 |
EL3#,NL30..AR,GL,SRI,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45026-16032 |
NL30..GL,TX;EL3#..AR,GL,SRI ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45026-16010 |
EL3#,NL30..AR,CD,GL,GP,SRI,TX |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17196 |
EL3#,NL30 厚さ=1.35−1.45 |
2 | ||
| 90520-17042 |
EL3#,NL30 厚さ=1.20 |
2 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17196 |
EL3#,NL30 厚さ=1.35−1.45 |
2 | ||
| 90520-17042 |
EL3#,NL30 厚さ=1.20 |
2 | ||
| 45204 - TUBE ASSY, STEERING COLUMN, LOWER | ||||
| 45204-16011 |
NL30;EL3#..AR,CD,GL,GP,SRI,TX |
1 | ||
| 45205J - TUBE SUB-ASSY, STEERING COLUMN, UPPER | ||||
| 45205-16050 |
NL30;EL3#..AR,CD,GL,GP,SRI,TX |
1 | ||
| 45205-16051 |
NL30;EL3#..AR,CD,GL,GP,SRI,TX |
1 | ||
| 45209 - YOKE SUB-ASSY, STEERING SLIDING | ||||
| 45209-16020 |
EL3#,NL30..AR,GL,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45209-16030 |
EL3#,NL30..AR,CD,GL,GP,SRI,TX |
1 | ||
| 45209-16020 |
EL3#..AR,GL;NL30..GL,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45210 - SHAFT ASSY, STEERING MAIN | ||||
| 45210-16100 |
EL3#,NL30..AR,GL,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45210-16100 |
EL3#..AR,GL;NL30..GL,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45210-16081 |
EL3#,NL30..AR,CD,GL,GP,SRI,TX |
1 | ||
| 45271 - CLAMP, STEERING COLUMN, UPPER | ||||
| 45271-16020 |
EL3#,NL30 |
1 | ||
| 45273 - BUSH, STEERING MAIN SHAFT | ||||
| 45273-16010 |
EL3#,NL30 |
1 | ||
| 45280A - BRACKET ASSY, STEERING COLUMN, UPPER | ||||
| 45280-16041 |
EL3#,NL30 |
1 | ||
| 45283A - PLATE, BEAM CHANGE & TURN SIGNAL CAUTION | ||||
| 45283-12010 |
EL3#,NL30 |
1 | ||
| 45286 - COVER, STEERING COLUMN | ||||
| 45286-1690904 |
NL30;EL3#..AR,CD,GL,GP,SRI,TX BLUE,TRIM8# |
1 | ||
| 45286-1690901 |
NL30;EL3#..AR,GL,GP,SRI,TX NEW BLACK,TRIM2# |
1 | ||
| 45295 - BUSH, STEERING COLUMN TUBE | ||||
| 45295-16010 |
EL3#,NL30 |
1 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-32010 |
EL3#,NL30 |
2 | ||
| 45897-12020 |
EL3#,NL30 |
2 | ||
| Common parts | ||||
| 90119-08560 | ||||
| 90164-50048 | ||||
| 90179-06007 | ||||
| 90179-10016 | ||||
| 91515-40612 | ||||
| 91651-40618 | ||||
| 91665-61025 | ||||
| 93315-14012 | ||||
