TE70-EEHNS (1979)
Toyota Corolla
(7908-8108)13TU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17061 - DIAPHRAGM SUB-ASSY | ||||
| 17061-26010 |
13TU..TE70 |
1 | ||
| 17700 - CLEANER ASSY, AIR | ||||
| 17700-27120 |
13TU..TE70 |
1 | ||
| 17700-27121 |
13TU..TE70 |
1 | ||
| 17700-27122 |
13TU..TE70 |
1 | ||
| 17700A - NUT, WING(FOR AIR CLEANER) | ||||
| 90175-06003 |
12TJ,13TU..TE70,73 |
1 | ||
| 17705 - CAP SUB-ASSY, AIR CLEANER | ||||
| 17705-25012 |
12TJ,13TU..TE70,73 |
1 | ||
| 17706 - INLET SUB-ASSY, AIR CLEANER, NO.2 | ||||
| 17902-27031 |
13TU..TE70 |
1 | ||
| 17902-27032 |
13TU..TE70 |
1 | ||
| 17728 - VALVE, THERMOSTATIC | ||||
| 17728-27010 |
13TU..TE70 |
1 | ||
| 17848 - GASKET, AIR CLEANER TO CARBURETOR | ||||
| 90430-63187 |
12TJ,13TU..TE70,73 |
1 | ||
| 17881 - HOSE, AIR CLEANER, NO.1 | ||||
| 17881-26020 |
13TU..TE70 |
1 | ||
| 17882 - HOSE, AIR CLEANER, NO.2 | ||||
| 17881-28020 |
13TU..TE70..GL,SE,SL W/POWER STEERING |
1 | ||
| 17881-27030 |
13TU..TE70 |
1 | ||
| 17882 - HOSE, AIR CLEANER, NO.2 | ||||
| 17881-28020 |
13TU..TE70..GL,SE,SL W/POWER STEERING |
1 | ||
| 17881-27030 |
13TU..TE70 |
1 | ||
| 17882A - CLAMP(FOR AIR CLEANER HOSE, NO.2) | ||||
| 90460-01003 |
13TU..TE70 AIR CLEANER SIDE |
1 | ||
| 96111-10560 |
13TU..TE70..GL,SE,SL BODY SIDE,W/POWER STEERING |
1 | ||
| 17882A - CLAMP(FOR AIR CLEANER HOSE, NO.2) | ||||
| 90460-01003 |
13TU..TE70 AIR CLEANER SIDE |
1 | ||
| 96111-10560 |
13TU..TE70..GL,SE,SL BODY SIDE,W/POWER STEERING |
1 | ||
| 17882A - CLAMP(FOR AIR CLEANER HOSE, NO.2) | ||||
| 90460-01003 |
13TU..TE70 AIR CLEANER SIDE |
1 | ||
| 96111-10560 |
13TU..TE70..GL,SE,SL BODY SIDE,W/POWER STEERING |
1 | ||
| 17883 - HOSE, AIR CLEANER, NO.3 | ||||
| 17882-13031 |
13TU..TE70..GL,SE,SL W/POWER STEERING |
1 | ||
| 17882-13030 |
13TU..TE70..GL,SE,SL W/POWER STEERING |
1 | ||
| 17883A - CLAMP(FOR AIR CLEANER HOSE, NO.3) | ||||
| 90460-60001 |
13TU..TE70..GL,SE,SL HOSE X APRON,W/POWER STEERING |
1 | ||
| 17887 - COVER, AIR CLEANER HOSE | ||||
| 17887-27010 |
13TU..TE70 |
1 | ||
| 17991 - CASE, AIR SUCTION FILTER | ||||
| 17991-27070 |
13TU..TE70 |
1 | ||
| 17991-27080 |
13TU..TE70 |
1 | ||
| 23285B - VALVE, CHECK, NO.1 | ||||
| 90917-10053 |
13TU..TE70 COLD SPEC |
1 | ||
| 25710D - VALVE ASSY, AIR SWITCHING | ||||
| 25710-18030 |
13TU..TE70 |
1 | ||
| 25710-18031 |
13TU..TE70 |
1 | ||
| 25717 - GASKET, AIR SWITCHING VALVE | ||||
| 25717-18010 |
13TU..TE70 |
1 | ||
| Common parts | ||||
| 90119-06164 | ||||
| 90159-60008 | ||||
| 90179-06097 | ||||
| 90189-06005 | ||||
| 90445-11048 | ||||
| 90445-11961 | ||||
| 91621-40812 | ||||
| 93319-15010 | ||||
| 93385-15010 | ||||
| Linked diagrams | ||||
| 1709 | ||||
